Fiche recette : les ingrédients à côté de la préparation

// ═══ Postext Cookbook · Nº 033 · Recipe card: ingredients beside the method ═══════
// https://postext.dev/en/cookbook/recipe-card
// Code: MIT · Text: original (CC BY 4.0) · Photos: diffusion models · Pictograms: CC BY 4.0
// Fonts: Young Serif, Figtree, Caveat (SIL OFL 1.1) · Needs postext ≥ 1.25.0
import {
  buildDocumentWithFonts, renderPageToCanvas, registerResourceImage,
} from 'https://esm.sh/postext';

const LANG = 'en'; // @lang: the language of the sample document ('en' | 'es')
const RECIPE = 'recipe-card';

// ─── 1 · Design ─────────────────────────────────────────────────────────────
const palette = { ink: '#2b2118', muted: '#76634e', // text; folios and the colophon
  paper: '#f7eddb', card: '#fffdf8', // the cream page; the white recipe card on it
  tomato: '#bf3d29', olive: '#6b7a3a', tint: '#f6e3c1' }; // numbers and tab; dashes; tags
// Each colour names its palette entry and carries its hex.
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
// The engine's defaults link to 'main-color': point it at the tomato, so nothing prints blue.
const colorPalette = Object.entries({ ...palette, 'main-color': palette.tomato })
  .map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } }));
const [TEXT, DISPLAY, HAND] = ['Figtree', 'Young Serif', 'Caveat'];
const PAGE = { w: 190, h: 250, top: 22, inner: 18, outer: 16 }; // mm, mirrored margins
const [BODY, LEAD] = [9.4, 12.8]; // pt: the text of the cards and the notes under them

// #region answer: a white card with a servings tab, two columns inside it
// In the Markdown, :::callout{type="card" label="SERVES 4"} holds a :::columns{count=2} group
// of two nested boxes, :::callout{type="column" title="Ingredients"} and one for the method.
// The group levels its columns by cutting between blocks or lines, so loose lists would run
// the method on under the ingredients. A nested box is one block that never splits, so the
// only cut left is between the two.
const TAB = 5.6; // mm: the tab's height, and how far it rises above the card
const card = { id: 'card', background: col('card'),
  padding: { top: mm(4.5), right: mm(6), bottom: mm(5), left: mm(6) },
  // No space of its own above: the tab starts on the first grid line under the opener.
  columnGap: mm(7), marginTop: mm(0),
  // label="…" on the fence prints here: a tab on the top-right corner, a cutlery pictogram
  // beside it and a rule from the far corner that makes the tab part of the card.
  label: { fontFamily: TEXT, fontSize: pt(8), color: col('card'), // bold by default
    background: col('tomato'), height: mm(TAB), offset: mm(TAB), paddingX: mm(2.6),
    icon: { resourceId: 'cutlery', width: mm(TAB * 6 / 8), gap: mm(1.6) }, // as tall as the tab
    rule: { enabled: true, color: col('tomato'), width: pt(1.2) } } };
// The two columns: frameless boxes whose only device is a tracked title.
const NONE = { top: mm(0), right: mm(0), bottom: mm(0), left: mm(0) };
const column = { id: 'column', backgroundEnabled: false, padding: NONE,
  lists: { gap: mm(2.2), itemSpacing: pt(3.5) }, // for the steps as well as the dashes
  titleStyle: { fontFamily: TEXT, fontSize: pt(8), color: col('tomato'), // bold by default
    textTransform: 'uppercase', letterSpacing: pt(1.5), gap: mm(2.4) } };
// config() plugs them in: calloutStyles: [card, column, prep].
// #endregion

// #region prep: a checklist under a header with a strip of three pictograms
// :::callout{type="prep" title="Before you start"}, closed at once, is a header: a box that
// holds only its title and icon. The icon is one picture of three drawings; a width KIT times
// its size makes its box a strip, and the picture is fitted into width × size, left of the
// title. Tasks set inside the box would start after that column, 21 mm in, so the '- [ ]'
// items follow the box, where they print the default task box, '☐'.
const [STRIP, KIT] = [5, 30 / 8]; // mm: the strip's height; the drawing's width over height
const prep = { id: 'prep', backgroundEnabled: false, padding: NONE,
  marginTop: pt(LEAD), marginBottom: column.titleStyle.gap, // the tasks follow at this gap
  icon: { kind: 'resource', resourceId: 'kit', size: mm(STRIP), width: mm(STRIP * KIT),
    align: 'center' }, // the title centred on the strip
  titleStyle: { ...column.titleStyle, color: col('olive') } };
// #endregion

