Fiche d’exercices avec cases réponse et banque de mots

// ═══ Postext Cookbook · Nº 022 · Worksheet with answer boxes and a word bank ══════
// https://postext.dev/en/cookbook/worksheet-answer-boxes
// Code: MIT · Text: original (CC BY 4.0) · Plant: diffusion models · Icons: drawn in code
// Fonts: Andika, Baloo 2, Fredoka (SIL OFL 1.1) · Needs postext ≥ 1.25.0
import {
  buildDocumentWithFonts, prepareFonts, renderPageToCanvas, registerResourceImage,
} from 'https://esm.sh/postext';

const LANG = 'en'; // @lang: the language of the sample document ('en' | 'es')
const RECIPE = 'worksheet-answer-boxes';

// ─── 1 · Design ─────────────────────────────────────────────────────────────
const palette = { ink: '#243040', muted: '#5d6975', paper: '#ffffff', // type; prompts; boxes
  leaf: '#2f7d4a', sun: '#f4b43a', soil: '#8a5a36', // the accent; words to pick; drawings
  tint: '#e5f1e7', rule: '#a9c9b1' }; // the activity cards; answer-box outlines
// Each colour names its palette entry and carries its hex.
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
// The engine's defaults link to 'main-color': point it at the leaf, so nothing prints blue.
const colorPalette = Object.entries({ ...palette, 'main-color': palette.leaf })
  .map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } }));
const [TEXT, DISPLAY, LABEL] = ['Andika', 'Baloo 2', 'Fredoka']; // Andika: for early readers
const [TOP, SIDE] = [18, 16]; // mm; a sheet printed one-sided, so the margins do not mirror

// #region answer: cards that hold white answer boxes, stacked exactly, off the grid
// In the Markdown a box inside a box is a fence inside a fence (each ::: closes one):
//   :::callout{type="card"}
//   What is inside the pea pods?
//   :::callout{type="answer"}
//   Write here               ← the prompt first: a :::space that opens a box is dropped
//   :::space{lines=3}           (gotcha: space-dropped-box-top)
//   :::
//   :::
const [ASK, AFTER, HEAD, NEXT] = [2, 5, 3, 9]; // mm: question→box, box→next, heading→card
const card = {
  id: 'card', background: col('tint'), borderRadius: mm(4),
  padding: { top: mm(4), right: mm(5), bottom: mm(5), left: mm(5) },
  marginTop: mm(HEAD), marginBottom: mm(NEXT), // NEXT: under a card, to whatever follows
  // Off the grid, or what follows a card drops to the next grid line. Only the outer card can
  // set it: a nested box ignores snapToGrid, span and placement (gotcha: nested-callout-limits).
  snapToGrid: false,
  body: { paragraphSpacing: false }, // the boxes' margins do all the spacing
  lists: { bulletChar: '', // no bullet: in the checklist a circle chip opens each item
    gap: mm(2), itemSpacing: pt(7) }, columnGap: mm(6),
};
// A nested box's margins collapse with its neighbours', the larger winning (ASK, AFTER); the
// last box's marginBottom falls inside the card's padding instead of adding to it.
const nested = (id, look) => ({ id, background: col('paper'), borderRadius: mm(2.5),
  marginTop: mm(ASK), marginBottom: mm(AFTER), ...look });
const answer = nested('answer', { border: { enabled: true, color: col('rule'), width: pt(0.75) },
  padding: { top: mm(1.6), right: mm(3), bottom: mm(2), left: mm(3) },
  // A small grey prompt on a full 17 pt line; :::space counts in these body lines.
  body: { fontFamily: LABEL, fontSize: pt(8), color: col('muted') } });
const bank = nested('bank', { title: t({ en: 'Word bank', es: 'Banco de palabras' }),
  padding: { top: mm(2.2), right: mm(3), bottom: mm(2.4), left: mm(3) },
  titleStyle: { fontFamily: LABEL, fontSize: pt(7.5), fontWeight: 600, color: col('leaf'),
    textTransform: 'uppercase', letterSpacing: pt(1.3), gap: mm(1.6) } });
// config() plugs in all three: calloutStyles: [card, answer, bank].
// #endregion

// #region chips: words to pick, blanks to fill, dots to join, circles to colour
const chip = (id, fill, look) => ({ id, fontFamily: LABEL, background: col(fill),
  borderWidth: pt(0), borderColor: col('leaf'), borderRadius: em(1), ...look });
// An empty chip, :chip[ ], is a box of padding and outline alone. It is a band 1.25 em tall,
// so paddingX ROUND makes it a circle.
const [ROUND, OUTLINE] = [em(0.625), pt(0.9)];
// A blank is all padding, 2 × paddingX wide and 19.6 pt tall: taller than the 17 pt line, so
// the card's itemSpacing sets its items 24 pt apart (gotcha: chip-overlap).
const blank = (id, width) => chip(id, 'paper', { borderWidth: OUTLINE, borderRadius: mm(1.4),
  paddingX: mm(width / 2), paddingY: em(0.12), fontSize: em(1.15) });
const chipStyles = [
  chip('word', 'sun', { bold: true, paddingX: em(0.6), paddingY: em(0.08), gap: em(0.45) }),
  blank('blank', 34), blank('wide', 38), // mm: in a sentence; alone in a column
  chip('dot', 'leaf', { paddingX: ROUND, fontSize: em(0.6) }),
  chip('tick', 'paper', { borderWidth: OUTLINE, paddingX: ROUND, fontSize: em(1.1), gap: em(0.5) }),
];
// #endregion

