What you'll build

Lecture I of Michael Faraday's The Chemical History of a Candle, set as a small reader's edition on a 156 × 234 mm page. The lecture opens on a field of soot with a lit candle standing on its lower edge, and the text runs in one justified column of Libre Bodoni. Where a book would put footnotes, small raised numbers in dark orange send the reader to the end of the lecture. The notes follow on a page of their own, under a band of soot with the candle snuffed out, in two ragged columns of 8.2 pt type with each bold number hanging in the indent. Three of the six are William Crookes's, from the 1908 impression of his 1861 edition; the other three are new and signed Ed. Both columns end on the same line, and the colophon closes the second.

This recipe answers

How do I do footnotes?
How do I set a bibliography or glossary (hanging indent, smaller type)?
How do I write superscripts, subscripts and chemical formulas without full maths?

The short answer

script.js · lines 29–56in full code

// Use: buildDocument({ markdown: endnotes(markdown) }, config()), with a 'note' paragraph style.
// [^label] in the text → **^n^**, numbered by first citation; bold, so it takes bodyText.boldColor.
// The [^label]: definitions (one line each) print where the first stood, a 'note' paragraph each:
// '**n** text', never '1. text', which would open a numbered list (gotcha: digit-period-list).
function endnotes(markdown, style = 'note') {
  const notes = new Map(); // label → text
  const HOLE = '\u0000'; // marks where a definition stood: the first becomes the notes
  const text = markdown.replace(/^\[\^([^\]\s]+)\]:[ \t]*(.+)\n?/gm,
    (_, label, note) => { notes.set(label, note.trim()); return HOLE; });
  const cited = []; // labels in order of first citation
  const number = (label) => {
    if (!notes.has(label)) throw new Error(`The note [^${label}] has no definition`);
    if (!cited.includes(label)) cited.push(label);
    return cited.indexOf(label) + 1;
  };
  // Markers side by side share one superscript, [^a][^b] → **^1,2^**, never 12 raised (note 12).
  // A word joiner (U+2060, no width) opens each one: after an italic, '*Royal George*' and the
  // bold's ** would make '***', which the parser reads as a bold run, and print the asterisks.
  const marked = text.replace(/(?:\[\^[^\]\s]+\])+/g, (run) => {
    const numbers = [...run.matchAll(/\[\^([^\]\s]+)\]/g)].map(([, label]) => number(label));
    return `⁠**^${numbers.join(',')}^**`;
  });
  const unused = [...notes.keys()].filter((label) => !cited.includes(label));
  if (unused.length) console.warn(`Notes never cited: ${unused.join(', ')}`);
  const entries = cited.map((label, i) => `**${i + 1}** ${notes.get(label)}`);
  const section = `:::paragraphs{style="${style}"}\n${entries.join('\n\n')}\n:::\n`;
  return marked.replace(HOLE, () => section).replaceAll(HOLE, ''); // () =>: '$&' stays text
}

Markdown footnotes become raised markers and a Notes section

Ingredients

Features: Superscripts and subscripts Bibliographies and glossaries Section geometry Heading styles Column balancing Column rule Paragraph styles Escapes and literal characters Bold, italic and their colours Citations that place figures Numbered captions Custom resource types Caption style Designed openers Pictures in page designs Heading attributes Running heads and folios Mirrored margins Semantic colour palette
Also uses: Full-width chapter band Paper colour Heads by page role Figures and tables as resources
Type: Libre Bodoni, Besley, Archivo Narrow (SIL OFL 1.1)
Assets: None: every picture is drawn in code
API: buildDocumentclearMeasurementCacheregisterResourceImagerenderPageToCanvas

Method

#1 · Turn footnotes into endnotes before the build

The preprocessor is the short answer above. Postext 1.4.1 does not lay out notes: what is not supported lists the [^1] marker, and the engine ignores PostextContent.notes, although the types accept it. A lone [^1] prints as typed, and two in one paragraph pair their carets as a superscript that raises all the text between them. So the pen rewrites the Markdown before it calls buildDocument. It numbers the markers in the order the text first cites them and sets all the definitions, in that order, where the first of them stands, under ## Notes. Each note starts with **1**, since 1. would open a numbered list. A word joiner (U+2060) opens each marker; without it, the ** of the marker after *Royal George* would meet the italic's closing asterisk as ***, and the asterisks would print.

#2 · Keep bold for the markers

script.js · lines 60–61in full code

const markers = { boldColor: col('ember'), // **^n^**: a superscript at 58 % of the text size
  referenceBold: false }; // [Fig. 1] follows the bold colour, set roman

The preprocessor writes each marker as **^n^**. The carets set the number at 58 % of the text size, raised a third of it (inline formatting), and the bold gives it bodyText.boldColor, which is free because Faraday never uses bold. A 5.8 pt figure needs a contrast of 4.5:1 against the paper, and the flame reaches only 2.6:1, so the markers take the darker ember. The reference [Fig. 1] on page 17 prints in the same colour, in roman, because referenceColor defaults to the bold colour and referenceBold: false drops the bold.

#3 · Set the notes smaller, with the number in the hang

script.js · lines 65–79in full code

const NOTE = 8.2; // pt: the notes' size, about four fifths of the text
// The hang is a bold number and an en space, measured in the notes' face once the fonts are in:
// a bold 5 matches 2, 3 and 6 within 0.02 em (the 4 is 0.05 em wider, the 1 0.14 em narrower).
function hang(label = '5') { // from ten notes on, pass the widest label: hang('10')
  const ctx = new OffscreenCanvas(1, 1).getContext('2d');
  const width = (w, s) => { ctx.font = `${w} 100px "${TEXT}"`; return ctx.measureText(s).width; };
  return em((width(700, label) + width(400, ' ')) / 100);
}
// Ragged, as justifying would stretch the en space (gotcha: ragged-no-hyphenation).
const noteStyles = () => [{ id: 'note', fontSize: pt(NOTE), lineHeight: pt(NOTE * 1.3),
  textAlign: 'left', hangingIndent: hang() },
  // 22 pt above the colophon is copy-fitted: its last line and the first column's share a line.
  { id: 'colophon', fontFamily: LABEL, fontSize: pt(7), lineHeight: pt(9.2), color: col('muted'),
    textAlign: 'left', firstLineIndent: pt(0), marginTop: pt(22) },
];

The notes are 8.2 pt on 10.7 pt, about four fifths of the text size. The pen measures the style's hangingIndent in Libre Bodoni once the fonts are loaded: a bold 5 and an en space come to 1.12 em, so the first word of each note lines up with its turnover lines (paragraph styles). With the number out in the hang, the notes need no space between them. They are set ragged because justification would stretch that en space, and a justified 55 mm column of 8.2 pt type runs loose. Tildes set subscripts the way carets set superscripts, as in C~25~H~52~ in note 4 and H~2~O in note 5.

#4 · Give the notes a page in two columns

script.js · lines 116–129in full code

const BAND = 82; // mm from the trim's top: level with the foot of Figure 1 across the spread
// The band sets the reserve too, but the first grid line clear of it lies 3 mm under the soot:
const BAND_GAP = 5; // mm more of minHeight moves the notes down a line
const notesSection = { id: 'notes', // an opener page: the drop folio, no running heads
  breakBefore: { enabled: true, parity: 'any' }, span: 'page', // the next page, either side
  layout: { layoutType: 'double', gutterWidth: mm(6) }, // two columns of about 40 characters
  advancedDesign: { enabled: true, minHeight: mm(BAND - TOP + BAND_GAP), slot: { elements: [
    soot(BAND), art('snuffed', 32, 64, BAND, 12), series,
    text('kicker', '{attr.kicker}', LABEL, 9.5, 'flame', at('container', 'top-left', 0, 16),
      caps(9.5)),
    text('title', '{titleText}', DISPLAY, 52, 'wax', below('kicker', 0.5, 80), display),
    text('intro', '{attr.intro}', LABEL, 8.4, 'rule', below('title', 2.5, 92),
      { lineHeight: 1.3 }),
  ] } } };

The heading ## Notes {style="notes" …} opens a section whose pages take the style's layout and design. parity: 'any' starts it on the next page, odd or even, and span: 'page' runs the band across both columns, so it reaches the trim and the second column starts under it (heading styles). The band sets the reserve, but the first grid line clear of it lies only 3 mm under the soot, so BAND_GAP adds 5 mm to minHeight and the notes start a line lower. The hairline between the columns is declared on the document's layout, because 1.4.1 does not draw a heading style's columnRule. Column balancing is on by default and cuts the closing page so that both columns end on the same line (column balancing).