// #region steps: big step numbers in the display face, an olive full stop after each
// Young Serif has old-style figures: 1 and 2 stand 0.56 em, a little above its 0.50 em
// x-height, so 5.1 mm at STEP. A list number is centred 0.3 em (of the text) above the item's
// first baseline, with the canvas 'middle' baseline, which Chrome puts 0.24 em above Young
// Serif's own (gotcha: list-number-centred). DROP centres the figures on the step's first two
// lines, from the cap height of the first to the baseline of the second.
const [STEP, FIGURE, MIDDLE, CAP] = [26, 0.56, 0.24, 0.7]; // pt; em of each face
const DROP = (LEAD - CAP * BODY) / 2 + 0.3 * BODY + (FIGURE / 2 - MIDDLE) * STEP; // pt
const orderedLists = { fontFamily: DISPLAY, fontWeight: 400, // Young Serif ships 400 only
  numberFontSize: pt(STEP), color: col('tomato'),
  separatorColor: col('olive'), separatorGap: pt(0.6), // the default '.' as its own run
  numberVerticalOffset: pt(DROP) };
// #endregion

// #region chips: tags for diet and occasion, as pills in the text
const chipStyles = [{ id: 'tag', fontSize: em(0.86), bold: true, background: col('tint'),
  borderWidth: pt(0), borderRadius: em(1), // no outline; a radius past half the height: a pill
  paddingX: em(0.7), paddingY: em(0.18), gap: em(0.3) }];
// #endregion

// #region opener: the photograph bled across the head, the title and pills set on it
const BAND = 104; // mm: the photo's foot; the pills sit 13 mm above it, the lead 6 mm below
const NOTE = { x: 18, y: 24, w: 70 }; // mm on the page: the box ends 2 mm before the arrow
const at = (x, y, size) => ({ anchor: { to: 'container', edge: 'top-left' },
  offset: { x: mm(x), y: mm(y - PAGE.top) }, size }); // y in mm from the top of the page
const text = (id, content, family, size, placement, extra) => ({ kind: 'text', id, content,
  fontFamily: family, fontSize: pt(size), color: col('ink'), align: 'left',
  overflow: 'wrap', placement, ...extra }); // a foot wraps too, where the default is '…'
const tracked = { fontWeight: 700, textTransform: 'uppercase', letterSpacing: pt(1.6) };
// Pills are text boxes chained right-of each other; each prints one heading attribute.
const pill = (id, after) => text(id, `{attr.${id}}`, TEXT, 8.4, after ? { anchor:
  { to: `#${after}`, edge: 'right-of' }, offset: { x: mm(1.8) } } : at(0, BAND - 13), {
  fontWeight: 600, box: { backgroundColor: col('card'), borderRadius: mm(3),
    padding: { top: mm(1.1), right: mm(2.8), bottom: mm(1.1), left: mm(2.8) } } });
// One heading style for every recipe; each heading names its photo: art="tortilla".
const opener = { id: 'receta', advancedDesign: { enabled: true, slot: { elements: [
    { kind: 'image', id: 'art', resourceId: '{attr.art}', // filled in per heading, like a text
      placement: { anchor: { to: 'page', edge: 'top-left' },
        size: { width: mm(PAGE.w), height: mm(BAND) } } },
    { kind: 'image', id: 'arrow', resourceId: 'arrow', // the note's arrow, over the photo
      placement: { anchor: { to: 'page', edge: 'top-left' },
        size: { width: mm(PAGE.w), height: mm(BAND) } } },
    text('note', '{attr.note}', HAND, 19, { anchor: { to: 'page', edge: 'top-left' },
      offset: { x: mm(NOTE.x), y: mm(NOTE.y) }, size: { width: mm(NOTE.w) } },
    { fontWeight: 600, align: 'right' }), // on the page, like the arrow and the photo
    pill('time'), pill('level', 'time'), pill('season', 'level'),
    text('title', '{titleText}', DISPLAY, 42, { anchor: { to: '#time', edge: 'above' },
      offset: { y: mm(-3.2) }, size: { width: mm(96) } }, // two lines: the \\ in the heading
    { lineHeight: 1 }), // set solid: 42 pt from line to line
    text('kicker', '{attr.kicker}', TEXT, 8.2, { anchor: { to: '#title', edge: 'above' },
      offset: { y: mm(-2.4) }, size: { width: mm(96) } }, tracked),
    // The lead is the design's lowest element: the opener reserves down to its last line, and
    // the card starts under it without a minHeight.
    text('lead', '{attr.lead}', TEXT, 10.5, at(0, BAND + 6, { width: mm(122) }),
      { italic: true, lineHeight: 1.45 }),
  ] } } };
// #endregion