// #region activity: an in-column H2 design: the automatic number in a green disc
const DISC_H2 = 8.6; // mm: the disc and the title are this tall, so the heading reserves this
const numberDisc = { kind: 'text', id: 'num', content: '{number}', // numberingTemplate '{2}'
  fontFamily: DISPLAY, fontSize: pt(15), fontWeight: 800, color: col('paper'),
  box: { backgroundColor: col('leaf'), borderRadius: mm(DISC_H2 / 2) }, // centred both ways
  placement: { anchor: { to: 'container', edge: 'top-left' },
    size: { width: mm(DISC_H2), height: mm(DISC_H2) } } };
const activityTitle = { kind: 'text', id: 'title', content: '{titleText}',
  fontFamily: DISPLAY, fontSize: pt(17), fontWeight: 700, color: col('ink'), align: 'left',
  overflow: 'wrap', placement: { anchor: { to: '#num', edge: 'right-of' },
    offset: { x: mm(3) }, size: { width: mm(140), height: mm(DISC_H2) } } };
const activity = { enabled: true, slot: { elements: [numberDisc, activityTitle] } };
// ## How did I do? {style="review"} is not an activity: it has no number and a star for a disc.
const review = { id: 'review', numbered: false, advancedDesign: { ...activity, slot: {
  elements: [{ kind: 'image', id: 'num', resourceId: 'star', placement: numberDisc.placement },
    activityTitle] } } };
// #endregion

const [BAND, AIR, DOT] = [76, 5, 6]; // mm: the opener's band, air under the disc, dot size
const DISC = { x: 108, y: 5, d: 78 }; // mm: the plant's disc on the page
const EDGE = BAND - DISC.y; // mm down the disc: the band's edge, where its two pictures meet
const at = (x, y, size, edge = 'top-left') => ({ anchor: { to: 'page', edge },
  offset: { x: mm(x), y: mm(y) }, size });
const words = (id, content, family, size, weight, placement, extra) => ({ kind: 'text', id,
  content, fontFamily: family, fontSize: pt(size), fontWeight: weight, color: col('paper'),
  align: 'left', overflow: 'wrap', placement, ...extra });
const tag = { textTransform: 'uppercase', letterSpacing: pt(1.3) };
const dot = ([n, x, y]) => words(`dot${n}`, String(n), DISPLAY, 10.5, 800, at(DISC.x + x - DOT / 2,
  DISC.y + y - DOT / 2, { width: mm(DOT), height: mm(DOT) }), { color: col('ink'), align: 'center',
  box: { backgroundColor: col('sun'), borderRadius: mm(DOT / 2) } }); // a yellow disc per number
const field = (id, label, x, w) => [words(`${id}-label`, label, LABEL, 7.5, 600, at(x, 59), tag),
  { kind: 'box', id, style: { backgroundColor: col('paper'), borderRadius: mm(1.6) },
    placement: at(x, 63, { width: mm(w), height: mm(7.5) }) }]; // a label over a white field
// The opener reserves down to the disc's foot; minHeight adds AIR, 5 mm, under it.
const opener = () => ({ enabled: true, minHeight: mm(DISC.y + DISC.d + AIR - TOP),
  slot: { elements: [
    { kind: 'box', id: 'band', style: { backgroundColor: col('leaf') },
      placement: at(0, 0, { height: mm(BAND) }) },
    ...[['plant', 0, EDGE], ['plant-foot', EDGE, DISC.d - EDGE], ['leaders', 0, DISC.d]]
      .map(([id, y, h]) => ({ kind: 'image', id, resourceId: id, // the leaders last, on top
        placement: at(DISC.x, DISC.y + y, { width: mm(DISC.d), height: mm(h) }) })),
    ...LABELS.map(dot),
    words('unit', '{attr.unit}', LABEL, 9, 600, at(SIDE, TOP - 4), { ...tag, color: col('ink'),
      box: { backgroundColor: col('sun'), borderRadius: mm(3),
        padding: { top: mm(1), right: mm(2.6), bottom: mm(1), left: mm(2.6) } } }),
    words('title', '{titleText}', DISPLAY, 40, 800, at(SIDE, 23.5, { width: mm(88) }),
      { lineHeight: 0.98 }), // two lines: the headings break with \\
    words('series', '{title} · {subtitle} · {attr.sheet}', LABEL, 9.5, 500, at(SIDE, 53)),
    ...field('name', t({ en: 'Name', es: 'Nombre' }), SIDE, 58),
    ...field('date', t({ en: 'Date', es: 'Fecha' }), SIDE + 62, 22),
  ] } });