#5 · Open the lecture on a field of soot

script.js · lines 101–112in full code

const FIELD = 112; // mm from the trim's top
// The field reaches below the heading, so it sets the reserve (gotcha: opener-reserves-anchored);
// the H1's default bottom margin (0.5 em of 18 pt) rides on it: the text starts a grid line lower.
const opener = { enabled: true,
  slot: { elements: [soot(FIELD), art('candle', 40, 100, FIELD, 10), series,
    text('kicker', '{attr.kicker}', LABEL, 9.5, 'flame', below('series', 17, 60), caps(9.5)),
    text('title', '{titleText}', DISPLAY, 48, 'wax', below('kicker', 1.5, 96), display),
    // 86 mm breaks the subtitle after a dash: no-break spaces do not hold (gotcha: nbsp-breaks)
    text('subtitle', '{attr.subtitle}', DISPLAY, 11.5, 'rule', below('title', 3.5, 86),
      { fontWeight: 500, italic: true, lineHeight: 1.3 }),
    text('byline', '{attr.byline}', LABEL, 7.6, 'rule', below('subtitle', 7, 84), caps(7.6)),
  ] } };

The field is a box anchored to the page, and the candle, an image element, stands on its lower edge. The first heading level sets span: 'page' although the lecture has one column: without it, 1.4.1 clips the design at the top of the column instead of painting it from the trim. The kicker, subtitle and byline come from the heading line, # A Candle {kicker="Lecture I" subtitle="…" byline="…"}, so Lecture II would need no new code. The field reaches below the heading, so it sets the reserve. The heading's default bottom margin of 0.5 em is added to it, and the text starts one grid line below the first line clear of the soot. The subtitle is 86 mm wide so that it breaks after a dash, since a no-break space does not hold in design text.

#6 · Use the flame on soot and the ember on paper

script.js · lines 13–23in full code

const palette = {
  ink: '#1f1c19', paper: '#fffdf8', // text and the soot of the fields; a warm white page
  flame: '#e08a1e', ember: '#a9560c', // kickers on soot (6:1); markers and numbers (5.1:1)
  wax: '#f6efe1', rule: '#d4c6ad', // type on soot; hairlines and small type on soot (10:1)
  muted: '#6d6356', blue: '#4f7cae', // running heads, colophon (5.8:1); a flame's blue foot
};
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
// The engine's defaults link to 'main-color': point it at the ember, so nothing prints blue.
// col() writes the hex too: design slots do not read the palette (gotcha: palette-skips-designs).
const colorPalette = Object.entries({ ...palette, 'main-color': palette.ember })
  .map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } }));

The flame orange has a contrast of 6:1 on soot but only 2.6:1 on the paper. It colours the kickers on the dark bands and the drawings; everything small printed in orange on the paper (markers, note numbers, the figure's label) takes the darker ember, at 5.1:1. main-color points at the ember, so a default that the config does not restate follows the design instead of printing blue.

The whole recipe

// ═══ Postext Cookbook · Nº 020 · Endnotes in two columns instead of footnotes ═════════
// https://postext.dev/en/cookbook/endnotes-instead-of-footnotes
// Code: MIT · Text: Faraday, ed. Crookes (PD, Gutenberg #14474) · Notes, drawings: CC BY 4.0
// Fonts: Libre Bodoni, Besley, Archivo Narrow (SIL OFL 1.1) · Needs postext ≥ 1.4.1
import { buildDocument, renderPageToCanvas, clearMeasurementCache, registerResourceImage }
  from 'https://esm.sh/postext';

const LANG = 'en'; // @lang: the language of the sample document ('en' | 'es')
const RECIPE = 'endnotes-instead-of-footnotes';

// ─── 1 · Design ─────────────────────────────────────────────────────────────
// #region palette: soot, wax and a flame; the ember is the flame dark enough for small type
const palette = {
  ink: '#1f1c19', paper: '#fffdf8', // text and the soot of the fields; a warm white page
  flame: '#e08a1e', ember: '#a9560c', // kickers on soot (6:1); markers and numbers (5.1:1)
  wax: '#f6efe1', rule: '#d4c6ad', // type on soot; hairlines and small type on soot (10:1)
  muted: '#6d6356', blue: '#4f7cae', // running heads, colophon (5.8:1); a flame's blue foot
};
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
// The engine's defaults link to 'main-color': point it at the ember, so nothing prints blue.
// col() writes the hex too: design slots do not read the palette (gotcha: palette-skips-designs).
const colorPalette = Object.entries({ ...palette, 'main-color': palette.ember })
  .map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } }));
// #endregion
const TEXT = 'Libre Bodoni', DISPLAY = 'Besley', LABEL = 'Archivo Narrow'; // text; titles; labels
const TOP = 22, INNER = 18, OUTER = 22; // mm: margins, and a 116 mm measure of 74 characters

// #region answer: Markdown footnotes become raised markers and a Notes section
// Use: buildDocument({ markdown: endnotes(markdown) }, config()), with a 'note' paragraph style.
// [^label] in the text → **^n^**, numbered by first citation; bold, so it takes bodyText.boldColor.
// The [^label]: definitions (one line each) print where the first stood, a 'note' paragraph each:
// '**n** text', never '1. text', which would open a numbered list (gotcha: digit-period-list).
function endnotes(markdown, style = 'note') {
  const notes = new Map(); // label → text
  const HOLE = '\u0000'; // marks where a definition stood: the first becomes the notes
  const text = markdown.replace(/^\[\^([^\]\s]+)\]:[ \t]*(.+)\n?/gm,
    (_, label, note) => { notes.set(label, note.trim()); return HOLE; });
  const cited = []; // labels in order of first citation
  const number = (label) => {
    if (!notes.has(label)) throw new Error(`The note [^${label}] has no definition`);
    if (!cited.includes(label)) cited.push(label);
    return cited.indexOf(label) + 1;
  };
  // Markers side by side share one superscript, [^a][^b] → **^1,2^**, never 12 raised (note 12).
  // A word joiner (U+2060, no width) opens each one: after an italic, '*Royal George*' and the
  // bold's ** would make '***', which the parser reads as a bold run, and print the asterisks.
  const marked = text.replace(/(?:\[\^[^\]\s]+\])+/g, (run) => {
    const numbers = [...run.matchAll(/\[\^([^\]\s]+)\]/g)].map(([, label]) => number(label));
    return `⁠**^${numbers.join(',')}^**`;
  });
  const unused = [...notes.keys()].filter((label) => !cited.includes(label));
  if (unused.length) console.warn(`Notes never cited: ${unused.join(', ')}`);
  const entries = cited.map((label, i) => `**${i + 1}** ${notes.get(label)}`);
  const section = `:::paragraphs{style="${style}"}\n${entries.join('\n\n')}\n:::\n`;
  return marked.replace(HOLE, () => section).replaceAll(HOLE, ''); // () =>: '$&' stays text
}
// #endregion

// #region markers: the lecture has no bold of its own, so the bold colour is free for the markers
const markers = { boldColor: col('ember'), // **^n^**: a superscript at 58 % of the text size
  referenceBold: false }; // [Fig. 1] follows the bold colour, set roman
// #endregion