// Folios at the foot of the outer corner: the book on versos, the recipe on rectos.
const foot = (id, content, parity, edge, x, look) => text(id, content, TEXT, 7.6,
  { anchor: { to: 'page', edge }, offset: { x: mm(x), y: mm(-12) } },
  { color: col('muted'), parity, align: edge.endsWith('left') ? 'left' : 'right', ...look });
const folio = { fontFamily: DISPLAY, fontSize: pt(10), color: col('tomato') };
const footer = { elements: [
  foot('verso-folio', '{pageNumber}', 'even', 'bottom-left', PAGE.outer, folio),
  foot('verso-book', '{title}', 'even', 'bottom-left', PAGE.outer + 9, tracked),
  foot('recto-dish', '{chapterTitle}', 'odd', 'bottom-right', -(PAGE.outer + 9), tracked),
  foot('recto-folio', '{pageNumber}', 'odd', 'bottom-right', -PAGE.outer, folio),
] };

const config = () => ({
  colorPalette, chipStyles, orderedLists, footer, header: { elements: [] },
  page: { width: mm(PAGE.w), height: mm(PAGE.h), dpi: 150, backgroundColor: col('paper'),
    margins: { top: mm(PAGE.top), bottom: mm(20), left: mm(PAGE.inner),
      right: mm(PAGE.outer), mirror: true } }, // left is the inner margin
  layout: { layoutType: 'single' }, locale: t({ en: 'en-us', es: 'es' }), // the edition's language
  bodyText: { fontFamily: TEXT, fontSize: pt(BODY), lineHeight: pt(LEAD), color: col('ink'),
    boldColor: col('ink'), italicColor: col('ink'), referenceColor: col('ink'),
    textAlign: 'left', firstLineIndent: mm(0) }, // ragged and flush: the notes under the cards
  // A designed heading's own text is hidden but still measured: in Young Serif 400, the only
  // weight it ships, not in the default Open Sans 700 that FONTS does not load.
  headings: { fontFamily: DISPLAY, fontWeight: 400, levels: [
    // 'any': each recipe opens the next page, whichever side it is on.
    { level: 1, breakBefore: { enabled: true, parity: 'any' } },
  ] },
  headingStyles: [opener],
  // Olive dashes for the whole document: an olive lists.color on the column style would turn
  // the step numbers olive too (gotcha: box-list-colour-numbers).
  unorderedLists: { bulletChar: '–', color: col('olive'),
    marginTop: mm(0), // under the checklist's header, the header's marginBottom alone
    marginBottom: pt(LEAD / 2) }, // half a line above the tags
  calloutStyles: [card, column, prep],
  paragraphStyles: [{ id: 'colophon', fontSize: pt(7.4), lineHeight: pt(10),
    color: col('muted'), marginTop: pt(LEAD) }],
});

// ─── 2 · Content ────────────────────────────────────────────────────────────
const markdown = String.raw`---
Exemple Markdown · 66 lignes · content.en.md
title: "Salt & Olive Oil"
---

# Tortilla \\ de patatas {style="receta" art="tortilla" kicker="Spanish potato omelette" time="45 min" level="Intermediate" season="All year" note="onion, always!" lead="Our house version: potatoes poached slowly in plenty of oil, eggs barely set and ten minutes’ rest so the potato soaks up the egg. With onion, as my grandmother made it; without, if your family argues about it."}

:::callout{type="card" label="SERVES 4"}
:::columns{count=2}
:::callout{type="column" title="Ingredients"}
- **6** large free-range eggs
- **800 g** frying potatoes
- **1** medium onion
- **300 ml** extra virgin olive oil
- Fine salt

:chip[Vegetarian]{style="tag"} :chip[Gluten-free]{style="tag"} :chip[Picnic]{style="tag"}

:::callout{type="prep" title="Before you start"}
:::

- [ ] Eggs out of the fridge
- [ ] A bowl for eggs and potato
- [ ] A plate wider than the pan
:::
:::callout{type="column" title="Method"}
1. Peel and thinly slice the potatoes, cut the onion into fine strips and salt them.
2. Poach them in the oil over a medium heat, in a 24 cm pan, until tender but pale: about 20 minutes.
3. Drain, keeping the oil, and stir the hot potato into the eggs, beaten with salt. Leave for 10 minutes.
4. Heat a spoonful of the oil over a high heat, pour in the mixture and let it set for 2 minutes, loosening the edges.
5. Turn it over with a plate, let it set a minute more and serve it warm.
:::
:::
:::