// #region tables: a rounded panel with a picture in each row and chips to join
const tableStyles = [{ id: 'match', borderRadius: mm(3), // no header row, so no header fill
  headerBackgroundEnabled: false, bodyBackgroundEnabled: true, bodyBackground: col('paper'),
  bodyFontFamily: LABEL, bodyFontSize: pt(13), bodyColor: col('ink'), cellPadding: mm(1.4),
  rules: 'none' }]; // the white panel is the body fill alone
const cell = (content, extra) => ({ content, verticalAlign: 'middle', ...extra });
const dotCell = () => cell(':chip[ ]{style="dot"}', { align: 'center' });
const matchRow = (icon, food, part) => [cell('', { image: { resourceId: icon, width: 0.76 },
  align: 'center' }), cell(food), dotCell(), cell(''), dotCell(),
cell(`:chip[${part}]{style="word"}`)];
const sheetType = { id: 'sheet', name: 'Worksheet item', shortLabel: '', captionPrefix: '',
  numberingTemplate: '{n}', resetOn: 'never', counterFormat: 'decimal' }; // no caption, no number
// Set 'here' in its card, built once FOODS exist. A box keeps a line of its text, 6 mm, over
// an embedded table; with that off (see layout), a :::space{lines=0.33} sets ASK instead.
const foods = () => ({ id: 'foods', typeId: 'sheet', kind: 'table', createdAt: 0, updatedAt: 0,
  placement: { position: 'here' }, table: { styleId: 'match', model: {
    columnWidths: [0.14, 0.25, 0.06, 0.31, 0.06, 0.18], // the widest gap: room to draw a line
    rows: FOODS.map((name, r) => matchRow(ICONS[r], name, PARTS[r])) } } });
// #endregion

const config = () => ({
  locale: t({ en: 'en-us', es: 'es' }), // the hyphenation patterns of the edition
  resourceTypes: [sheetType], colorPalette, chipStyles, tableStyles, header: { elements: [] },
  footer: { elements: [words('foot', '{title} · {subtitle} · {attr.unit} · {pageNumber}', LABEL,
    7.8, 600, at(SIDE, -11, undefined, 'bottom-left'), { ...tag, color: col('muted') })] },
  page: { width: mm(200), height: mm(260), dpi: 150, margins: { top: mm(TOP), bottom: mm(20),
    left: mm(SIDE), right: mm(SIDE) } },
  layout: { layoutType: 'single', inlineResourceGapInBoxes: false }, // ASK over the table
  bodyText: { fontFamily: TEXT, fontSize: pt(12), lineHeight: pt(17), color: col('ink'),
    boldColor: col('ink'), italicColor: col('ink'), referenceColor: col('ink'),
    textAlign: 'left', firstLineIndent: pt(0), paragraphSpacing: true },
  // #region grid: the headings leave the grid too, and nothing stretches the gaps
  headings: { fontFamily: DISPLAY, snapToGrid: false, // or what follows snaps back to the grid
    balancing: { enabled: false }, // no extra space above headings to fill out a page
    levels: [
      // parity 'any': a sheet opens the next page, on either side.
      { level: 1, span: 'page', breakBefore: { enabled: true, parity: 'any' },
        marginTop: pt(0), marginBottom: pt(0), advancedDesign: opener() },
      { level: 2, numberingTemplate: '{2}', marginTop: mm(0), marginBottom: mm(0),
        advancedDesign: activity },
    ] },
  // #endregion
  orderedLists: { fontFamily: DISPLAY, fontWeight: 800, marginTop: mm(ASK), // a bank's AFTER wins
    numberVerticalOffset: pt(1.7) }, // centred 0.3 em over the baseline, Baloo 2 sat high
  headingStyles: [review], calloutStyles: [card, answer, bank],
  paragraphStyles: [{ id: 'lead', fontSize: pt(14), lineHeight: pt(20) }, { id: 'colophon',
    fontFamily: LABEL, fontSize: pt(7.5), lineHeight: pt(10), color: col('muted') }],
});

// ─── 2 · Content ────────────────────────────────────────────────────────────
const markdown = String.raw`---
Exemple Markdown · 119 lignes · content.en.md
title: "Seedlings Science"
subtitle: "Year 4"
---

# Plants and \\ their parts {unit="Unit 3" sheet="Worksheet 3A"}

:::paragraphs{style="lead"}
Every part of a plant has a job to do. In this worksheet you will name the parts of a pea plant and find out what each one does and which ones we eat. You will need a pencil and some coloured pencils.
:::

## Look closely

:::callout{type="card"}
What is inside the pea pods on the plant at the top of the page?

:::callout{type="answer"}
Write here
:::space{lines=4}
:::

Which part of the plant grows under the ground? Why does the plant need it?

:::callout{type="answer"}
Write here
:::space{lines=6}
:::
:::

## Name the parts

:::callout{type="card"}
Six parts of the pea plant on page 1 have a number. Choose a word from the word bank and write it next to the same number.

:::callout{type="bank"}
:chip[stem]{style="word"} :chip[seeds]{style="word"} :chip[flower]{style="word"} :chip[roots]{style="word"} :chip[leaf]{style="word"} :chip[fruit]{style="word"}
:::

:::columns{count=3}
1. :chip[ ]{style="wide"}
2. :chip[ ]{style="wide"}
3. :chip[ ]{style="wide"}
4. :chip[ ]{style="wide"}
5. :chip[ ]{style="wide"}
6. :chip[ ]{style="wide"}
:::
:::

## What does each part do?

:::callout{type="card"}
Finish each sentence with a word from the word bank.