// #region notes: 8.2 pt, set ragged, each number hanging in the indent
const NOTE = 8.2; // pt: the notes' size, about four fifths of the text
// The hang is a bold number and an en space, measured in the notes' face once the fonts are in:
// a bold 5 matches 2, 3 and 6 within 0.02 em (the 4 is 0.05 em wider, the 1 0.14 em narrower).
function hang(label = '5') { // from ten notes on, pass the widest label: hang('10')
  const ctx = new OffscreenCanvas(1, 1).getContext('2d');
  const width = (w, s) => { ctx.font = `${w} 100px "${TEXT}"`; return ctx.measureText(s).width; };
  return em((width(700, label) + width(400, ' ')) / 100);
}
// Ragged, as justifying would stretch the en space (gotcha: ragged-no-hyphenation).
const noteStyles = () => [{ id: 'note', fontSize: pt(NOTE), lineHeight: pt(NOTE * 1.3),
  textAlign: 'left', hangingIndent: hang() },
  // 22 pt above the colophon is copy-fitted: its last line and the first column's share a line.
  { id: 'colophon', fontFamily: LABEL, fontSize: pt(7), lineHeight: pt(9.2), color: col('muted'),
    textAlign: 'left', firstLineIndent: pt(0), marginTop: pt(22) },
];
// #endregion

// Design text wraps (it ends in an ellipsis by default: gotcha overflow-ellipsis-default).
const text = (id, content, family, size, color, placement, extra) => ({ kind: 'text', id,
  content, fontFamily: family, fontSize: pt(size), color: col(color), placement,
  overflow: 'wrap', align: 'left', ...extra });
const caps = (s) => ({ fontWeight: 600, textTransform: 'uppercase', letterSpacing: pt(s * 0.18) });
const display = { fontWeight: 800, lineHeight: 1 }; // the titles, set solid
const at = (to, edge, x, y, width) => ({ anchor: { to, edge }, offset: { x: mm(x), y: mm(y) },
  ...(width && { size: { width: mm(width) } }) });
const below = (id, y, width) => at(`#${id}`, 'below', 0, y, width);
// A field of soot from the trim's top, edge to edge, and a candle standing on its lower edge.
const soot = (height) => ({ kind: 'box', id: 'soot', style: { backgroundColor: col('ink') },
  placement: { ...at('page', 'top-left', 0, 0), size: { width: 'fill', height: mm(height) } } });
const art = (id, width, height, foot, x) => ({ kind: 'image', id, resourceId: id,
  placement: at('page', 'top-right', -x, foot - height, width) });

const series = text('series', '{title}', LABEL, 7.6, 'rule', at('container', 'top-left', 0, 4),
  caps(7.6)); // the book's title, from the frontmatter, heads both bands

// #region opener: the lecture opens on a field of soot with a lit candle
const FIELD = 112; // mm from the trim's top
// The field reaches below the heading, so it sets the reserve (gotcha: opener-reserves-anchored);
// the H1's default bottom margin (0.5 em of 18 pt) rides on it: the text starts a grid line lower.
const opener = { enabled: true,
  slot: { elements: [soot(FIELD), art('candle', 40, 100, FIELD, 10), series,
    text('kicker', '{attr.kicker}', LABEL, 9.5, 'flame', below('series', 17, 60), caps(9.5)),
    text('title', '{titleText}', DISPLAY, 48, 'wax', below('kicker', 1.5, 96), display),
    // 86 mm breaks the subtitle after a dash: no-break spaces do not hold (gotcha: nbsp-breaks)
    text('subtitle', '{attr.subtitle}', DISPLAY, 11.5, 'rule', below('title', 3.5, 86),
      { fontWeight: 500, italic: true, lineHeight: 1.3 }),
    text('byline', '{attr.byline}', LABEL, 7.6, 'rule', below('subtitle', 7, 84), caps(7.6)),
  ] } };
// #endregion

// #region section: the notes open a page of their own, in two columns under a band of soot
const BAND = 82; // mm from the trim's top: level with the foot of Figure 1 across the spread
// The band sets the reserve too, but the first grid line clear of it lies 3 mm under the soot:
const BAND_GAP = 5; // mm more of minHeight moves the notes down a line
const notesSection = { id: 'notes', // an opener page: the drop folio, no running heads
  breakBefore: { enabled: true, parity: 'any' }, span: 'page', // the next page, either side
  layout: { layoutType: 'double', gutterWidth: mm(6) }, // two columns of about 40 characters
  advancedDesign: { enabled: true, minHeight: mm(BAND - TOP + BAND_GAP), slot: { elements: [
    soot(BAND), art('snuffed', 32, 64, BAND, 12), series,
    text('kicker', '{attr.kicker}', LABEL, 9.5, 'flame', at('container', 'top-left', 0, 16),
      caps(9.5)),
    text('title', '{titleText}', DISPLAY, 52, 'wax', below('kicker', 0.5, 80), display),
    text('intro', '{attr.intro}', LABEL, 8.4, 'rule', below('title', 2.5, 92),
      { lineHeight: 1.3 }),
  ] } } };
// #endregion

const head = (id, content, parity, edge, x, extra) => ({ kind: 'text', id, content, parity,
  pages: 'body', fontFamily: LABEL, fontSize: pt(7.6), color: col('muted'), ...caps(7.6),
  placement: at('page', edge, x, 13), ...extra });
const folio = { fontFamily: DISPLAY, fontSize: pt(8.6), fontWeight: 700, color: col('ink'),
  letterSpacing: pt(0) }; // untracked figures
const header = { elements: [ // the book on the verso, the lecture on the recto, folios outside
  head('verso-folio', '{pageNumber}', 'even', 'top-left', OUTER, folio),
  head('verso-title', '{title}', 'even', 'top-left', OUTER + 9),
  head('recto-title', '{attr.kicker} · {chapterTitle}', 'odd', 'top-right', -(OUTER + 9)),
  head('recto-folio', '{pageNumber}', 'odd', 'top-right', -OUTER, folio),
] };
const dropFolio = text('drop', '{pageNumber}', DISPLAY, 8.6, 'ink', at('page', 'bottom', 0, -12),
  { fontWeight: 700, align: 'center', pages: 'opener' }); // the lecture's and the notes' openers

const config = () => ({ // a factory, never a shared object (gotcha: config-cache-identity)
  colorPalette, header, footer: { elements: [dropFolio] },
  page: { width: mm(156), height: mm(234), dpi: 150, // a trade octavo
    backgroundColor: col('paper'), margins: { top: mm(TOP), bottom: mm(23), left: mm(INNER),
      right: mm(OUTER), mirror: true } }, // left is the inner margin
  // Drawn only where a page has two columns: the notes' (gotcha: section-column-rule).
  layout: { layoutType: 'single', columnRule: { enabled: true, color: col('rule') } },
  bodyText: { fontFamily: TEXT, fontSize: pt(10), lineHeight: pt(13.8), color: col('ink'),
    italicColor: col('ink'), ...markers, firstLineIndent: mm(4.5), indentAfterHeading: false,
    minWordSpacing: 0.85, maxWordSpacing: 1.8 }, // the loosest lines reach 1.78 under any cap
  headings: { fontFamily: DISPLAY, color: col('ink'), levels: [
    // Break restated (gotcha: headings-drop-h1-break); the span lets the design reach the trim.
    { level: 1, span: 'page', breakBefore: { enabled: true, parity: 'odd' },
      advancedDesign: opener },
  ] },
  headingStyles: [notesSection], paragraphStyles: noteStyles(),
  // One figure, numbered through the book: "Figure 1", not the chapter-scoped "Figure 1.1".
  resourceTypes: [{ id: 'figure', name: 'Figure', shortLabel: 'Fig.', captionPrefix: 'Figure',
    numberingTemplate: '{n}', resetOn: 'never', counterFormat: 'decimal' }],
  captionStyle: { fontFamily: LABEL, fontSize: pt(8.2), labelColor: col('ember') },
});

// ─── 2 · Content ────────────────────────────────────────────────────────────
const markdown = String.raw`---
Markdown sample · 36 lines · content.en.md
title: "The Chemical History of a Candle"
author: "Michael Faraday"
---

# A Candle {kicker="Lecture I" subtitle="The Flame – Its Sources – Structure – Mobility – Brightness" byline="Michael Faraday · Christmas 1860"}

I purpose, in return for the honour you do us by coming to see what are our proceedings here, to bring before you, in the course of these lectures, the Chemical History of a Candle. I have taken this subject on a former occasion;[^christmas] and were it left to my own will, I should prefer to repeat it almost every year—so abundant is the interest that attaches itself to the subject, so wonderful are the varieties of outlet which it offers into the various departments of philosophy. There is not a law under which any part of this universe is governed which does not come into play, and is touched upon in these phenomena. There is no better, there is no more open door by which you can enter into the study of natural philosophy, than by considering the physical phenomena of a candle. I trust, therefore, I shall not disappoint you in choosing this for my subject rather than any newer topic, which could not be better, were it even so good.