**Keep the oil.** Strained into a jar, it will fry the next tortilla.

# Gazpacho \\ andaluz {style="receta" art="gazpacho" kicker="Andalusian cold soup" time="25 min + 2 h chilling" level="Easy" season="June to September" note="serve it ice cold!" lead="In many Andalusian homes it is drunk from a glass, straight from the fridge. It needs truly ripe tomatoes, and oil poured in a thin stream while the blender runs, which leaves it creamy and orange."}

:::callout{type="card" label="SERVES 6"}
:::columns{count=2}
:::callout{type="column" title="Ingredients"}
- **1.5 kg** ripe plum tomatoes
- **1** long green pepper
- **1** cucumber
- **1** garlic clove
- **100 g** day-old bread, soaked in water
- **120 ml** extra virgin olive oil
- **3 tbsp** sherry vinegar
- Salt and cold water

:chip[Vegan]{style="tag"} :chip[No-cook]{style="tag"} :chip[Make ahead]{style="tag"}
:::
:::callout{type="column" title="Method"}
1. Chop the tomatoes, seeded pepper, peeled cucumber and garlic.
2. Put it all in the blender with the soaked bread, the vinegar and a teaspoon of salt; leave for 15 minutes.
3. Blend on full power for 2 minutes, then, with the motor running, add the oil in a thin stream until it emulsifies.
4. Press it through a fine sieve and thin it with cold water to taste.
5. Season with salt and vinegar and chill for at least 2 hours before serving.
:::
:::
:::

**Make it ahead.** It keeps two days in a covered jug in the fridge; stir it before you pour.

:::paragraphs{style="colophon"}
*Salt & Olive Oil* · Set in Young Serif, Figtree and Caveat (SIL OFL) · Recipes: original, CC BY 4.0 · Photos: generated
:::
`; // content.<lang>.md, inlined by the Cookbook

// #region art: the note's arrow and the pictograms, drawn in the palette's colours
// The dishes are photographs, JPEGs in assets/ cut to the band's 190 × 104 mm. The arrow from
// the handwritten note to the dish and the line pictograms stay vector; the note itself is a
// design element set in Caveat.
const n = (v) => +v.toFixed(2);
const svgDoc = (w, h, body) => `<svg xmlns="http://www.w3.org/2000/svg" width="${w * 10}" `
  + `height="${h * 10}" viewBox="0 0 ${w} ${h}">${body}</svg>`;
const circle = (x, y, r, fill, extra = '') => `<circle cx="${n(x)}" cy="${n(y)}" r="${n(r)}" `
  + `fill="${fill}"${extra}/>`;
const path = (d, fill, extra = '') => `<path d="${d}" fill="${fill}"${extra}/>`;
const stroke = (d, color, width, extra = '') => path(d, 'none', ` stroke="${color}" `
  + `stroke-width="${width}" stroke-linecap="round" stroke-linejoin="round"${extra}`);
const group = (x, y, turn, body) => `<g transform="translate(${n(x)} ${n(y)}) `
  + `rotate(${n(turn)})">${body}</g>`;
// A hand-drawn line and its head, as paths, never a <marker>, in a box as large as the photo:
// it runs from the end of the note, over the plate's rim, to the edge of the dish.
const arrow = svgDoc(PAGE.w, BAND, stroke('M90 29C97 26 102 28 106 33', palette.ink, 0.55)
  + group(106, 33, 62, stroke('M-2.4-1.3L0 0-2.4 1.5', palette.ink, 0.55)));
const cutlery = svgDoc(6, 8, stroke('M1.6 .6V7.4M.6 .6V2.6C.6 3.4 2.6 3.4 2.6 2.6V.6',
  palette.tomato, 0.55) + stroke('M4.6 7.4V.6C5.8 1.4 5.8 3.6 4.6 4.4', palette.tomato, 0.55));
// The kit in line drawings: a bowl with two eggs, the frying pan and the plate that turns the
// tortilla over, in a box KIT times as wide as it is tall.
const egg = (x, turn) => `<ellipse cx="${x}" cy="2.5" rx="1.05" ry="1.35" `
  + `transform="rotate(${turn} ${x} 2.5)" fill="none" stroke="${palette.olive}" `
  + 'stroke-width=".6"/>';
const kit = svgDoc(8 * KIT, 8, egg(3, -12) + egg(5, 14)
  + stroke('M.6 3.9H7.4M1 3.9C1 6.4 2.4 7.4 4 7.4S7 6.4 7 3.9', palette.olive, 0.7)
  + stroke('M9.8 4.4H16.8M10.2 4.4L10.8 6.7C10.9 7.1 11.2 7.3 11.6 7.3H15C15.4 7.3 15.7 7.1 '
    + '15.8 6.7L16.4 4.4', palette.olive, 0.7) + stroke('M16.8 5L20.2 4.1', palette.olive, 1.1)
  + circle(26.2, 4.2, 3.3, 'none', ` stroke="${palette.olive}" stroke-width=".7"`)
  + circle(26.2, 4.2, 2, 'none', ` stroke="${palette.olive}" stroke-width=".5"`));
// #endregion