:::callout{type="bank"}
:chip[food]{style="word"} :chip[insects]{style="word"} :chip[water]{style="word"} :chip[plant]{style="word"} :chip[upright]{style="word"} :chip[seeds]{style="word"}
:::

1. The **roots** hold the plant in the soil and take in :chip[ ]{style="blank"}.
2. The **stem** keeps the plant :chip[ ]{style="blank"} and carries water to the leaves.
3. The **leaves** use sunlight to make :chip[ ]{style="blank"} for the plant.
4. The **flower** has bright petals that attract :chip[ ]{style="blank"} such as bees.
5. The **fruit** grows around the :chip[ ]{style="blank"} and keeps them safe.
6. A **seed** can grow into a new :chip[ ]{style="blank"}.
:::

**Did you know?** A pea plant cannot stand up on its own. It climbs by wrapping thin, curly tendrils around anything it touches.

## Parts we eat

:::callout{type="card"}
We eat many different plant parts. Draw a line from each food to the part of the plant it comes from.

:::space{lines=0.33}
::resource{id="foods"}
:::

## Draw and label

:::callout{type="card"}
Draw a plant you have seen at home or at school. Label at least four of its parts.

:::callout{type="answer"}
My plant is called
:::space{lines=7}
:::
:::

## Try it at home

:::callout{type="card"}
Put a dried pea on some wet cotton wool in a clear jar. Keep the cotton wool damp and look at the pea every day for a week. What do you think will come out of the pea first: a root or a shoot?

:::callout{type="answer"}
I think
:::space{lines=3}
:::

After a week, draw or write what you saw.

:::callout{type="answer"}
I saw
:::space{lines=6}
:::
:::

## How did I do? {style="review"}

:::callout{type="card"}
Colour a circle for each thing you can do.

- :chip[ ]{style="tick"} I can name the six parts of a plant.
- :chip[ ]{style="tick"} I can say what each part does.
- :chip[ ]{style="tick"} I can tell which part of a plant a food comes from.
:::

:::paragraphs{style="colophon"}
Seedlings Science is an invented series made for the Postext Cookbook. Text: CC BY 4.0. Plant: diffusion models.

Set in Andika, Baloo 2 and Fredoka (SIL Open Font License).
:::
`; // content.<lang>.md, inlined by the Cookbook

// The matching table's words. The parts are shuffled so that no food faces its own part.
const FOODS = t({ en: 'carrot|asparagus|lettuce|broccoli|orange|kidney beans',
  es: 'zanahoria|espárrago|lechuga|brócoli|naranja|alubias' }).split('|');
const PARTS = t({ en: 'leaf|seeds|root|fruit|stem|flower',
  es: 'hoja|semillas|raíz|fruto|tallo|flor' }).split('|');