But we must speak of candles as they are in commerce. Here are a couple of candles commonly called dips. They are made of lengths of cotton cut off, hung up by a loop, dipped into melted tallow, taken out again and cooled, then re-dipped until there is an accumulation of tallow round the cotton. In order that you may have an idea of the various characters of these candles, you see these which I hold in my hand—they are very small, and very curious. They are, or were, the candles used by the miners in coal mines. In olden times the miner had to find his own candles; and it was supposed that a small candle would not so soon set fire to the fire-damp in the coal mines as a large one; and for that reason, as well as for economy’s sake, he had candles made of this sort—20, 30, 40, or 60 to the pound. They have been replaced since then by the steel-mill, and then by the Davy-lamp, and other safety-lamps of various kinds. I have here a candle that was taken out of the *Royal George*[^george], it is said, by Colonel Pasley. It has been sunk in the sea for many years, subject to the action of salt water. It shews you how well candles may be preserved; for though it is cracked about and broken a good deal, yet, when lighted, it goes on burning regularly, and the tallow resumes its natural condition as soon as it is fused.

Mr. Field, of Lambeth, has supplied me abundantly with beautiful illustrations of the candle and its materials. I shall therefore now refer to them. And, first, there is the suet—the fat of the ox—Russian tallow, I believe, employed in the manufacture of these dips, which Gay Lussac, or some one who entrusted him with his knowledge, converted into that beautiful substance, stearin, which you see lying beside it. A candle, you know, is not now a greasy thing like an ordinary tallow candle, but a clean thing, and you may almost scrape off and pulverise the drops which fall from it without soiling anything. This is the process he adopted:[^stearin]—The fat or tallow is first boiled with quick-lime, and made into a soap, and then the soap is decomposed by sulphuric acid, which takes away the lime, and leaves the fat re-arranged as stearic acid, whilst a quantity of glycerin is produced at the same time. Glycerin—absolutely a sugar, or a substance similar to sugar—comes out of the tallow in this chemical change. The oil is then pressed out of it; and you see here this series of pressed cakes, shewing how beautifully the impurities are carried out by the oily part as the pressure goes on increasing, and at last you have left that substance which is melted, and cast into candles as here represented. The candle I have in my hand is a stearin candle, made of stearin from tallow in the way I have told you. Then here is a sperm candle, which comes from the purified oil of the spermaceti whale. Here also are yellow bees-wax and refined bees-wax, from which candles are made. Here, too, is that curious substance called paraffin, and some paraffin candles made of paraffin obtained from the bogs of Ireland.[^paraffin] I have here also a substance brought from Japan, since we have forced an entrance into that out-of-the-way place—a sort of wax which a kind friend has sent me, and which forms a new material for the manufacture of candles.

There is another condition which you must learn as regards the candle, without which you would not be able fully to understand the philosophy of it, and that is the vaporous condition of the fuel. In order that you may understand that, let me shew you a very pretty, but very common-place experiment. If you blow a candle out cleverly, you will see the vapour rise from it. You have, I know, often smelt the vapour of a blown-out candle—and a very bad smell it is; but if you blow it out cleverly, you will be able to see the vapour into which this solid matter is transformed. I will blow out one of these candles in such a way as not to disturb the air around it, by the continuing action of my breath; and now, if I hold a lighted taper two or three inches from the wick, you will observe a train of fire going through the air till it reaches the candle. I am obliged to be quick and ready, because, if I allow the vapour time to cool, it becomes condensed into a liquid or solid, or the stream of combustible matter gets disturbed.

Now, as to the shape or form of the flame. It concerns us much to know about the condition which the matter of the candle finally assumes at the top of the wick—where you have such beauty and brightness as nothing but combustion or flame can produce.[^combustion]

You have the glittering beauty of gold and silver, and the still higher lustre of jewels, like the ruby and diamond; but none of these rival the brilliancy and beauty of flame. What diamond can shine like flame? It owes its lustre at night-time to the very flame shining upon it. The flame shines in darkness, but the light which the diamond has is as nothing until the flame shine upon it, when it is brilliant again. The candle alone shines by itself, and for itself, or for those who have arranged the materials. Now, let us look a little at the form of the flame as you see it under the glass shade. It is steady and equal; and its general form is that which is represented in the diagram [:ref{id="flame"}], varying with atmospheric disturbances, and also varying according to the size of the candle. It is a bright oblong—brighter at the top than towards the bottom—with the wick in the middle, and besides the wick in the middle, certain darker parts towards the bottom, where the ignition is not so perfect as in the part above.

I can give you here a little further illustration, for the purpose of shewing you how flame goes up or down; according to the current. I have here a flame—it is not a candle-flame—but you can, no doubt, by this time, generalise enough to be able to compare one thing with another. What I am about to do is to change the ascending current that takes the flame upwards into a descending current. This I can easily do by the little apparatus you see before me. The flame, as I have said, is not a candle flame, but it is produced by alcohol, so that it shall not smoke too much. I will also colour the flame with another substance,[^copper] so that you may trace its course; for with the spirit alone you could hardly see well enough to have the opportunity of tracing its direction. By lighting this spirit-of-wine, we have then a flame produced; and you observe that when held in the air, it naturally goes upwards.

You understand now easily enough why flames go up under ordinary circumstances—it is because of the draught of air by which the combustion is formed. But now, by blowing the flame down, you see I am enabled to make it go downwards into this little chimney—the direction of the current being changed. Before we have concluded this course of lectures, we shall shew you a lamp in which the flame goes up and the smoke goes down, or the flame goes down and the smoke goes up. You see, then, that we have the power in this way of varying the flame in different directions.

It is too bad that we have not got further; but we must not, under any circumstances, keep you beyond your time. It will be a lesson to me in future to hold you more strictly to the philosophy of the thing, than to take up your time so much with these illustrations.

## Notes {style="notes" kicker="Lecture I" intro="The raised numbers in the lecture point here. Notes signed by the editor are new to this edition; the rest are William Crookes’s, from the impression of 1908."}

[^christmas]: Faraday first gave this course of six lectures at Christmas 1848. The text printed here is that of his second course, given at the Royal Institution in 1860–61 and published in 1861, edited by William Crookes. *Ed.*
[^george]: The *Royal George* sunk at Spithead on the 29th of August, 1782. Colonel Pasley commenced operations for the removal of the wreck by the explosion of gunpowder, in August, 1839. The candle which Professor Faraday exhibited must therefore have been exposed to the action of salt water for upwards of fifty-seven years.
[^stearin]: The fat or tallow consists of a chemical combination of fatty acids with glycerine. The lime unites with the palmitic, oleic, and stearic acids, and separates the glycerine. After washing, the insoluble lime soap is decomposed with hot dilute sulphuric acid. The melted fatty acids thus rise as an oil to the surface, when they are decanted. They are again washed and cast into thin plates, which, when cold, are placed between layers of cocoa-nut matting, and submitted to intense hydraulic pressure. In this way the soft oleic acid is squeezed out, whilst the hard palmitic and stearic acids remain. These are further purified by pressure at a higher temperature, and washing in warm dilute sulphuric acid, when they are ready to be made into candles. These acids are harder and whiter than the fats from which they were obtained, whilst at the same time they are cleaner and more combustible.
[^paraffin]: Paraffin wax is a mixture of hydrocarbons with 20 to 40 carbon atoms, such as C~25~H~52~. Karl von Reichenbach first isolated it from wood tar in 1830; by 1860 it was distilled for candles from shale, peat and coal. *Ed.*
[^combustion]: As it burns, the vapour of the wax combines with oxygen from the air and leaves the flame as water, H~2~O, and carbon dioxide, CO~2~, which Faraday calls “carbonic acid”. He finds the water in Lecture II and the carbonic acid in Lecture V. *Ed.*
[^copper]: The alcohol had chloride of copper dissolved in it: this produces a beautiful green flame.

