What you'll build

The front page and page 2 of The Elverdale Courier, an invented valley weekly, on a 246 × 328 mm sheet. A blackletter nameplate sits between a weather ear and a price ear, over a thick and a thin rule and the dateline. The lead story opens with a two-line banner in Libre Franklin Black at 56 pt across both columns, an italic deck and a photo band 222 mm wide, then runs in two justified columns parted by a hairline. At the foot, four briefs share a tinted strip, one to a column, each led by a red chip. Page 2 opens on a red section flag and holds the bridge story with a drawing made in code, a five-day forecast at the head of the right column, a second headline across the page, the letters and a table of the ward votes with a bar in every row.

This recipe answers

Can Postext set three or more text columns, or wrap text around an image?
How do I set a box across both columns mid-page, such as a 3-up "in numbers" panel?
How do I control where a figure goes: top of page, across both columns, exactly here, or in the margin?
How do I set a chapter title across the page while the body runs in two columns below?

The short answer

script.js · lines 83–100in full code

const layout = { layoutType: 'double', gutterWidth: mm(GUTTER), // the most a body can have
  columnRule: { enabled: true, color: col('rule'), lineWidth: pt(0.5) } };
// Three or more columns live only inside a box: a :::columns group in a :::callout. Its fence
// spans the page and floats the box to the foot, so the story fills the columns above it:
//   :::callout{type="briefs" span="page" placement="bottom" title="In brief"}
//   :::columns{count=4 breaks="2,3,4"}   ← each brief opens a column (child 2, 3 and 4)
//   …four paragraphs…
//   :::
//   :::                                  (gotcha: callout-columns)
// The style could carry span and placement too; on the fence they stay in sight in the text.
// hook-up: config() takes layout as it is and lists briefs in calloutStyles.
const briefs = { id: 'briefs',
  background: col('tint'), // one device: a tint, no stripe or border
  padding: { top: mm(3), right: mm(4), bottom: mm(4), left: mm(4) },
  columnGap: mm(GUTTER), // the inner columns keep the page's gutter
  titleStyle: { ...caps(9, 800, 'flag'), gap: mm(2) },
  body: { fontFamily: 'PT Serif', fontSize: pt(8.6), lineHeight: pt(11.4), textAlign: 'left',
    firstLineIndent: pt(0) } }; // ragged and unindented, unlike the columns

Two body columns at most, so the four-up strip is a box with columns

Ingredients

Features: Boxes across the page Columns inside a box Floated boxes Designed openers Full-width chapter band Heading styles Heading attributes Anchoring design elements Text, rules and boxes in page designs Running heads and folios Column rule Callout boxes Inline chips Paragraph styles Figure placement Figures exactly here Source and credit lines Named table styles Custom resource types Pictures in table cells
Also uses: Citations that place figures Paper colour Page and column breaks Figures and tables as resources Running heads per section Explicit vertical space
Type: Grenze Gotisch, PT Serif, Libre Franklin (SIL OFL 1.1)
Assets: ridge-2400.jpg
Wind turbines on a snowy ridge (the front-page photograph, cropped to a band) (Jason Blackeye, CC0 1.0)
The bridge drawing and the bars in the ward table, drawn in code in the page's palette (Ignacio Ferro, CC BY 4.0)
API: buildDocumentclearMeasurementCacheregisterResourceImagerenderPageToCanvas

Method

#1 · Newsprint, ink and one red

script.js · lines 14–27in full code

const palette = {
  ink: '#111315', // text and the heavy rules: a cold near-black
  paper: '#f8f5ee', // newsprint, and type reversed out of ink or red
  flag: '#a6192e', // the one accent: section flags, kickers, the Yes bars
  tint: '#ebe6db', // the In brief strip
  rule: '#9a978f', // hairlines: the column rule, table rules
  muted: '#5d5a55', // bylines, the folio line's title and date, credit notes, the imprint
};
// The hex rides along: 1.4.1 designs read it, not the link (gotcha: palette-skips-designs).
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
const colorPalette = [ // defaults link to 'main-color': point it at the ink, never blue
  ...Object.entries(palette).map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } })),
  { id: 'main-color', name: 'ink (defaults)', value: { hex: palette.ink, model: 'hex' } },
];

The page is newsprint (#f8f5ee) and the type near-black ink (#111315). The one red, #a6192e, goes on the section flags, the kickers, the chips and the yes bars. Each colour carries its paletteId and its hex, because 1.4.1 paints design elements from the hex. main-color points at the ink, so the italics and every default the config leaves alone print in ink. bodyText.boldColor is set to the ink as well. The reference colour falls back to it and each box copies it for its bold text, and the palette recolours neither. Without it, the two references on page 2 and the bold lead-ins of the briefs print in the default blue, #295AA3.