// #region art: the plant's leader lines, the six foods and the star, in the palette's colours
// The pea plant is a watercolour already set in its disc, in two JPEGs that meet at the band's
// edge: the top one's corners carry the band's green, the foot's are white. One picture would
// resample its green-to-white step and print a pale line along the band's edge. No words in
// the drawings: the plant's numbers are design elements set in Baloo 2 over the picture (see
// the band).
// [number, x, y] in the disc's millimetres: each numbered dot, where its leader line starts.
const LABELS = [[1, 58, 8], [2, 68, 33], [3, 9, 44], [4, 13, 20], [5, 62, 52], [6, 18, 66]];
const n = (v) => +v.toFixed(2);
const svgDoc = (w, h, body, scale = 10) => `<svg xmlns="http://www.w3.org/2000/svg" `
  + `width="${w * scale}" height="${h * scale}" viewBox="0 0 ${w} ${h}">${body}</svg>`;
const circle = (x, y, r, fill, extra = '') => `<circle cx="${n(x)}" cy="${n(y)}" r="${n(r)}" `
  + `fill="${fill}"${extra}/>`;
const path = (d, fill, extra = '') => `<path d="${d}" fill="${fill}"${extra}/>`;
const stroke = (d, color, width) => path(d, 'none', ` stroke="${color}" stroke-width="${width}" `
  + 'stroke-linecap="round" stroke-linejoin="round"');
const leafShape = (x, y, len, wid, turn, fill) => `<g transform="translate(${n(x)} ${n(y)}) `
  + `rotate(${n(turn)})">${path(`M0 0C${n(len * 0.3)} ${n(-wid)} ${n(len * 0.8)} ${n(-wid)} `
  + `${n(len)} 0C${n(len * 0.8)} ${n(wid)} ${n(len * 0.3)} ${n(wid)} 0 0Z`, fill)}</g>`;
function leaders() { // from each dot to its part, in ink on a white halo that clears the soil
  // 1 a flower, 2 the closed pod's wall (the fruit), 3 a pea in the open pod (the seeds),
  // 4 a leaf's blade, 5 the stem between two leaves, 6 the taproot.
  const targets = { 1: [45.5, 11.5], 2: [50, 34], 3: [28.4, 33.2], 4: [34.6, 16.4],
    5: [38.8, 52], 6: [38.4, 64] };
  const lines = LABELS.map(([num, x, y]) => `M${x} ${y}L${targets[num].join(' ')}`).join('');
  return svgDoc(78, 78, stroke(lines, palette.paper, 0.9) + stroke(lines, palette.ink, 0.35)
    + Object.values(targets).map(([x, y]) => circle(x, y, 0.75, palette.ink,
      ` stroke="${palette.paper}" stroke-width=".3"`)).join(''));
}
function star() { // the self-check's badge: a white star on a sun disc
  const pts = Array.from({ length: 10 }, (_, i) => {
    const a = -Math.PI / 2 + (i * Math.PI) / 5;
    const rr = i % 2 ? 4.4 : 9.4;
    return `${n(12 + Math.cos(a) * rr)} ${n(12.6 + Math.sin(a) * rr)}`;
  });
  return svgDoc(24, 24, circle(12, 12, 12, palette.sun) + path(`M${pts.join('L')}Z`,
    palette.paper), 10);
}
const food = {
  carrot: () => path('M3.5 17.5C8 13 12 8.5 16.2 5.2C18 4 20.6 6.4 19.2 8.2C15.8 12.4 10 15.8 '
    + '3.5 17.5Z', palette.sun) + stroke('M8 13.6l1.4 1.2M11.6 10.6l1.3 1.3M14.6 8l1.2 1.2',
    palette.soil, 0.4) + [-120, -80, -40].map((a) => leafShape(18.4, 6.4, 6, 1.4, a,
    palette.leaf)).join(''),
  asparagus: () => [[10, 7], [12, 12], [14, 17]].map(([x0, x1]) => path(`M${x0 - 1.3} 19`
    + `L${x1 - 1} 5Q${x1} 1.4 ${x1 + 1} 5L${x0 + 1.3} 19Z`, palette.leaf) + stroke(`M${x1 - 0.8} `
    + `7.6l.8.8.8-.8M${(x0 + x1) / 2 - 0.9} 11.4l.9.9.9-.9`, palette.tint, 0.35)).join('')
    + path('M7.8 13.4h8.4v2.2H7.8Z', palette.sun),
  lettuce: () => { // a head seen from the side: two dark outer leaves cupping a pale heart
    const side = path('M13 19C6 19 2.6 15 3 9.6C3.2 7.4 4.6 6 5.8 7C6.2 5.4 7.8 4.8 8.6 6.2'
      + 'C9.4 5.2 10.6 5.6 10.6 6.8C9 10 9.4 15 13 19Z', palette.leaf)
      + stroke('M11 17.6C7.6 16 5.2 12.6 5.2 8.6', palette.tint, 0.4); // a frilled leaf, its vein
    return `<ellipse cx="12" cy="11.4" rx="5.8" ry="6.8" fill="${palette.rule}"/>`
      + stroke('M12 17.6C11.6 14 11.8 10 12.8 6', palette.tint, 0.45)
      + side + `<g transform="translate(24 0) scale(-1 1)">${side}</g>`;
  },
  broccoli: () => path('M10 19l1-7h2l1 7Z', palette.rule) + [[8, 9, 3.4], [12, 7, 3.8],
    [16, 9, 3.4], [10, 11.5, 2.6], [14, 11.5, 2.6]].map(([x, y, rr]) => circle(x, y, rr,
    palette.leaf)).join(''),
  orange: () => circle(12, 11.5, 7.5, palette.sun) + leafShape(12, 4.2, 5, 1.6, -30,
    palette.leaf) + circle(9, 9, 1.2, palette.paper, ' fill-opacity=".45"'),
  beans: () => [[7, 13, -20], [13, 9, 15], [16, 15, -35]].map(([x, y, a]) => `<g transform=`
    + `"translate(${x} ${y}) rotate(${a})">${path('M-4 0C-4 -3 -1 -3 0 -1.5C1 -3 4 -3 4 0'
    + 'C4 3 -4 3 -4 0Z', palette.soil)}</g>`).join(''),
};
const ICONS = Object.keys(food); // carrot … beans: the matching table's rows, in order
const drawings = { leaders, star,
  ...Object.fromEntries(Object.entries(food).map(([id, draw]) => [id, () => svgDoc(24, 20,
    draw())])) };
const ALT = { ...Object.fromEntries(ICONS.map((id, i) => [id, FOODS[i]])),
  plant: t({ en: 'A pea plant with its flower, pod, peas, leaf, stem and roots numbered 1 to 6',
    es: 'Una planta de guisante con la flor, la vaina, los guisantes, la hoja, el tallo y las '
      + 'raíces numerados del 1 al 6' }),
  leaders: '', star: t({ en: 'A white star on a yellow disc',
    es: 'Una estrella blanca en un disco amarillo' }) };
// Each picture is a resource that the opener, a table cell or the review heading names by
// id. None is cited, so none is placed as a figure. Drawings in px, 10 to the millimetre.
const pictures = Object.keys(drawings).map((id) => ({ id, typeId: 'sheet', kind: 'svg',
  altText: ALT[id], createdAt: 0, updatedAt: 0, svg: { fileId: `${id}.svg`,
    width: 240, height: 200,
    ...{ leaders: { width: 780, height: 780 }, star: { width: 240, height: 240 } }[id] } }));
// The plant's two slices, 14 px to the millimetre (356 dpi): 78 × 71 mm and 78 × 7 mm.
pictures.push(...[['plant', 994], ['plant-foot', 98]].map(([id, h]) => ({ id, typeId: 'sheet',
  kind: 'bitmap', altText: id === 'plant' ? ALT.plant : '', createdAt: 0, updatedAt: 0,
  bitmap: { fileId: `${id}-1092.jpg`, format: 'jpeg', width: 1092, height: h } })));
// #endregion

const resources = [...pictures, foods()];