:::paragraphs{style="colophon"}
Set in Libre Bodoni, Besley and Archivo Narrow, all three under the SIL Open Font License. The text is Michael Faraday’s, as edited by William Crookes in 1861, from the impression of 1908 (Project Gutenberg eBook 14474), abridged; the drawings and the editor’s notes are CC BY 4.0.
:::
`; // content.<lang>.md, inlined by the Cookbook

const svgResource = (id, width, height, extra) => ({ id, typeId: 'figure', kind: 'svg',
  svg: { fileId: `${id}.svg`, width, height }, createdAt: 0, updatedAt: 0, ...extra });
const resources = [
  svgResource('candle', 1600, 4000), svgResource('snuffed', 1100, 2200), // uncited: design only
  // Cited on page 17, the 'top' figure heads page 18 (gotcha: top-float-next-page).
  svgResource('flame', 2320, 1200, { placement: { position: 'top' }, caption: 'A candle flame as '
    + 'it looks under a glass shade (left) and in section (right): the dark core of wax vapour '
    + 'round the wick, the blue foot where the air first meets it, the bright zone where soot '
    + 'glows, and the faint mantle, the hottest part. Heated air rises round it and draws it up.',
    altText: 'A candle flame, whole and in section, with arrows of rising air' }),
];

// #region art: a lit candle, a snuffed one and the flame in section, in the palette (seeded)
// No words in the drawings: an SVG drawn as an image cannot use web fonts
// (gotcha: svg-no-webfonts). Arrowheads are paths (gotcha: svg-no-marker-filters).
function rng(seed) { // Mulberry32: the same smoke on every run
  return () => {
    seed = (seed + 0x6d2b79f5) | 0;
    let x = Math.imul(seed ^ (seed >>> 15), 1 | seed);
    x = (x + Math.imul(x ^ (x >>> 7), 61 | x)) ^ x;
    return ((x ^ (x >>> 14)) >>> 0) / 4294967296;
  };
}
const n = (v) => +v.toFixed(2);
const svg = (w, h, body) => `<svg xmlns="http://www.w3.org/2000/svg" width="${w * 10}" `
  + `height="${h * 10}" viewBox="0 0 ${w} ${h}">${body}</svg>`;
const shape = (d, fill, extra = '') => `<path d="${d}" fill="${fill}"${extra}/>`;
const line = (d, stroke, width, extra = '') => `<path d="${d}" fill="none" stroke="${stroke}" `
  + `stroke-width="${width}" stroke-linecap="round" stroke-linejoin="round"${extra}/>`;
const dot = (x, y, r, fill, extra = '') => `<circle cx="${n(x)}" cy="${n(y)}" r="${n(r)}" `
  + `fill="${fill}"${extra}/>`;
const op = (v) => ` fill-opacity="${v}"`;
// Light round a flame: a radial gradient from the flame's colour to nothing.
const halo = (x, y, r, strength) => `<radialGradient id="h${x}" cx="0.5" cy="0.5" r="0.5">`
  + `<stop offset="0" stop-color="${palette.flame}" stop-opacity="${strength}"/>`
  + `<stop offset="0.45" stop-color="${palette.flame}" stop-opacity="${strength * 0.35}"/>`
  + `<stop offset="1" stop-color="${palette.flame}" stop-opacity="0"/></radialGradient>`
  + dot(x, y, r, `url(#h${x})`);
// A flame from its foot (x, base) up to its tip: round below, drawn out above.
function tongue(x, base, top, half) {
  const h = base - top;
  return `M${n(x)} ${n(top)}C${n(x + half * 0.3)} ${n(top + h * 0.28)} ${n(x + half)} `
    + `${n(top + h * 0.5)} ${n(x + half)} ${n(top + h * 0.74)}`
    + `C${n(x + half)} ${n(base - h * 0.04)} `
    + `${n(x + half * 0.5)} ${n(base)} ${n(x)} ${n(base)}C${n(x - half * 0.5)} ${n(base)} `
    + `${n(x - half)} ${n(base - h * 0.04)} ${n(x - half)} ${n(top + h * 0.74)}C${n(x - half)} `
    + `${n(top + h * 0.5)} ${n(x - half * 0.3)} ${n(top + h * 0.28)} ${n(x)} ${n(top)}Z`;
}
// The flame's zones: mantle, bright body, dark core round the wick, blue foot.
function flameAt(x, base, top, half, { lit = true, section = false } = {}) {
  const h = base - top;
  const P = palette;
  let out = shape(tongue(x, base + 2, top - h * 0.08, half * 1.22), P.flame,
    section ? `${op(0.16)} stroke="${P.flame}" stroke-width="0.8"` : op(0.22));
  out += shape(tongue(x, base, top, half), P.flame);
  if (!section) { // as seen: brighter above, darker below
    out += shape(tongue(x, base - h * 0.22, top + h * 0.1, half * 0.72), P.wax, op(0.55))
      + shape(tongue(x, base - h * 0.38, top + h * 0.2, half * 0.42), P.wax, op(0.75));
  }
  out += shape(tongue(x, base, base - h * (section ? 0.5 : 0.36), half * (section ? 0.5 : 0.36)),
    section ? P.ink : P.ember, op(section ? 0.72 : 0.7));
  out += shape(`M${n(x - half * 0.95)} ${n(base - h * 0.1)}Q${n(x)} ${n(base + h * 0.06)} `
    + `${n(x + half * 0.95)} ${n(base - h * 0.1)}Q${n(x + half * 0.7)} ${n(base + h * 0.03)} `
    + `${n(x)} ${n(base + h * 0.03)}Q${n(x - half * 0.7)} ${n(base + h * 0.03)} `
    + `${n(x - half * 0.95)} ${n(base - h * 0.1)}Z`, P.blue, op(lit ? 0.9 : 0));
  return out;
}
// A pillar of wax from y down past the art's foot, with the cup of melted wax on top.
function pillar(x, y, half, foot, drip = 0) {
  const P = palette;
  const shade = `<linearGradient id="w${x}" x1="0" x2="1" y1="0" y2="0">` // rounded by light
    + `<stop offset="0" stop-color="${P.rule}"/><stop offset="0.3" stop-color="${P.wax}"/>`
    + `<stop offset="0.62" stop-color="${P.wax}"/><stop offset="1" stop-color="${P.rule}"/>`
    + '</linearGradient>';
  return shade + `<rect x="${n(x - half)}" y="${n(y)}" width="${n(half * 2)}" `
    + `height="${n(foot - y)}" fill="url(#w${x})"/>`
    + (drip ? shape(`M${n(x - half * 0.78)} ${n(y)}h${n(half * 0.34)}v${n(drip)}a${n(half * 0.17)} `
      + `${n(half * 0.17)} 0 0 1-${n(half * 0.34)} 0Z`, P.wax) : '')
    + `<ellipse cx="${n(x)}" cy="${n(y)}" rx="${n(half)}" ry="${n(half * 0.2)}" `
    + `fill="${P.wax}"/>`
    + `<ellipse cx="${n(x)}" cy="${n(y + half * 0.02)}" rx="${n(half * 0.76)}" `
    + `ry="${n(half * 0.13)}" fill="${P.rule}"${op(0.8)}/>`; // the cup of melted wax
}
const wick = (x, y, len, lean = 2) => line(`M${n(x)} ${n(y)}q${n(lean * 0.3)} ${n(-len * 0.5)} `
  + `${n(lean)} ${n(-len)}`, palette.ink, 1.6);
// Rising air: a curve from beside the foot to above the tip, and a path arrowhead.
function draught(x0, y0, x1, y1, color, width, opacity) {
  const head = shape(`M${n(x1 - 2.2)} ${n(y1 + 3.2)}L${n(x1)} ${n(y1 - 0.6)}L${n(x1 + 2.2)} `
    + `${n(y1 + 3.2)}Z`, color, op(opacity));
  return line(`M${n(x0)} ${n(y0)}C${n(x0)} ${n((y0 + y1) / 2)} ${n(x1)} ${n(y0 - (y0 - y1) * 0.6)} `
    + `${n(x1)} ${n(y1 + 2)}`, color, width, ` stroke-opacity="${opacity}"`) + head;
}
function candle() { // the opener's: 40 × 100 mm, lit, with a halo on the soot
  return svg(160, 400, halo(80, 128, 80, 0.34) + flameAt(80, 206, 66, 19)
    + pillar(80, 222, 30, 400, 46) + wick(79, 223, 22));
}
function snuffed() { // the notes band's: 32 × 64 mm, blown out, three strands of smoke
  const r = rng(7);
  const P = palette;
  let out = pillar(55, 140, 24, 220, 26) + wick(54, 141, 14, 3);
  for (let k = 0; k < 3; k++) { // three strands of vapour, thinning as they rise
    let d = `M${n(57 + k)} 126`;
    for (let y = 126, a = r() * 6; y > 8; y -= 14, a += 1.3) {
      d += `S${n(57 + Math.sin(a) * (4 + (126 - y) * 0.12))} ${n(y - 7)} `
        + `${n(57 + Math.sin(a + 0.8) * (3 + (126 - y) * 0.1))} ${n(y - 14)}`;
    }
    out += line(d, P.rule, 1.2 - k * 0.3, ` stroke-opacity="${0.55 - k * 0.15}"`);
  }
  return svg(110, 220, out + dot(57, 127, 1.6, P.ember));
}
function flame() { // Figure 1: 116 × 60 mm, as seen and in section, on soot
  const P = palette;
  let out = `<rect width="232" height="120" rx="2" fill="${P.ink}"/>`;
  out += halo(70, 60, 46, 0.3) + flameAt(70, 92, 24, 11) + pillar(70, 100, 17, 120, 12)
    + wick(69.5, 101, 12) // then the glass shade, open below, drawn over the candle it stands round
    + `<path d="M47 112V17a5 5 0 0 1 5-5h36a5 5 0 0 1 5 5v95" fill="${P.wax}"${op(0.05)} `
    + `stroke="${P.rule}" stroke-opacity="0.4" stroke-width="0.8"/>`
    + line('M52 18v88', P.wax, 1.4, ' stroke-opacity="0.18"');
  for (const side of [-1, 1]) { // the air the flame heats, rising round it
    out += draught(160 + side * 32, 108, 160 + side * 10, 14, P.rule, 1, 0.75)
      + draught(160 + side * 44, 104, 160 + side * 22, 30, P.rule, 1, 0.5);
  }
  return svg(232, 120, out + flameAt(160, 92, 24, 11, { section: true })
    + pillar(160, 100, 17, 120) + wick(159.5, 101, 12));
}
const drawings = { candle, snuffed, flame };
// #endregion