#2 · The nameplate is the front page's H1

script.js · lines 51–79in full code

const NAME = 52; // pt: the blackletter nameplate
const EAR = 31; // mm: each ear, in the room the nameplate leaves at either side
const EAR_DROP = 1.8; // mm: measured so the ears' big figures sit on the nameplate's baseline
const AIR = 2; // mm between the lower rule and the masthead's foot, where the banner box starts
const ear = (side, lines) => lines.map(([id, content, look], i) => text(id, content,
  { ...look, align: side }, { ...(i === 0 ? at('container', `top-${side}`, 0, EAR_DROP)
    : at(`#${lines[i - 1][0]}`, 'below', 0, 1)), size: { width: mm(EAR) } }));
const serif = { fontFamily: 'PT Serif', fontSize: pt(9), italic: true, color: col('ink'),
  lineHeight: 1.25 }; // a multiple of the size (gotcha: design-lineheight-multiple)
const nameplate = { enabled: true, slot: { elements: [
  depth(7), // the masthead is seven grid lines deep; the rules and dateline hang from its foot
  { kind: 'rule', id: 'foot', thickness: pt(0.5), color: col('ink'),
    placement: { ...at('#depth', 'align-bottom', 0, -AIR), size: { width: 'fill' } } },
  ...[['left', '{attr.issue}'], ['center', '{publishDate}'], ['right', '{attr.area}']].map(
    ([align, content]) => text(`date-${align}`, content, { ...caps(7.5, 600), align },
      { ...at('#foot', 'above', 0, -1.4), size: { width: 'fill' } })),
  rule('thin', '#date-left', 0.5, 1.6), rule('heavy', '#thin', 2.5, 0.6), // the Oxford rule
  text('name', '{titleText}', { fontFamily: 'Grenze Gotisch', fontSize: pt(NAME),
    fontWeight: 700, lineHeight: 1, align: 'center' },
  { ...at('#heavy', 'above', 0, -1.2), size: { width: 'fill' } }), // centred between the ears
  ...ear('left', [['w-kicker', 'Weather', caps(7, 700, 'flag')],
    ['w-outlook', '{attr.outlook}', serif], ['w-temps', '{attr.temps}', franklin(15, 800)]]),
  ...ear('right', [['p-kicker', '{attr.since}', caps(7, 700, 'flag')],
    ['p-day', '{attr.day}', serif], ['p-price', '{attr.price}', franklin(15, 800)]]),
] } };
// hook-up: headingStyles gets { id: 'front', advancedDesign: nameplate, header: { elements:
// [] } }, H1 already spans the page, and the Markdown opens with
// # The Elverdale Courier {style="front" issue="…" area="…" outlook="…" temps="…" since="…"
//   day="…" price="…"}

# The Elverdale Courier takes the front heading style, which fills the masthead from the heading's text and seven of its attributes (issue, area, outlook, temps, since, day and price); the date comes from publishDate in the frontmatter. An empty box seven grid lines deep (31.1 mm) sets the height of the opener. The rules, the dateline and the name hang from its foot, so the opener ends on a grid line. Make the box 6.6 lines deep and 1.4.1 draws the column rule down through the name and the dateline.

#3 · A headline across both columns is a box

script.js · lines 104–117in full code

// :::callout{type="banner" span="page" title="Transport"} ← an optional kicker, then the H2
const banner = { id: 'banner', backgroundEnabled: false,
  padding: { top: pt(0), right: pt(0), bottom: pt(0), left: pt(0) },
  titleStyle: { ...caps(8, 800, 'flag'), gap: mm(1.2) }, // a kicker, when the fence has a title
  marginTop: pt(0), // flush under the nameplate or the section flag
  marginBottom: pt(LEAD / 2), // half a line, then the columns start on the next grid line
  body: { fontFamily: 'PT Serif', fontSize: pt(13), lineHeight: pt(16.5), textAlign: 'left' } };
// A story that starts mid-page: the same box under a rule. The columns above it are cut level.
const story = { ...banner, id: 'story', marginTop: pt(LEAD),
  stripe: { enabled: true, side: 'top', width: pt(1), color: col('ink') }, // its one device
  padding: { top: mm(2.5), right: pt(0), bottom: pt(0), left: pt(0) } };
// Inside the box the headline is an H2 in a heading style: one size for each rank of story.
const headline = (id, size, look = {}) => ({ id, fontSize: pt(size), lineHeight: pt(size * 1.02),
  marginBottom: pt(size * 0.2), ...look }); // tight leading, a fifth of it below

A heading spans both columns only as an opener, and an opener starts a new page. Put span: 'page' on the ward story's H2 instead of its box and that story moves to a third page. A frameless box with span="page" can start mid-page. On page 2 the columns are cut level above it and resume below. The box holds the H2 in one of three heading styles (56, 30 or 22 pt), the italic deck and, on the front page, the photograph. Its marginBottom of half a line starts the columns on the next grid line, 3.4 mm under the deck on page 2. At the default margin the gap is 7.8 mm and the letters run onto a third page.