// ─── 3 · Fonts ──────────────────────────────────────────────────────────────
const FONTS = { Andika: ['400', '700'], 'Baloo 2': ['700', '800'],
  Fredoka: ['400', '500', '600', '700'] };

// ─── 4 · Build & show ───────────────────────────────────────────────────────
await Promise.all([prepareFonts(markdown, config(), kitFonts(FONTS)),
  ...Object.entries(drawings).map(([id, draw]) => loadSvg(`${id}.svg`, draw())),
  ...['plant-1092.jpg', 'plant-foot-1092.jpg'].map((file) => loadImage(file, asset(file)))]);
const doc = await buildDocumentWithFonts({ markdown, resources }, config(), kitFonts(FONTS));
showPages(doc, { title: t({ en: 'Plants and their parts', es: 'Las plantas y sus partes' }) });

Kit · core, fonts, viewer, images : identique dans toutes les recettes · 270 lignes
// ─── Kit ── helpers shared by every Cookbook recipe · postext.dev/cookbook ─────

// ─── Kit · core v1 ── the same in every recipe · postext.dev/cookbook
function mm(value) { return { value, unit: 'mm' }; }
function pt(value) { return { value, unit: 'pt' }; }
function em(value) { return { value, unit: 'em' }; }
/** The sample language's string: t({ en: 'Figure', es: 'Figura' }). */
function t(strings) { return strings[LANG] ?? Object.values(strings)[0]; }
/** A file in this recipe's assets folder, served from the Postext repo by jsDelivr. */
function asset(file) { return `https://cdn.jsdelivr.net/gh/drnachio/postext@main/cookbook/${RECIPE}/assets/${file}`; }

// ─── Kit · fonts v3 ── the same in every recipe · postext.dev/cookbook
// Postext loads the faces a config asks for before layout (prepareFonts,
// buildDocumentWithFonts) and asks the kit for the files: Fontsource's, the
// files the PDF embeds too.

/** The options of buildDocumentWithFonts / prepareFonts / withLoadedFonts:
 *  the Fontsource resolver, and the faces of FONTS loaded with the ones the
 *  config names. FONTS = { 'Family Name': ['400', '400i', '700'] }. */
function kitFonts(FONTS = {}) {
  const faces = Object.entries(FONTS).flatMap(([family, specs]) => specs.map((spec) =>
    ({ family, weight: parseInt(spec, 10), style: spec.endsWith('i') ? 'italic' : 'normal' })));
  return { resolve: fontsourceResolver, faces };
}

/** A face's Fontsource files, in a fixed order: latin, then latin-ext and greek
 *  when `text` needs them and the family ships them (kitSubsetsFor), each with
 *  its unicode-range. Null for a weight or slant Fontsource does not ship. */
async function fontsourceResolver(family, weight, style, { text = '' } = {}) {
  const id = fontsourceId(family);
  const meta = await fontsourceMeta(family);
  if (meta && !(meta.weights.includes(weight) && meta.styles.includes(style))) return null;
  kitStatus('Loading fonts…');
  const at = await fontsourceAt(id);
  return ['latin', ...kitSubsetsFor(text, meta)].map((subset) => ({
    source: `${at}files/${id}-${subset}-${weight}-${style}.woff2`,
    unicodeRange: kitRanges()[subset],
  }));
}

/** The unicode-range of each Fontsource file the kit loads (a function: the
 *  kit is inlined after the pen's code, which runs before a const would be set). */
function kitRanges() {
  return {
    latin: 'U+0000-00FF,U+0131,U+0152-0153,U+02BB-02BC,U+02C6,U+02DA,U+02DC,U+0304,U+0308,U+0329,'
      + 'U+2000-206F,U+20AC,U+2122,U+2191,U+2193,U+2212,U+2215,U+FEFF,U+FFFD',
    'latin-ext': 'U+0100-02BA,U+02BD-02C5,U+02C7-02CC,U+02CE-02D7,U+02DD-02FF,U+0304,U+0308,U+0329,'
      + 'U+1D00-1DBF,U+1E00-1E9F,U+1EF2-1EFF,U+2020,U+20A0-20AB,U+20AD-20C0,U+2113,U+2C60-2C7F,U+A720-A7FF',
    greek: 'U+0370-03FF',
  };
}