// ─── 3 · Fonts ──────────────────────────────────────────────────────────────
// Every face the design uses. Layout measures with the browser's fonts, so the
// kit loads them from Fontsource before the first build.
const FONTS = { Figtree: ['400', '400i', '600', '700'], 'Young Serif': ['400'], Caveat: ['600'] };

// ─── 4 · Build & show ───────────────────────────────────────────────────────
// #region pictures: the photos and the pictograms are resources, cited by id, never by :ref
// The opener's image elements and both icons name a resource id; the resource names the file
// the canvas paints (loadImage or loadSvg registers it). No :ref cites them, so none is numbered.
const photo = (id, altText) => ({ id, typeId: 'figure', kind: 'bitmap', createdAt: 0, updatedAt: 0,
  altText, bitmap: { fileId: `${id}-1520.jpg`, format: 'jpeg', width: 1520, height: 832 } });
const ART = { // markup, width and height in mm, and the alt text
  arrow: [arrow, PAGE.w, BAND, t({ en: 'An arrow to the dish', es: 'Una flecha al plato' })],
  cutlery: [cutlery, 6, 8, t({ en: 'Fork and knife', es: 'Tenedor y cuchillo' })],
  kit: [kit, 8 * KIT, 8, t({ en: 'A bowl with two eggs, a frying pan and a plate',
    es: 'Un bol con dos huevos, una sartén y un plato' })] };
const resources = [
  photo('tortilla', t({ en: 'A potato omelette with a slice pulled out, on a blue-rimmed plate '
    + 'and a red-checked napkin', es: 'Una tortilla de patatas con una porción separada, en un '
    + 'plato de borde azul sobre una servilleta de cuadros rojos' })),
  photo('gazpacho', t({ en: 'A bowl of gazpacho with diced vegetables and a spoon, on a '
    + 'blue-checked napkin beside a tomato', es: 'Un cuenco de gazpacho con dados de verdura '
    + 'y una cuchara, sobre una servilleta de cuadros azules junto a un tomate' })),
  ...Object.entries(ART).map(([id, [, w, h, altText]]) => ({ id, typeId: 'figure',
    kind: 'svg', createdAt: 0, updatedAt: 0, altText, svg: { fileId: `${id}.svg`, width: w * 10,
      height: h * 10 } })), // 10 px a millimetre: the sizes only set the aspect ratio here
];
const photos = resources.filter((r) => r.kind === 'bitmap').map((r) => r.bitmap.fileId);
await Promise.all([...photos.map((file) => loadImage(file, asset(file))),
  ...Object.entries(ART).map(([id, [svg]]) => loadSvg(`${id}.svg`, svg))]);
// #endregion
// The excerpt is pages 58 and 59 of the book: 57 pages come before it, so the tortilla opens
// on a verso and the two recipes face each other.
const doc = await buildDocumentWithFonts({ markdown, resources,
  continuation: { pageIndexOffset: 57, pageNumbering: { startAt: 58 } } }, config(),
  kitFonts(FONTS));
showPages(doc, { title: t({ en: 'Recipe card', es: 'Tarjeta de receta' }) });

Kit · core, fonts, viewer, images : identique dans toutes les recettes · 270 lignes
// ─── Kit ── helpers shared by every Cookbook recipe · postext.dev/cookbook ─────

// ─── Kit · core v1 ── the same in every recipe · postext.dev/cookbook
function mm(value) { return { value, unit: 'mm' }; }
function pt(value) { return { value, unit: 'pt' }; }
function em(value) { return { value, unit: 'em' }; }
/** The sample language's string: t({ en: 'Figure', es: 'Figura' }). */
function t(strings) { return strings[LANG] ?? Object.values(strings)[0]; }
/** A file in this recipe's assets folder, served from the Postext repo by jsDelivr. */
function asset(file) { return `https://cdn.jsdelivr.net/gh/drnachio/postext@main/cookbook/${RECIPE}/assets/${file}`; }

// ─── Kit · fonts v3 ── the same in every recipe · postext.dev/cookbook
// Postext loads the faces a config asks for before layout (prepareFonts,
// buildDocumentWithFonts) and asks the kit for the files: Fontsource's, the
// files the PDF embeds too.