#4 · More than two columns live inside a box

The code for this step is the short answer above. A page's body takes two columns at most (Layout types), so a newspaper's four or five columns go in a box, here a page-wide one holding a :::columns group. breaks counts the group's blocks, one per brief, so briefs 2, 3 and 4 open columns 2, 3 and 4. Each column is 49 mm wide, with the page's 6 mm gutter between them.

:::callout{type="briefs" span="page" placement="bottom" title="In brief"}
:::columns{count=4 breaks="2,3,4"}
:chip[TRANSPORT]{style="flag"} **Bus 44 back on Sundays.** The Elverdale to Kirkby bus …

:chip[SCHOOLS]{style="flag"} **An orchard for Brook Lane.** Pupils at Brook Lane …
…
:::
:::

placement="bottom" floats the box to the foot of page 1, where it takes 36.9 mm, and the story fills the 83 mm of columns above it. Nor does 1.4.1 wrap text round a picture. A float takes a whole band of its column or of the page, so the lead photo is a band across both columns inside the banner box, and the bridge drawing takes the full width of column 1. To set text beside a picture, use the same kind of box: in :::columns{count=2 breaks="2"} the ::resource line opens the first column and the text the second.

#5 · Pictures inline, tables as floats

script.js · lines 342–377in full code

// A caption label prints only when captionPrefix has text: '' leaves no "Figure 1".
const unnumbered = (id, name, captionStyle) => ({ id, name, shortLabel: name, captionPrefix: '',
  numberingTemplate: '', resetOn: 'never', counterFormat: 'decimal', captionStyle });
const resourceTypes = [unnumbered('picture', 'Picture'), // captions under the picture
  unnumbered('panel', 'Panel', { position: 'above', fontSize: pt(9.5) })]; // tables: titled above
const resource = (id, typeId, kind, body, extra) => ({ id, typeId, kind, [kind]: body,
  createdAt: 0, updatedAt: 0, ...extra });
const resources = [
  // Set inline in the page-span banner box: a 'top' float never lands above the line that
  // cites it (gotcha: top-float-next-page). A :::space gives it air (gotcha: box-embed-no-gap).
  // 2400 px at 150 dpi is 406 mm: the photo shrinks to the box (gotcha: bitmap-print-size).
  resource('ridge', 'picture', 'bitmap', { fileId: 'ridge-2400.jpg', format: 'jpeg', width: 2400,
    height: 800 }, { placement: { position: 'here' },
    altText: 'Wind turbines on a snow-covered ridge under a bright, cloudy sky.',
    caption: '**File picture:** turbines on an upland ridge. Each of the three planned for '
      + 'Harrow Ridge would generate 2.3 megawatts.',
    note: 'Photograph: Jason Blackeye, CC0, via Wikimedia Commons' }),
  // Drawn in code (the art region) and set inline, where ::resource puts it in column 1.
  resource('bridge', 'picture', 'svg', { fileId: 'bridge.svg', width: 1190, height: 460 },
    { placement: { position: 'here' },
      altText: 'Drawing of a two-arch stone bridge between sloping river banks; under its '
        + 'central pier, a red concrete footing.',
      caption: '**The rebuilt pier.** Its new concrete footing (red) goes six metres below the '
        + 'riverbed. Both arches were relaid with their own stones.',
      note: 'Drawing: The Courier' }),
  // A page-span 'bottom' float sits under both columns of the page that cites it. On the last
  // page it follows the balanced columns, so the copy there is fitted to bring it to the foot.
  resource('wards', 'panel', 'table', { styleId: 'results', model: resultsTable() },
    { placement: { position: 'bottom', span: 'page' }, caption: '**How the wards voted**',
      note: 'Red: yes. Grey: no. The black line marks half the vote. '
        + 'Source: Elverdale Town Council.' }),
  // A column 'top' float waits for the head of the next column with room.
  resource('forecast', 'panel', 'table', { styleId: 'forecast', model: forecastTable() },
    { placement: { position: 'top', span: 'column' }, caption: '**The next five days**',
      note: 'Sunrise 6.57, sunset 19.03 on Thursday. Forecast: Wend Valley Weather Station.' }),
];

The photograph is inline in the banner box because a page-wide top float never lands above the line that cites it; as a float, the photo would open page 2 (see Pitfalls). The bridge drawing is inline too, after the paragraph about the pier. The forecast floats to the head of a column and lands at the top of the right one. The ward table floats under both columns, where the column rule stops. On the last page it sits right under the balanced columns, so the copy above it was fitted to bring it down to the foot. Both resource types set captionPrefix: '', and 1.4.1 prints a caption label only when the prefix has text, so no caption starts with "Figure 1".