/** For the cjk, arabic and comics blocks, which add their own files: the
 *  faces of `faces` = { 'Family Name': ['400', '400i', '700'] }. `text` is the sample:
 *  č ł † α χ also load latin-ext and greek files (kitSubsetsFor). With
 *  `optional`, a face Fontsource does not ship is skipped instead of failing.
 *  The files are added once all have loaded, in the order asked (latin, then
 *  latin-ext, then greek), whatever order they arrive in: the last one added
 *  wins a character two files hold. Resolves to the number of faces added. */
async function loadFonts(faces, text = '', { optional = false } = {}) {
  kitStatus('Loading fonts…');
  const ranges = kitRanges();
  const jobs = [];
  for (const [family, specs] of Object.entries(faces)) {
    const id = fontsourceId(family);
    const todo = [...new Set(specs)].map((spec) => [parseInt(spec, 10), spec.endsWith('i') ? 'italic' : 'normal'])
      .filter(([weight, style]) => !hasFace(family, weight, style)); // before any await
    const at = fontsourceAt(id);
    const meta = optional || /[^\0-ÿ]/u.test(text) ? await fontsourceMeta(family) : null;
    const subsets = ['latin', ...kitSubsetsFor(text, meta)];
    for (const [weight, style] of todo) {
      if (optional && !(meta?.weights.includes(weight) && meta.styles.includes(style))) continue;
      for (const subset of subsets) {
        const url = `${await at}files/${id}-${subset}-${weight}-${style}.woff2`;
        const face = new FontFace(family, `url(${url}) format('woff2')`,
          { weight: String(weight), style, unicodeRange: ranges[subset] });
        jobs.push(face.load().catch(() => {
          if (subset === 'latin' && !optional) throw new Error(`Fontsource has no ${family} ${weight} ${style}`);
        }));
      }
    }
  }
  const ready = await Promise.all(jobs).catch((error) => { kitFail(error); throw error; });
  return ready.filter((face) => face && document.fonts.add(face)).length;
}

/** A loaded FontFace covers this family, weight and style (fonts.check() would
 *  also say yes for families nobody declared). */
function hasFace(family, weight, style) {
  for (const face of document.fonts) {
    if (face.status !== 'loaded' || face.style !== style) continue;
    if (face.family.replace(/^["']|["']$/g, '') !== family) continue;
    const [low, high = low] = face.weight.split(' ').map(Number);
    if (weight >= low && weight <= high) return true;
  }
  return false;
}

/** The files beyond latin `text` needs that `meta`'s family ships. */
function kitSubsetsFor(text, meta) {
  return [[/[Ā-˿ᴀ-ᶿḀ-ỿ†ℓⱠ-Ɀ꜠-ꟿ]/u, 'latin-ext'], [/[Ͱ-Ͽ]/u, 'greek']]
    .filter(([re, x]) => re.test(text) && meta?.subsets?.includes(x)).map(([, x]) => x);
}

/** Fontsource's id for a family: 'Source Serif 4' → 'source-serif-4'. */
function fontsourceId(family) { return family.toLowerCase().replace(/\s+/g, '-'); }

/** A package's folder at the one version @5 names now (#766). */
function fontsourceAt(id, u = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@`) {
  return (fontsourceAt.c ??= {})[id] ??= fetch(u + '5/package.json').then((r) => r.json())
    .then((p) => p.version || 5, () => 5).then((v) => `${u}${v}/`);
}

/** The family's Fontsource metadata (weights, styles, subsets), or null. */
function fontsourceMeta(family) {
  fontsourceMeta.cache ??= new Map();
  const id = fontsourceId(family);
  if (!fontsourceMeta.cache.has(id)) {
    fontsourceMeta.cache.set(id, fetch(`https://api.fontsource.org/v1/fonts/${id}`)
      .then((res) => (res.ok ? res.json() : null), () => null));
  }
  return fontsourceMeta.cache.get(id);
}

// ─── Kit · viewer v2 ── the same in every recipe · postext.dev/cookbook
/** The pages as spreads on a dark desk, page 1 alone, then verso | recto,
 *  each painted when it scrolls near. Other options go to renderPageToCanvas. */
function showPages(docs, { title, width = 460, ...render } = {}) {
  const root = viewer(title);
  const pages = [docs].flat().flatMap((doc) =>
    doc.pages.map((page) => ({ doc, page, n: (doc.pageIndexOffset ?? 0) + page.index })));
  const spreads = [];
  let verso = null;
  for (const p of pages) {
    if (p.n % 2 === 1) { if (verso) spreads.push([verso, null]); verso = p; }
    else { spreads.push([verso, p]); verso = null; }
  }
  if (verso) spreads.push([verso, null]);
  const density = Math.min(window.devicePixelRatio || 1, 2);
  showPages.painter?.disconnect();
  const painter = new IntersectionObserver((entries) => {
    for (const { isIntersecting, target } of entries) {
      if (!isIntersecting) continue;
      painter.unobserve(target);
      const { doc, page } = target.postext;
      renderPageToCanvas(page, doc, target, { ...render, scale: (width * density) / page.width });
    }
  }, { rootMargin: '800px' });
  showPages.painter = painter;
  root.replaceChildren(...spreads.map((pair) => {
    const spread = document.createElement('div');
    spread.className = 'pt-spread';
    for (const p of pair) {
      const figure = document.createElement('figure');
      if (p) {
        const label = p.page.pageLabel || String(p.n + 1);
        const canvas = document.createElement('canvas');
        canvas.postext = p;
        canvas.style.aspectRatio = `${p.page.width} / ${p.page.height}`;
        canvas.setAttribute('role', 'img');
        canvas.setAttribute('aria-label', `Page ${label}`);
        const folio = document.createElement('figcaption');
        folio.textContent = label;
        figure.append(canvas, folio);
        painter.observe(canvas);
      } else figure.className = 'pt-blank';
      spread.append(figure);
    }
    return spread;
  }));
  kitStatus(`${pages.length} ${pages.length === 1 ? 'page' : 'pages'}`);
  document.documentElement.dataset.postext = 'ready';
  return pages.length;
}