/** The options of buildDocumentWithFonts / prepareFonts / withLoadedFonts:
 *  the Fontsource resolver, and the faces of FONTS loaded with the ones the
 *  config names. FONTS = { 'Family Name': ['400', '400i', '700'] }. */
function kitFonts(FONTS = {}) {
  const faces = Object.entries(FONTS).flatMap(([family, specs]) => specs.map((spec) =>
    ({ family, weight: parseInt(spec, 10), style: spec.endsWith('i') ? 'italic' : 'normal' })));
  return { resolve: fontsourceResolver, faces };
}

/** A face's Fontsource files, in a fixed order: latin, then latin-ext and greek
 *  when `text` needs them and the family ships them (kitSubsetsFor), each with
 *  its unicode-range. Null for a weight or slant Fontsource does not ship. */
async function fontsourceResolver(family, weight, style, { text = '' } = {}) {
  const id = fontsourceId(family);
  const meta = await fontsourceMeta(family);
  if (meta && !(meta.weights.includes(weight) && meta.styles.includes(style))) return null;
  kitStatus('Loading fonts…');
  const at = await fontsourceAt(id);
  return ['latin', ...kitSubsetsFor(text, meta)].map((subset) => ({
    source: `${at}files/${id}-${subset}-${weight}-${style}.woff2`,
    unicodeRange: kitRanges()[subset],
  }));
}

/** The unicode-range of each Fontsource file the kit loads (a function: the
 *  kit is inlined after the pen's code, which runs before a const would be set). */
function kitRanges() {
  return {
    latin: 'U+0000-00FF,U+0131,U+0152-0153,U+02BB-02BC,U+02C6,U+02DA,U+02DC,U+0304,U+0308,U+0329,'
      + 'U+2000-206F,U+20AC,U+2122,U+2191,U+2193,U+2212,U+2215,U+FEFF,U+FFFD',
    'latin-ext': 'U+0100-02BA,U+02BD-02C5,U+02C7-02CC,U+02CE-02D7,U+02DD-02FF,U+0304,U+0308,U+0329,'
      + 'U+1D00-1DBF,U+1E00-1E9F,U+1EF2-1EFF,U+2020,U+20A0-20AB,U+20AD-20C0,U+2113,U+2C60-2C7F,U+A720-A7FF',
    greek: 'U+0370-03FF',
  };
}

/** For the cjk, arabic and comics blocks, which add their own files: the
 *  faces of `faces` = { 'Family Name': ['400', '400i', '700'] }. `text` is the sample:
 *  č ł † α χ also load latin-ext and greek files (kitSubsetsFor). With
 *  `optional`, a face Fontsource does not ship is skipped instead of failing.
 *  The files are added once all have loaded, in the order asked (latin, then
 *  latin-ext, then greek), whatever order they arrive in: the last one added
 *  wins a character two files hold. Resolves to the number of faces added. */
async function loadFonts(faces, text = '', { optional = false } = {}) {
  kitStatus('Loading fonts…');
  const ranges = kitRanges();
  const jobs = [];
  for (const [family, specs] of Object.entries(faces)) {
    const id = fontsourceId(family);
    const todo = [...new Set(specs)].map((spec) => [parseInt(spec, 10), spec.endsWith('i') ? 'italic' : 'normal'])
      .filter(([weight, style]) => !hasFace(family, weight, style)); // before any await
    const at = fontsourceAt(id);
    const meta = optional || /[^\0-ÿ]/u.test(text) ? await fontsourceMeta(family) : null;
    const subsets = ['latin', ...kitSubsetsFor(text, meta)];
    for (const [weight, style] of todo) {
      if (optional && !(meta?.weights.includes(weight) && meta.styles.includes(style))) continue;
      for (const subset of subsets) {
        const url = `${await at}files/${id}-${subset}-${weight}-${style}.woff2`;
        const face = new FontFace(family, `url(${url}) format('woff2')`,
          { weight: String(weight), style, unicodeRange: ranges[subset] });
        jobs.push(face.load().catch(() => {
          if (subset === 'latin' && !optional) throw new Error(`Fontsource has no ${family} ${weight} ${style}`);
        }));
      }
    }
  }
  const ready = await Promise.all(jobs).catch((error) => { kitFail(error); throw error; });
  return ready.filter((face) => face && document.fonts.add(face)).length;
}

/** A loaded FontFace covers this family, weight and style (fonts.check() would
 *  also say yes for families nobody declared). */
function hasFace(family, weight, style) {
  for (const face of document.fonts) {
    if (face.status !== 'loaded' || face.style !== style) continue;
    if (face.family.replace(/^["']|["']$/g, '') !== family) continue;
    const [low, high = low] = face.weight.split(' ').map(Number);
    if (weight >= low && weight <= high) return true;
  }
  return false;
}