#6 · An inside page opens on a section flag

script.js · lines 121–139in full code

const section = { enabled: true, slot: { elements: [
  depth(2), // two grid lines: the flag sits on a 3 pt bar, 1.6 mm above the foot
  { kind: 'rule', id: 'bar', thickness: pt(3), color: col('ink'),
    placement: { ...at('#depth', 'align-bottom', 0, -1.6), size: { width: 'fill' } } },
  text('flag', '{titleText}', { ...caps(11, 800, 'paper'), box: { backgroundColor: col('flag'),
    padding: { top: mm(1.3), right: mm(3), bottom: mm(1.1), left: mm(3) } } },
  at('#bar', 'above')),
] } };
const FOLIO = 6; // mm from the top edge to the folio line; its rule 4 mm lower
const folio = (parity, side, s) => [ // s: +1 on a verso (folio on the left), −1 on a recto
  text(`n-${parity}`, '{pageNumber}', { ...franklin(9, 800), align: side },
    at('page', `top-${side}`, s * MARGIN.side, FOLIO)),
  text(`t-${parity}`, '{title} · {publishDate}', { ...caps(7, 600, 'muted'), align: side },
    at(`#n-${parity}`, s > 0 ? 'right-of' : 'left-of', s * 3, 0.9)),
].map((element) => ({ ...element, parity }));
const header = { elements: [...folio('even', 'left', 1), ...folio('odd', 'right', -1),
  { kind: 'rule', id: 'folio-rule', thickness: pt(0.5), color: col('ink'),
    placement: { ...at('page', 'top-left', MARGIN.side, FOLIO + 4), size: { width: mm(TRIM.width
      - 2 * MARGIN.side) } } }] };

# Town & Valley is an H1 whose breakBefore has the parity 'any', so the section opens page 2 without a blank page before it. Its design is a red flag on a 3 pt bar, hung from an empty box two grid lines deep. The folio line is a header anchored 6 mm below the top edge of the page, with one version for even pages and one for odd. The front page's style empties the header, so no folio line prints above the nameplate.

The whole recipe

// ═══ Postext Cookbook · Nº 027 · Newspaper front page ═══════════════════════════
// https://postext.dev/en/cookbook/newspaper-front-page
// Code: MIT · Text: original (CC BY 4.0) · Photo: Jason Blackeye (CC0)
// Fonts: Grenze Gotisch, PT Serif, Libre Franklin (SIL OFL 1.1) · Needs postext ≥ 1.4.1
import {
  buildDocument, renderPageToCanvas, clearMeasurementCache, registerResourceImage,
} from 'https://esm.sh/postext';

const LANG = 'en'; // @lang: the language of the sample document ('en' | 'es')
const RECIPE = 'newspaper-front-page';