// ─── 3 · Fonts ──────────────────────────────────────────────────────────────
// Every face the design uses, loaded before the first build (gotcha: fonts-first).
const FONTS = { 'Libre Bodoni': ['400', '400i', '700'], // text and notes (700: the numbers)
  Besley: ['500i', '700', '800'], 'Archivo Narrow': ['400', '400i', '600', '700'] }; // labels

// ─── 4 · Build & show ───────────────────────────────────────────────────────
const source = endnotes(markdown); // the answer, run before the engine sees the text
await Promise.all([loadFonts(FONTS, source),
  ...Object.entries(drawings).map(([id, draw]) => loadSvg(`${id}.svg`, draw()))]);
// The lecture starts on folio 15, a recto, 14 pages into the book (gotcha: parity-page1-recto).
const continuation = { pageIndexOffset: 14, pageNumbering: { startAt: 15 } };
const doc = await buildWithFonts(
  () => buildDocument({ markdown: source, resources, continuation }, config()), source);
showPages(doc, { title: 'The Chemical History of a Candle, Lecture I' });

Kit · core, fonts, viewer, images: the same in every recipe · 270 lines
// ─── Kit ── helpers shared by every Cookbook recipe · postext.dev/cookbook ─────

// ─── Kit · core v1 ── the same in every recipe · postext.dev/cookbook ─────────
function mm(value) { return { value, unit: 'mm' }; }
function pt(value) { return { value, unit: 'pt' }; }
function em(value) { return { value, unit: 'em' }; }
/** The sample language's string: t({ en: 'Figure', es: 'Figura' }). */
function t(strings) { return strings[LANG] ?? Object.values(strings)[0]; }
/** A file in this recipe's assets folder, served from the Postext repo by jsDelivr. */
function asset(file) { return `https://cdn.jsdelivr.net/gh/drnachio/postext@main/cookbook/${RECIPE}/assets/${file}`; }

// ─── Kit · fonts v1 ── the same in every recipe · postext.dev/cookbook ────────
// Postext measures text with the faces the browser has loaded, and caches the
// widths, so every face must be ready before the first build. Faces come from
// Fontsource: the same static files the PDF embeds, so screen and PDF agree.

/** faces = { 'Family Name': ['400', '400i', '700'] }. `text` is the sample:
 *  letters beyond Latin-1 (č, ł, ő…) also load the latin-ext files. With
 *  `optional`, a face Fontsource does not ship is skipped instead of failing.
 *  Resolves to the number of faces added. */
async function loadFonts(faces, text = '', { optional = false } = {}) {
  kitStatus('Loading fonts…');
  const ranges = {
    latin: 'U+0000-00FF,U+0131,U+0152-0153,U+02BB-02BC,U+02C6,U+02DA,U+02DC,U+0304,U+0308,U+0329,'
      + 'U+2000-206F,U+20AC,U+2122,U+2191,U+2193,U+2212,U+2215,U+FEFF,U+FFFD',
    'latin-ext': 'U+0100-02BA,U+02BD-02C5,U+02C7-02CC,U+02CE-02D7,U+02DD-02FF,U+0304,U+0308,U+0329,'
      + 'U+1D00-1DBF,U+1E00-1E9F,U+1EF2-1EFF,U+2020,U+20A0-20AB,U+20AD-20C0,U+2113,U+2C60-2C7F,U+A720-A7FF',
  };
  const subsets = /[Ā-˿Ḁ-ỿ]/.test(text) ? ['latin', 'latin-ext'] : ['latin'];
  const jobs = [];
  let added = 0;
  for (const [family, specs] of Object.entries(faces)) {
    const id = fontsourceId(family);
    const meta = optional ? await fontsourceMeta(family) : null;
    for (const spec of new Set(specs)) {
      const weight = parseInt(spec, 10);
      const style = spec.endsWith('i') ? 'italic' : 'normal';
      if (hasFace(family, weight, style)) continue;
      if (optional && !(meta?.weights.includes(weight) && meta.styles.includes(style))) continue;
      for (const subset of subsets) {
        const url = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-${subset}-${weight}-${style}.woff2`;
        const face = new FontFace(family, `url(${url}) format('woff2')`,
          { weight: String(weight), style, unicodeRange: ranges[subset] });
        jobs.push(face.load().then((ready) => { document.fonts.add(ready); added++; }, () => {
          if (subset === 'latin' && !optional) throw new Error(`Fontsource has no ${family} ${weight} ${style}`);
        }));
      }
    }
  }
  await Promise.all(jobs).catch((error) => { kitFail(error); throw error; });
  return added;
}