/** The files beyond latin `text` needs that `meta`'s family ships. */
function kitSubsetsFor(text, meta) {
  return [[/[Ā-˿ᴀ-ᶿḀ-ỿ†ℓⱠ-Ɀ꜠-ꟿ]/u, 'latin-ext'], [/[Ͱ-Ͽ]/u, 'greek']]
    .filter(([re, x]) => re.test(text) && meta?.subsets?.includes(x)).map(([, x]) => x);
}

/** Fontsource's id for a family: 'Source Serif 4' → 'source-serif-4'. */
function fontsourceId(family) { return family.toLowerCase().replace(/\s+/g, '-'); }

/** A package's folder at the one version @5 names now (#766). */
function fontsourceAt(id, u = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@`) {
  return (fontsourceAt.c ??= {})[id] ??= fetch(u + '5/package.json').then((r) => r.json())
    .then((p) => p.version || 5, () => 5).then((v) => `${u}${v}/`);
}

/** The family's Fontsource metadata (weights, styles, subsets), or null. */
function fontsourceMeta(family) {
  fontsourceMeta.cache ??= new Map();
  const id = fontsourceId(family);
  if (!fontsourceMeta.cache.has(id)) {
    fontsourceMeta.cache.set(id, fetch(`https://api.fontsource.org/v1/fonts/${id}`)
      .then((res) => (res.ok ? res.json() : null), () => null));
  }
  return fontsourceMeta.cache.get(id);
}

// ─── Kit · viewer v2 ── the same in every recipe · postext.dev/cookbook
/** The pages as spreads on a dark desk, page 1 alone, then verso | recto,
 *  each painted when it scrolls near. Other options go to renderPageToCanvas. */
function showPages(docs, { title, width = 460, ...render } = {}) {
  const root = viewer(title);
  const pages = [docs].flat().flatMap((doc) =>
    doc.pages.map((page) => ({ doc, page, n: (doc.pageIndexOffset ?? 0) + page.index })));
  const spreads = [];
  let verso = null;
  for (const p of pages) {
    if (p.n % 2 === 1) { if (verso) spreads.push([verso, null]); verso = p; }
    else { spreads.push([verso, p]); verso = null; }
  }
  if (verso) spreads.push([verso, null]);
  const density = Math.min(window.devicePixelRatio || 1, 2);
  showPages.painter?.disconnect();
  const painter = new IntersectionObserver((entries) => {
    for (const { isIntersecting, target } of entries) {
      if (!isIntersecting) continue;
      painter.unobserve(target);
      const { doc, page } = target.postext;
      renderPageToCanvas(page, doc, target, { ...render, scale: (width * density) / page.width });
    }
  }, { rootMargin: '800px' });
  showPages.painter = painter;
  root.replaceChildren(...spreads.map((pair) => {
    const spread = document.createElement('div');
    spread.className = 'pt-spread';
    for (const p of pair) {
      const figure = document.createElement('figure');
      if (p) {
        const label = p.page.pageLabel || String(p.n + 1);
        const canvas = document.createElement('canvas');
        canvas.postext = p;
        canvas.style.aspectRatio = `${p.page.width} / ${p.page.height}`;
        canvas.setAttribute('role', 'img');
        canvas.setAttribute('aria-label', `Page ${label}`);
        const folio = document.createElement('figcaption');
        folio.textContent = label;
        figure.append(canvas, folio);
        painter.observe(canvas);
      } else figure.className = 'pt-blank';
      spread.append(figure);
    }
    return spread;
  }));
  kitStatus(`${pages.length} ${pages.length === 1 ? 'page' : 'pages'}`);
  document.documentElement.dataset.postext = 'ready';
  return pages.length;
}