// ─── 1 · Design ─────────────────────────────────────────────────────────────
// #region palette: newsprint, ink and one red for the section flags
const palette = {
  ink: '#111315', // text and the heavy rules: a cold near-black
  paper: '#f8f5ee', // newsprint, and type reversed out of ink or red
  flag: '#a6192e', // the one accent: section flags, kickers, the Yes bars
  tint: '#ebe6db', // the In brief strip
  rule: '#9a978f', // hairlines: the column rule, table rules
  muted: '#5d5a55', // bylines, the folio line's title and date, credit notes, the imprint
};
// The hex rides along: 1.4.1 designs read it, not the link (gotcha: palette-skips-designs).
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
const colorPalette = [ // defaults link to 'main-color': point it at the ink, never blue
  ...Object.entries(palette).map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } })),
  { id: 'main-color', name: 'ink (defaults)', value: { hex: palette.ink, model: 'hex' } },
];
// #endregion
const TRIM = { width: 246, height: 328 }; // mm: a 3 : 4 compact, smaller than a tabloid
const MARGIN = { top: 14, bottom: 15, side: 12 }; // newspaper margins: narrow, not mirrored
const GUTTER = 6; // mm between the two body columns, and between the In brief columns
const LEAD = 12.6; // body leading in pt: the baseline grid
const franklin = (size, weight, look = {}) => ({ fontFamily: 'Libre Franklin',
  fontSize: pt(size), fontWeight: weight, color: col('ink'), ...look });
const caps = (size, weight, colour = 'ink') => franklin(size, weight, { color: col(colour),
  textTransform: 'uppercase', letterSpacing: pt(size * 0.16) }); // capitals tracked 0.16 em
const at = (to, edge, x = 0, y = 0) => ({ anchor: { to, edge }, offset: { x: mm(x), y: mm(y) } });
const text = (id, content, look, placement) => ({ kind: 'text', id, content, align: 'left',
  overflow: 'wrap', color: col('ink'), ...look, placement }); // design text defaults to centred,
// black and ellipsized (gotcha: overflow-ellipsis-default)
// A rule across the slot whose bottom sits `gap` mm above the element it names.
const rule = (id, under, weight, gap = 0) => ({ kind: 'rule', id, thickness: pt(weight),
  color: col('ink'), placement: { ...at(under, 'above', 0, -gap), size: { width: 'fill' } } });
// An empty box exactly `lines` grid lines deep sets an opener's depth, and the rest hangs from
// its foot. Ending on a grid line leaves no sliver of column beside the opener, which 1.4.1
// would rule down through the title (gotcha: column-rule-through-opener).
const depth = (lines) => ({ kind: 'box', id: 'depth', style: {}, placement: {
  ...at('container', 'top-left'), size: { width: 'fill', height: pt(lines * LEAD) } } });

// #region nameplate: the front page's H1 is the paper's name, between two ears
const NAME = 52; // pt: the blackletter nameplate
const EAR = 31; // mm: each ear, in the room the nameplate leaves at either side
const EAR_DROP = 1.8; // mm: measured so the ears' big figures sit on the nameplate's baseline
const AIR = 2; // mm between the lower rule and the masthead's foot, where the banner box starts
const ear = (side, lines) => lines.map(([id, content, look], i) => text(id, content,
  { ...look, align: side }, { ...(i === 0 ? at('container', `top-${side}`, 0, EAR_DROP)
    : at(`#${lines[i - 1][0]}`, 'below', 0, 1)), size: { width: mm(EAR) } }));
const serif = { fontFamily: 'PT Serif', fontSize: pt(9), italic: true, color: col('ink'),
  lineHeight: 1.25 }; // a multiple of the size (gotcha: design-lineheight-multiple)
const nameplate = { enabled: true, slot: { elements: [
  depth(7), // the masthead is seven grid lines deep; the rules and dateline hang from its foot
  { kind: 'rule', id: 'foot', thickness: pt(0.5), color: col('ink'),
    placement: { ...at('#depth', 'align-bottom', 0, -AIR), size: { width: 'fill' } } },
  ...[['left', '{attr.issue}'], ['center', '{publishDate}'], ['right', '{attr.area}']].map(
    ([align, content]) => text(`date-${align}`, content, { ...caps(7.5, 600), align },
      { ...at('#foot', 'above', 0, -1.4), size: { width: 'fill' } })),
  rule('thin', '#date-left', 0.5, 1.6), rule('heavy', '#thin', 2.5, 0.6), // the Oxford rule
  text('name', '{titleText}', { fontFamily: 'Grenze Gotisch', fontSize: pt(NAME),
    fontWeight: 700, lineHeight: 1, align: 'center' },
  { ...at('#heavy', 'above', 0, -1.2), size: { width: 'fill' } }), // centred between the ears
  ...ear('left', [['w-kicker', 'Weather', caps(7, 700, 'flag')],
    ['w-outlook', '{attr.outlook}', serif], ['w-temps', '{attr.temps}', franklin(15, 800)]]),
  ...ear('right', [['p-kicker', '{attr.since}', caps(7, 700, 'flag')],
    ['p-day', '{attr.day}', serif], ['p-price', '{attr.price}', franklin(15, 800)]]),
] } };
// hook-up: headingStyles gets { id: 'front', advancedDesign: nameplate, header: { elements:
// [] } }, H1 already spans the page, and the Markdown opens with
// # The Elverdale Courier {style="front" issue="…" area="…" outlook="…" temps="…" since="…"
//   day="…" price="…"}
// #endregion