/** Runs `build` (a buildDocument or buildBundle call) and checks the faces
 *  the pages use. A regular face missing from FONTS is loaded with a warning;
 *  bold and italic variants are loaded when the family ships them. Then the
 *  measurement caches are cleared and the build runs again. */
async function buildWithFonts(build, text = '') {
  const tried = new Set();
  for (let round = 0; round < 3; round++) {
    kitStatus('Laying out…');
    await new Promise(requestAnimationFrame);          // let the status paint first
    const result = await Promise.resolve().then(build).catch((error) => { kitFail(error); throw error; });
    const wanted = { base: {}, variants: {} };
    for (const { font, base } of [result].flat().flatMap(fontStringsOf)) {
      const { family, weight, style } = parseFont(font);
      const key = `${family}|${weight}|${style}`;
      if (tried.has(key) || hasFace(family, weight, style)) continue;
      tried.add(key);
      (wanted[base ? 'base' : 'variants'][family] ??= []).push(`${weight}${style === 'italic' ? 'i' : ''}`);
    }
    if (Object.keys(wanted.base).length) {
      console.warn(`[cookbook] FONTS does not list ${JSON.stringify(wanted.base)}: loading them.`);
    }
    const added = await loadFonts(wanted.base, text) + await loadFonts(wanted.variants, text, { optional: true });
    if (added === 0) return result;
    clearMeasurementCache();
  }
  throw new Error('The fonts did not settle after three builds.');
}

/** Every font string of the layout. `base` marks a block's own face; its
 *  bold, italic and bold-italic variants are listed whether or not used. */
function fontStringsOf(doc) {
  const found = new Map();
  const walk = (node) => {
    if (!node || typeof node !== 'object') return;
    if (Array.isArray(node)) { node.forEach(walk); return; }
    for (const [key, value] of Object.entries(node)) {
      if (typeof value === 'string' && /fontString$/i.test(key)) {
        found.set(value, found.get(value) || key === 'fontString');
      } else if (value && typeof value === 'object') walk(value);
    }
  };
  walk(doc.pages);
  walk(doc.blocks);
  return [...found].map(([font, base]) => ({ font, base }));
}

/** '700 37.5px Open Sans' / 'italic 400 13px "Source Serif 4"' → { family, weight, style }.
 *  A string with no weight ('95.8px Young Serif', from a design text) is 400. */
function parseFont(font) {
  const m = /^(?:(italic|oblique)\s+)?(?:small-caps\s+)?(?:(\d+|bold|normal)\s+)?[\d.]+px\s+(.+)$/.exec(font.trim());
  if (!m) throw new Error(`Unexpected font string: ${font}`);
  const weight = m[2] === 'bold' ? 700 : !m[2] || m[2] === 'normal' ? 400 : Number(m[2]);
  return { family: m[3].replace(/^["']|["']$/g, ''), weight, style: m[1] ? 'italic' : 'normal' };
}

/** True when a loaded FontFace covers exactly this family, weight and style
 *  (document.fonts.check() is also true for families nobody declared). */
function hasFace(family, weight, style) {
  for (const face of document.fonts) {
    if (face.status !== 'loaded' || face.style !== style) continue;
    if (face.family.replace(/^["']|["']$/g, '') !== family) continue;
    const [low, high = low] = face.weight.split(' ').map(Number);
    if (weight >= low && weight <= high) return true;
  }
  return false;
}

/** Fontsource's id for a family: 'Source Serif 4' → 'source-serif-4'. */
function fontsourceId(family) { return family.toLowerCase().replace(/\s+/g, '-'); }

/** The weights and styles a family ships ({ weights: [400, 700], styles: ['normal', 'italic'] }), or null. */
function fontsourceMeta(family) {
  fontsourceMeta.cache ??= new Map();
  const id = fontsourceId(family);
  if (!fontsourceMeta.cache.has(id)) {
    fontsourceMeta.cache.set(id, fetch(`https://api.fontsource.org/v1/fonts/${id}`)
      .then((res) => (res.ok ? res.json() : null), () => null));
  }
  return fontsourceMeta.cache.get(id);
}

// ─── Kit · viewer v1 ── the same in every recipe · postext.dev/cookbook ───────
/** Shows the pages as facing spreads on a dark desk: the first page is a
 *  recto on its own, then verso | recto pairs, as in a bound book. Pages
 *  are painted when they scroll near the screen. */
function showPages(docs, { title, width = 460 } = {}) {
  const root = viewer(title);
  const pages = [docs].flat().flatMap((doc) =>
    doc.pages.map((page) => ({ doc, page, n: (doc.pageIndexOffset ?? 0) + page.index })));
  const spreads = [];
  let verso = null;
  for (const p of pages) {
    if (p.n % 2 === 1) { if (verso) spreads.push([verso, null]); verso = p; }
    else { spreads.push([verso, p]); verso = null; }
  }
  if (verso) spreads.push([verso, null]);
  const density = Math.min(window.devicePixelRatio || 1, 2);
  showPages.painter?.disconnect();
  const painter = new IntersectionObserver((entries) => {
    for (const { isIntersecting, target } of entries) {
      if (!isIntersecting) continue;
      painter.unobserve(target);
      const { doc, page } = target.postext;
      renderPageToCanvas(page, doc, target, { scale: (width * density) / page.width });
    }
  }, { rootMargin: '800px' });
  showPages.painter = painter;
  root.replaceChildren(...spreads.map((pair) => {
    const spread = document.createElement('div');
    spread.className = 'pt-spread';
    for (const p of pair) {
      const figure = document.createElement('figure');
      if (p) {
        const label = p.page.pageLabel || String(p.n + 1);
        const canvas = document.createElement('canvas');
        canvas.postext = p;
        canvas.style.aspectRatio = `${p.page.width} / ${p.page.height}`;
        canvas.setAttribute('role', 'img');
        canvas.setAttribute('aria-label', `Page ${label}`);
        const folio = document.createElement('figcaption');
        folio.textContent = label;
        figure.append(canvas, folio);
        painter.observe(canvas);
      } else figure.className = 'pt-blank';
      spread.append(figure);
    }
    return spread;
  }));
  kitStatus(`${pages.length} ${pages.length === 1 ? 'page' : 'pages'}`);
  document.documentElement.dataset.postext = 'ready';
  return pages.length;
}

/** The desk, the bar and the error reporting, created once. */
function viewer(title) {
  if (!document.getElementById('pt-kit')) {
    document.head.insertAdjacentHTML('beforeend', `<style id="pt-kit">
      :root { color-scheme: dark; }
      body { margin: 0; background: #0e1014; color: #b9bcc4; font: 13px/1.45 system-ui, sans-serif; }
      #pt-bar { position: sticky; top: 0; z-index: 1; display: flex; flex-wrap: wrap; align-items: center;
        gap: 6px 16px; padding: 10px 16px; background: rgb(14 16 20 / .92); backdrop-filter: blur(6px);
        border-bottom: 1px solid #23262d; }
      #pt-bar strong { color: #f4f1ea; font-weight: 600; }
      #pt-actions { display: flex; gap: 12px; margin-left: auto; }
      #pt-actions a, #pt-actions button { color: #d8a21a; font: inherit; background: none; border: 0; padding: 0; cursor: pointer; }
      #pages { display: grid; justify-items: center; gap: 48px; padding: 32px 16px 72px; }
      .pt-spread { display: flex; }
      .pt-spread figure { margin: 0; width: min(460px, 44vw); }
      .pt-spread canvas { display: block; width: 100%; background: #fff;
        box-shadow: 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figure:first-child canvas { box-shadow: inset -14px 0 14px -14px rgb(0 0 0 / .18), 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figcaption { margin-top: 10px; text-align: center; font: 600 10px/1 system-ui, sans-serif;
        letter-spacing: .18em; text-transform: uppercase; color: #6c7079; }
      .pt-blank { visibility: hidden; }
      @media (max-width: 760px) {
        .pt-spread { flex-direction: column; gap: 32px; }
        .pt-spread figure { width: min(460px, 92vw); }
        .pt-blank { display: none; }
      }
    </style>`);
    document.body.insertAdjacentHTML('afterbegin',
      '<header id="pt-bar"><strong id="pt-title"></strong><span id="pt-status" role="status"></span><span id="pt-actions"></span></header>');
    document.getElementById('pt-title').textContent = document.title || 'Postext';
    addEventListener('error', (event) => kitFail(event.error ?? event.message));
    addEventListener('unhandledrejection', (event) => kitFail(event.reason));
  }
  if (title) document.getElementById('pt-title').textContent = title;
  return document.getElementById('pages')
    ?? document.body.appendChild(Object.assign(document.createElement('main'), { id: 'pages' }));
}

function kitStatus(text) {
  viewer();
  document.getElementById('pt-status').textContent = text;
}

function kitFail(error) {
  document.documentElement.dataset.postext = 'error';
  kitStatus(`Error: ${error?.message ?? error}`);
}