/** The desk, the bar and the error reporting, created once. */
function viewer(title) {
  if (!document.getElementById('pt-kit')) {
    document.head.insertAdjacentHTML('beforeend', `<style id="pt-kit">
      :root { color-scheme: dark; }
      body { margin: 0; background: #0e1014; color: #b9bcc4; font: 13px/1.45 system-ui, sans-serif; }
      #pt-bar { position: sticky; top: 0; z-index: 1; display: flex; flex-wrap: wrap; align-items: center;
        gap: 6px 16px; padding: 10px 16px; background: rgb(14 16 20 / .92); backdrop-filter: blur(6px);
        border-bottom: 1px solid #23262d; }
      #pt-bar strong { color: #f4f1ea; font-weight: 600; }
      #pt-actions { display: flex; gap: 12px; margin-left: auto; }
      #pt-actions a, #pt-actions button { color: #d8a21a; font: inherit; background: none; border: 0; padding: 0; cursor: pointer; }
      #pages { display: grid; justify-items: center; gap: 48px; padding: 32px 16px 72px; }
      .pt-spread { display: flex; }
      .pt-spread figure { margin: 0; width: min(460px, 44vw); }
      .pt-spread canvas { display: block; width: 100%; background: #fff;
        box-shadow: 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figure:first-child canvas { box-shadow: inset -14px 0 14px -14px rgb(0 0 0 / .18), 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figcaption { margin-top: 10px; text-align: center; font: 600 10px/1 system-ui, sans-serif;
        letter-spacing: .18em; text-transform: uppercase; color: #6c7079; }
      .pt-blank { visibility: hidden; }
      @media (max-width: 760px) {
        .pt-spread { flex-direction: column; gap: 32px; }
        .pt-spread figure { width: min(460px, 92vw); }
        .pt-blank { display: none; }
      }
    </style>`);
    document.body.insertAdjacentHTML('afterbegin',
      '<header id="pt-bar"><strong id="pt-title"></strong><span id="pt-status" role="status"></span><span id="pt-actions"></span></header>');
    document.getElementById('pt-title').textContent = document.title || 'Postext';
    addEventListener('error', (event) => kitFail(event.error ?? event.message));
    addEventListener('unhandledrejection', (event) => kitFail(event.reason));
  }
  if (title) document.getElementById('pt-title').textContent = title;
  return document.getElementById('pages')
    ?? document.body.appendChild(Object.assign(document.createElement('main'), { id: 'pages' }));
}

function kitStatus(text) {
  viewer();
  document.getElementById('pt-status').textContent = text;
}

function kitFail(error) {
  document.documentElement.dataset.postext = 'error';
  kitStatus(`Error: ${error?.message ?? error}`);
}

// ─── Kit · images v3 ── recipes with pictures · postext.dev/cookbook
/** Registers a photo or PNG for the canvas and keeps its bytes for the PDF.
 *  fetch → ImageBitmap never taints the canvas (a plain cross-origin <img> would). */
async function loadImage(fileId, url) {
  const res = await fetch(url);
  if (!res.ok) throw new Error(`Image not found (${res.status}): ${url}`);
  const bytes = new Uint8Array(await res.arrayBuffer());
  registerResourceImage(fileId, await createImageBitmap(new Blob([bytes])));
  (loadImage.bytes ??= new Map()).set(fileId, bytes);
}

/** Registers SVG markup as a vector image, its fonts inside (inlineSvgFonts, ≥ 1.25).
 *  `options` go to registerResourceImage: { singleInk: true } tints it on the canvas. */
async function loadSvg(fileId, svg, options) {
  if (typeof inlineSvgFonts === 'function') svg = await inlineSvgFonts(svg, svgFaces);
  const img = new Image();
  await img.decode();
  registerResourceImage(fileId, img, options);
  (loadImage.bytes ??= new Map()).set(fileId, new TextEncoder().encode(svg));
}

/** A face's Fontsource files: nearest weight; latin + what the SVG sets. */
async function svgFaces(family, weight, style, { codePoints = [] } = {}) {
  const [id, m] = [fontsourceId(family), await fontsourceMeta(family)];
  const w = m?.weights.reduce((a, b) => (Math.abs(b - weight) < Math.abs(a - weight) ? b : a)) ?? weight;
  const s = m?.styles.includes(style) === false ? 'normal' : style;
  return Promise.all(['latin', ...kitSubsetsFor(String.fromCodePoint(...codePoints), m)].map(async (x) => new Uint8Array(
    await (await fetch(`${await fontsourceAt(id)}files/${id}-${x}-${w}-${s}.woff2`)).arrayBuffer())));
}

/** renderToPdf({ resourceBytes: imageBytes }) */
function imageBytes(fileId) { return loadImage.bytes?.get(fileId); }

/** renderToHtml({ resourceImageUrl: imageUrl }) */
function imageUrl(fileId) {
  const bytes = imageBytes(fileId);
  if (!bytes) return undefined;
  imageUrl.urls ??= new Map();
  if (!imageUrl.urls.has(fileId)) {
    const type = /\.svg$/i.test(fileId) ? 'image/svg+xml' : /\.png$/i.test(fileId) ? 'image/png' : 'image/jpeg';
    imageUrl.urls.set(fileId, URL.createObjectURL(new Blob([bytes], { type })));
  }
  return imageUrl.urls.get(fileId);
}

// ─── /Kit ───────────────────────────────────────────────────────────────────────