// #region answer: two body columns at most, so the four-up strip is a box with columns
const layout = { layoutType: 'double', gutterWidth: mm(GUTTER), // the most a body can have
  columnRule: { enabled: true, color: col('rule'), lineWidth: pt(0.5) } };
// Three or more columns live only inside a box: a :::columns group in a :::callout. Its fence
// spans the page and floats the box to the foot, so the story fills the columns above it:
//   :::callout{type="briefs" span="page" placement="bottom" title="In brief"}
//   :::columns{count=4 breaks="2,3,4"}   ← each brief opens a column (child 2, 3 and 4)
//   …four paragraphs…
//   :::
//   :::                                  (gotcha: callout-columns)
// The style could carry span and placement too; on the fence they stay in sight in the text.
// hook-up: config() takes layout as it is and lists briefs in calloutStyles.
const briefs = { id: 'briefs',
  background: col('tint'), // one device: a tint, no stripe or border
  padding: { top: mm(3), right: mm(4), bottom: mm(4), left: mm(4) },
  columnGap: mm(GUTTER), // the inner columns keep the page's gutter
  titleStyle: { ...caps(9, 800, 'flag'), gap: mm(2) },
  body: { fontFamily: 'PT Serif', fontSize: pt(8.6), lineHeight: pt(11.4), textAlign: 'left',
    firstLineIndent: pt(0) } }; // ragged and unindented, unlike the columns
// #endregion

// #region banner: a headline across both columns is a frameless page-span box
// :::callout{type="banner" span="page" title="Transport"} ← an optional kicker, then the H2
const banner = { id: 'banner', backgroundEnabled: false,
  padding: { top: pt(0), right: pt(0), bottom: pt(0), left: pt(0) },
  titleStyle: { ...caps(8, 800, 'flag'), gap: mm(1.2) }, // a kicker, when the fence has a title
  marginTop: pt(0), // flush under the nameplate or the section flag
  marginBottom: pt(LEAD / 2), // half a line, then the columns start on the next grid line
  body: { fontFamily: 'PT Serif', fontSize: pt(13), lineHeight: pt(16.5), textAlign: 'left' } };
// A story that starts mid-page: the same box under a rule. The columns above it are cut level.
const story = { ...banner, id: 'story', marginTop: pt(LEAD),
  stripe: { enabled: true, side: 'top', width: pt(1), color: col('ink') }, // its one device
  padding: { top: mm(2.5), right: pt(0), bottom: pt(0), left: pt(0) } };
// Inside the box the headline is an H2 in a heading style: one size for each rank of story.
const headline = (id, size, look = {}) => ({ id, fontSize: pt(size), lineHeight: pt(size * 1.02),
  marginBottom: pt(size * 0.2), ...look }); // tight leading, a fifth of it below
// #endregion

// #region inside: an inside page opens with a section flag and carries a folio line
const section = { enabled: true, slot: { elements: [
  depth(2), // two grid lines: the flag sits on a 3 pt bar, 1.6 mm above the foot
  { kind: 'rule', id: 'bar', thickness: pt(3), color: col('ink'),
    placement: { ...at('#depth', 'align-bottom', 0, -1.6), size: { width: 'fill' } } },
  text('flag', '{titleText}', { ...caps(11, 800, 'paper'), box: { backgroundColor: col('flag'),
    padding: { top: mm(1.3), right: mm(3), bottom: mm(1.1), left: mm(3) } } },
  at('#bar', 'above')),
] } };
const FOLIO = 6; // mm from the top edge to the folio line; its rule 4 mm lower
const folio = (parity, side, s) => [ // s: +1 on a verso (folio on the left), −1 on a recto
  text(`n-${parity}`, '{pageNumber}', { ...franklin(9, 800), align: side },
    at('page', `top-${side}`, s * MARGIN.side, FOLIO)),
  text(`t-${parity}`, '{title} · {publishDate}', { ...caps(7, 600, 'muted'), align: side },
    at(`#n-${parity}`, s > 0 ? 'right-of' : 'left-of', s * 3, 0.9)),
].map((element) => ({ ...element, parity }));
const header = { elements: [...folio('even', 'left', 1), ...folio('odd', 'right', -1),
  { kind: 'rule', id: 'folio-rule', thickness: pt(0.5), color: col('ink'),
    placement: { ...at('page', 'top-left', MARGIN.side, FOLIO + 4), size: { width: mm(TRIM.width
      - 2 * MARGIN.side) } } }] };
// #endregion