/** The desk, the bar and the error reporting, created once. */
function viewer(title) {
  if (!document.getElementById('pt-kit')) {
    document.head.insertAdjacentHTML('beforeend', `<style id="pt-kit">
      :root { color-scheme: dark; }
      body { margin: 0; background: #0e1014; color: #b9bcc4; font: 13px/1.45 system-ui, sans-serif; }
      #pt-bar { position: sticky; top: 0; z-index: 1; display: flex; flex-wrap: wrap; align-items: center;
        gap: 6px 16px; padding: 10px 16px; background: rgb(14 16 20 / .92); backdrop-filter: blur(6px);
        border-bottom: 1px solid #23262d; }
      #pt-bar strong { color: #f4f1ea; font-weight: 600; }
      #pt-actions { display: flex; gap: 12px; margin-left: auto; }
      #pt-actions a, #pt-actions button { color: #d8a21a; font: inherit; background: none; border: 0; padding: 0; cursor: pointer; }
      #pages { display: grid; justify-items: center; gap: 48px; padding: 32px 16px 72px; }
      .pt-spread { display: flex; }
      .pt-spread figure { margin: 0; width: min(460px, 44vw); }
      .pt-spread canvas { display: block; width: 100%; background: #fff;
        box-shadow: 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figure:first-child canvas { box-shadow: inset -14px 0 14px -14px rgb(0 0 0 / .18), 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figcaption { margin-top: 10px; text-align: center; font: 600 10px/1 system-ui, sans-serif;
        letter-spacing: .18em; text-transform: uppercase; color: #6c7079; }
      .pt-blank { visibility: hidden; }
      @media (max-width: 760px) {
        .pt-spread { flex-direction: column; gap: 32px; }
        .pt-spread figure { width: min(460px, 92vw); }
        .pt-blank { display: none; }
      }
    </style>`);
    document.body.insertAdjacentHTML('afterbegin',
      '<header id="pt-bar"><strong id="pt-title"></strong><span id="pt-status" role="status"></span><span id="pt-actions"></span></header>');
    document.getElementById('pt-title').textContent = document.title || 'Postext';
    addEventListener('error', (event) => kitFail(event.error ?? event.message));
    addEventListener('unhandledrejection', (event) => kitFail(event.reason));
  }
  if (title) document.getElementById('pt-title').textContent = title;
  return document.getElementById('pages')
    ?? document.body.appendChild(Object.assign(document.createElement('main'), { id: 'pages' }));
}

function kitStatus(text) {
  viewer();
  document.getElementById('pt-status').textContent = text;
}

function kitFail(error) {
  document.documentElement.dataset.postext = 'error';
  kitStatus(`Error: ${error?.message ?? error}`);
}

// ─── Kit · images v3 ── recipes with pictures · postext.dev/cookbook
/** Registers a photo or PNG for the canvas and keeps its bytes for the PDF.
 *  fetch → ImageBitmap never taints the canvas (a plain cross-origin <img> would). */
async function loadImage(fileId, url) {
  const res = await fetch(url);
  if (!res.ok) throw new Error(`Image not found (${res.status}): ${url}`);
  const bytes = new Uint8Array(await res.arrayBuffer());
  registerResourceImage(fileId, await createImageBitmap(new Blob([bytes])));
  (loadImage.bytes ??= new Map()).set(fileId, bytes);
}

/** Registers SVG markup as a vector image, its fonts inside (inlineSvgFonts, ≥ 1.25).
 *  `options` go to registerResourceImage: { singleInk: true } tints it on the canvas. */
async function loadSvg(fileId, svg, options) {
  if (typeof inlineSvgFonts === 'function') svg = await inlineSvgFonts(svg, svgFaces);
  const img = new Image();
  await img.decode();
  registerResourceImage(fileId, img, options);
  (loadImage.bytes ??= new Map()).set(fileId, new TextEncoder().encode(svg));
}

/** A face's Fontsource files: nearest weight; latin + what the SVG sets. */
async function svgFaces(family, weight, style, { codePoints = [] } = {}) {
  const [id, m] = [fontsourceId(family), await fontsourceMeta(family)];
  const w = m?.weights.reduce((a, b) => (Math.abs(b - weight) < Math.abs(a - weight) ? b : a)) ?? weight;
  const s = m?.styles.includes(style) === false ? 'normal' : style;
  return Promise.all(['latin', ...kitSubsetsFor(String.fromCodePoint(...codePoints), m)].map(async (x) => new Uint8Array(
    await (await fetch(`${await fontsourceAt(id)}files/${id}-${x}-${w}-${s}.woff2`)).arrayBuffer())));
}

/** renderToPdf({ resourceBytes: imageBytes }) */
function imageBytes(fileId) { return loadImage.bytes?.get(fileId); }

/** renderToHtml({ resourceImageUrl: imageUrl }) */
function imageUrl(fileId) {
  const bytes = imageBytes(fileId);
  if (!bytes) return undefined;
  imageUrl.urls ??= new Map();
  if (!imageUrl.urls.has(fileId)) {
    const type = /\.svg$/i.test(fileId) ? 'image/svg+xml' : /\.png$/i.test(fileId) ? 'image/png' : 'image/jpeg';
    imageUrl.urls.set(fileId, URL.createObjectURL(new Blob([bytes], { type })));
  }
  return imageUrl.urls.get(fileId);
}

// ─── /Kit ───────────────────────────────────────────────────────────────────────