// ─── Kit · images v1 ── recipes with pictures · postext.dev/cookbook ──────────
/** Registers a photo or PNG for the canvas and keeps its bytes for the PDF.
 *  fetch → ImageBitmap never taints the canvas (a plain cross-origin <img> would). */
async function loadImage(fileId, url) {
  const res = await fetch(url);
  if (!res.ok) throw new Error(`Image not found (${res.status}): ${url}`);
  const bytes = new Uint8Array(await res.arrayBuffer());
  registerResourceImage(fileId, await createImageBitmap(new Blob([bytes])));
  (loadImage.bytes ??= new Map()).set(fileId, bytes);
}

/** Registers SVG markup (drawn in code, or fetched) as a vector image. */
async function loadSvg(fileId, svg) {
  const img = new Image();
  await img.decode();
  registerResourceImage(fileId, img);
  (loadImage.bytes ??= new Map()).set(fileId, new TextEncoder().encode(svg));
}

/** renderToPdf({ resourceBytes: imageBytes }) */
function imageBytes(fileId) { return loadImage.bytes?.get(fileId); }

/** renderToHtml({ resourceImageUrl: imageUrl }) */
function imageUrl(fileId) {
  const bytes = imageBytes(fileId);
  if (!bytes) return undefined;
  imageUrl.urls ??= new Map();
  if (!imageUrl.urls.has(fileId)) {
    const type = /\.svg$/i.test(fileId) ? 'image/svg+xml' : /\.png$/i.test(fileId) ? 'image/png' : 'image/jpeg';
    imageUrl.urls.set(fileId, URL.createObjectURL(new Blob([bytes], { type })));
  }
  return imageUrl.urls.get(fileId);
}

// ─── /Kit ───────────────────────────────────────────────────────────────────────

The composed script.js runs as it is: paste it into any page’s module script, or open the recipe on CodePen. Recipe folder on GitHub ↗

Variations

#Mark the notes in ink

If the text uses bold for its own emphasis, print the markers in ink, since boldColor colours the markers and every bold word alike.

-const markers = { boldColor: col('ember'), // **^n^**: a superscript at 58 % of the text size
+const markers = { boldColor: col('ink'), // **^n^**: a superscript at 58 % of the text size

#Let the note columns run unlevelled

Switch off the balancing of the closing page, and the first column fills to the foot before the second begins.

-  headings: { fontFamily: DISPLAY, color: col('ink'), levels: [
+  headings: { fontFamily: DISPLAY, color: col('ink'), balancing: { trailing: false }, levels: [

Pitfalls

Pitfall

'1998. ' or '- ' at a paragraph start opens a list

A paragraph that starts with a number, a period and a space, or with a hyphen and a space, becomes a list item. Put a word joiner (U+2060) before the number, and write dialogue with an em dash. Escapes and literal characters →

Pitfall

Ragged text is never hyphenated

Hyphenation applies to justified text only; ragged-right text breaks between words, so a narrow ragged column gets a deep rag. Justify the passage or widen the measure. Hyphenation and document language →

Pitfall

A heading style's column rule is not drawn

In postext 1.4.1 a heading style's layout switches its section to two columns, but the renderers read only the document's layout.columnRule, so a columnRule inside headingStyles[].layout is ignored. Declare the rule on the document's layout instead: it is drawn only where a page has more than one column, so a single-column book gets it on its two-column section alone. Column rule →

Pitfall

A no-break space still breaks the line

In postext 1.4.1 the line breaker treats U+00A0 as an ordinary space, so 0.08 %, 2.006 s or Section 2 can split across two lines. Close the pair up (0.08%) or reword the sentence. Escapes and literal characters →

Pitfall

A 'top' float never lands on its citing page

A float never goes above its own reference, so a page-wide 'top' float cited on page N opens page N+1. Cite it earlier, or use position 'auto' or 'bottom', which can take the foot of the citing page. Figure placement →

Pitfall

A swapped palette misses design elements and the reference colour

postext 1.4.1 reads colorPalette into the text styles (body, headings, lists, captions, tables, boxes) but not into the elements of headers, footers, openers and part pages, nor into bodyText.referenceColor: they keep the hex written beside their paletteId. When you swap the palette, for a dark screen edition or a retint, rewrite every linked colour from colorPalette before the build. Semantic colour palette →

Pitfall

An opener reserves height down to its lowest page-anchored element

An advanced-design opener reserves the height of its lowest element, and page- or bleed-anchored elements below the heading count too, so decoration at the foot of the page pushes the text to the next page. Keep such decoration above the heading, move it to a header or footer slot, or set the reservation with minHeight. Designed openers →

Pitfall

Any headings object switches off the H1 page break

By default an H1 breaks to a recto (always-odd), but passing any headings object resets that default, so chapters run on and span: 'page' does nothing. Restate headings.levels[0].breakBefore: { enabled: true, parity } in every config. Chapters that open on a recto →

Pitfall

Design text overflow defaults to 'ellipsis-end'

A design text element that does not fit its width ends in an ellipsis by default. Set overflow: 'wrap' for titles that should break onto more lines. Text, rules and boxes in page designs →

Pitfall

Text inside an SVG <img> cannot use web fonts

An SVG is drawn as an image, and an image has no access to the page's web fonts, so its labels fall back to a system face. Outline the text, embed an @font-face subset in the SVG, or move the labels to the caption. Figures and tables as resources →

Pitfall

No <marker> or filters in SVG art (raster fallback)

An SVG figure stays vector in the PDF only without <marker>, filters and masks; otherwise it falls back to a raster, and deeply nested filters can blank it in Chrome. Draw arrowheads as paths. Figures and tables as resources →

Pitfall

Page 1 is a recto: plan pages with physical numbers

Page 1 is a right-hand page and page 2 the first verso, so plan spreads with physical page numbers: an opener on an even page faces the odd page after it. Page and column breaks →

Pitfall

Quote every frontmatter value

YAML reads title: 1984 as a number and a date as a Date object, and non-string values print empty in placeholders and leave the PDF without a title. Quote every value: title: "1984". Document metadata →

Pitfall

A config is cached by identity: build a fresh object

The engine caches resolved configs by object identity, so changing a config in place and building again reuses the old result. Build a fresh object for every build, which is why a recipe's config is a factory: config(). Pages on a canvas →

Pitfall

Load every face before layout

Layout measures text with the faces the browser has loaded and caches the widths, so a face that arrives after the first build leaves wrong line breaks and a PDF that no longer matches the screen. Load every weight and style first, and call clearMeasurementCache() before rebuilding when one arrives late. Fonts before layout →

Credits

Recipe: Ignacio Ferro
Text: The Chemical History of a Candle, Lecture I (abridged), and William Crookes’s notes to it, from the Chatto & Windus impression of 1908 · Michael Faraday; William Crookes · public domain
The notes signed Ed., the colophon and the drawings · Ignacio Ferro · CC BY 4.0
Fonts: Libre Bodoni (SIL OFL 1.1) · Besley (SIL OFL 1.1) · Archivo Narrow (SIL OFL 1.1)
Code: MIT, like Postext

Edit this write-up ↗Recipe folder on GitHub ↗

#What you'll build

#The short answer

#Ingredients

#Method

#1 · Turn footnotes into endnotes before the build

#2 · Keep bold for the markers

#3 · Set the notes smaller, with the number in the hang

#4 · Give the notes a page in two columns

#5 · Open the lecture on a field of soot

#6 · Use the flame on soot and the ember on paper

#The whole recipe

#Variations

#Mark the notes in ink

#Let the note columns run unlevelled

#Pitfalls

#Credits

More from the Cookbook

Annotated classic with margin glosses

Critical edition: line numbers and line-keyed notes

Thesis back matter: appendix, glossary and index

What you'll build

The short answer

Ingredients

Method

The whole recipe

Variations

Pitfalls

Credits