const label = { fontFamily: 'Libre Franklin', fontSize: pt(8), firstLineIndent: pt(0) };
const config = () => ({ // a factory: the engine caches resolved configs per object
  colorPalette, resourceTypes,
  page: { width: mm(TRIM.width), height: mm(TRIM.height), dpi: 150,
    backgroundColor: col('paper'), margins: { top: mm(MARGIN.top), bottom: mm(MARGIN.bottom),
      left: mm(MARGIN.side), right: mm(MARGIN.side) } },
  layout,
  // Hyphenation stays at its defaults: on, in 'en-us'.
  bodyText: { fontFamily: 'PT Serif', fontSize: pt(9.4), lineHeight: pt(LEAD), color: col('ink'),
    // boldColor is restated: :ref labels take it, because 1.4.1 never points referenceColor
    // at main-color (gotcha: palette-skips-designs), and bold in a box copies it before the
    // palette applies. Italics do follow main-color.
    boldColor: col('ink'),
    textAlign: 'justify', firstLineIndent: mm(3.5), indentAfterHeading: false,
    minWordSpacing: 0.75, maxWordSpacing: 1.6, // tighter than the 0.6–2 defaults
    maxRuntTracking: 0 }, // tracking 1.4.1 never paints (gotcha: runt-tracking-unpainted)
  headings: { fontFamily: 'Libre Franklin', fontWeight: 800, // in ink, through main-color
    marginBottom: pt(0), levels: [
      // Restated (gotcha: headings-drop-h1-break); 'any': a section opens the next page.
      { level: 1, span: 'page', breakBefore: { enabled: true, parity: 'any' },
        advancedDesign: section },
      { level: 2, fontSize: pt(17), lineHeight: pt(19) }, // Letters; banners restyle it
      { level: 3, fontSize: pt(10), lineHeight: pt(LEAD), fontWeight: 700, marginTop: pt(LEAD) },
    ] },
  headingStyles: [
    { id: 'front', advancedDesign: nameplate, header: { elements: [] } }, // no folio line
    headline('lead', 56, { fontWeight: 900 }), headline('wide', 30), headline('second', 22),
  ],
  calloutStyles: [banner, story, briefs],
  chipStyles: [{ id: 'flag', background: col('flag'), color: col('paper'), borderWidth: pt(0),
    borderRadius: pt(0), fontFamily: 'Libre Franklin', fontSize: em(0.875), bold: true,
    paddingX: em(0.4), paddingY: em(0.15) }],
  paragraphStyles: [{ ...label, id: 'byline', textAlign: 'left', color: col('muted') },
    { id: 'flush', firstLineIndent: pt(0) }, // a story's first paragraph, the second letter
    { ...label, id: 'jump', textAlign: 'right' }, // "…: page 2", where a story turns
    { id: 'sign', textAlign: 'right', firstLineIndent: pt(0) }, // a letter's signature
    { id: 'imprint', fontFamily: 'Libre Franklin', fontSize: pt(6.8), lineHeight: pt(9),
      textAlign: 'left', firstLineIndent: pt(0), color: col('muted'), marginTop: pt(LEAD) }],
  captionStyle: { fontFamily: 'Libre Franklin', fontSize: pt(8), gap: mm(1.6),
    note: { fontSize: pt(6.8), color: col('muted') } }, // the credit line
  tableStyle: { rules: 'horizontal', borderColor: col('rule'), borderWidth: pt(0.5),
    headerBackground: col('ink'), headerColor: col('paper'), headerFontFamily: 'Libre Franklin',
    headerFontSize: pt(7.5), bodyFontFamily: 'Libre Franklin', bodyFontSize: pt(8.5),
    cellPadding: mm(1.3) },
  tableStyles: [{ id: 'results', cellPadding: mm(1) }, // tighter rows: the bars read as one chart
    { id: 'forecast', headerBackground: col('flag'), bodyFontSize: pt(8), // the weather box
      cellPadding: mm(1.2) }],
  header, footer: { elements: [] }, // newspapers put the folio at the head, if anywhere
});

// ─── 2 · Content ────────────────────────────────────────────────────────────
// #region art: the two tables as data, and the bridge and the ward bars drawn in code
const WARDS = [ // Tuesday's parish poll: yes, no (they add up to 3,904 and 2,393)
  ['Market', 942, 418], ['Riverside', 861, 402], ['St Oswald’s', 896, 471],
  ['Brook Lane', 736, 591], ['Harrow', 469, 511]];
const cell = (content, extra = {}) => ({ content, ...extra });
const head = (content, align = 'left') => cell(content, { isHeader: true, align });
const num = (n) => n.toLocaleString('en-GB');
const share = (yes, no) => `${Math.round((100 * yes) / (yes + no))}%`;
function barSvg(yes, no) { // 1000 × 34 units: yes in red from the left, no in grey, 50% marked
  const split = (1000 * yes) / (yes + no);
  return '<svg xmlns="http://www.w3.org/2000/svg" width="1000" height="34" viewBox="0 0 1000 34">'
    + `<rect width="${split.toFixed(1)}" height="34" fill="${palette.flag}"/>`
    + `<rect x="${(split + 4).toFixed(1)}" width="${(996 - split).toFixed(1)}" height="34" `
    + `fill="${palette.rule}"/><rect x="499" y="-1" width="2" height="36" fill="${palette.ink}"/>`
    + '</svg>';
}
const TOWN = WARDS.reduce(([, y, n], [, yes, no]) => ['Whole town', y + yes, n + no], ['', 0, 0]);
const bars = [...WARDS, TOWN].map(([ward, yes, no], i) => ({ ward, yes, no,
  id: i < WARDS.length ? `bar-${i + 1}` : 'bar-town', svg: barSvg(yes, no) })); // one per row
function mulberry32(seed) { // a seeded PRNG: the same stones on every run
  return () => {
    seed = (seed + 0x6d2b79f5) | 0;
    let r = Math.imul(seed ^ (seed >>> 15), 1 | seed);
    r = (r + Math.imul(r ^ (r >>> 7), 61 | r)) ^ r;
    return ((r ^ (r >>> 14)) >>> 0) / 4294967296;
  };
}
const channel = (hex, i) => parseInt(hex.slice(i, i + 2), 16);
const mix = (a, b, k) => `#${[1, 3, 5].map((i) => Math.round(channel(a, i) * (1 - k)
  + channel(b, i) * k).toString(16).padStart(2, '0')).join('')}`; // a towards b by k
function bridgeSvg() { // 119 × 46 mm, 1 unit = 1 mm, about 2.6 mm to the metre
  const rand = mulberry32(1791); // the year the bridge was built, as far as the Courier knows
  const f = (v) => v.toFixed(2);
  const [W, H, TOP, DECK, WATER, BED] = [119, 46, 4.5, 8, 25, 30]; // heights from the top, mm
  const stone = mix(palette.tint, palette.muted, 0.35);
  const joint = mix(palette.tint, palette.ink, 0.55);
  const arches = [[16, 57], [62, 103]]; // two spans; the central pier stands between them
  const [SPRING, CROWN] = [WATER - 7, 13]; // the arches spring 7 mm above the water
  const CTRL = 2 * CROWN - SPRING; // the Bézier control point that puts the top at CROWN
  // The banks: road level at each end, down under the outer half of each arch to the water's
  // edge, 24 mm in, and on at the same slope to the bed.
  const EDGE = 24;
  const run = ((BED - WATER) * (EDGE - 10)) / (WATER - DECK);
  const bank = [[0, DECK], [10, DECK], [EDGE, WATER], [EDGE + run, BED]];
  const profile = [...bank, ...bank.map(([x, y]) => [W - x, y]).reverse()];
  const groundAt = (x) => { // the height of the ground at x, between two profile points
    const i = profile.findIndex(([px]) => px >= x);
    if (i <= 0) return profile[Math.max(i, 0)][1];
    const [[x0, y0], [x1, y1]] = [profile[i - 1], profile[i]];
    return y0 + ((y1 - y0) * (x - x0)) / (x1 - x0);
  };
  const water = mix(palette.paper, palette.ink, 0.14);
  let out = `<rect x="0" y="${WATER}" width="${W}" height="${BED - WATER}" fill="${water}"/>`;
  out += `<path d="M${EDGE} ${WATER}H${W - EDGE}" stroke="${palette.muted}" stroke-width="0.3"/>`;
  for (let i = 0; i < 9; i++) { // ripples on the river, between the banks
    const [x, y] = [EDGE + 3 + rand() * (W - 2 * EDGE - 12),
      WATER + 1.2 + rand() * (BED - WATER - 2.4)];
    out += `<path d="M${f(x)} ${f(y)}h${f(3 + rand() * 5)}" stroke="${palette.paper}" `
      + 'stroke-width="0.4"/>';
  }
  // The masonry: parapet to riverbed, less the two arch openings (even-odd fill). The banks
  // are drawn over it, so only the stone above the ground shows.
  const opening = ([a, b]) => `M${a} ${BED}L${a} ${SPRING}Q${(a + b) / 2} ${CTRL} `
    + `${b} ${SPRING}L${b} ${BED}Z`;
  const outline = `M4 ${BED}L10 ${DECK}V${TOP}H${W - 10}V${DECK}L${W - 4} ${BED}`;
  out += `<path fill-rule="evenodd" fill="${stone}" `
    + `d="${outline}Z${arches.map(opening).join('')}"/>`;
  // Where the masonry is at height y: inside the sloping ends, outside the arch openings.
  const solid = (x, y) => {
    const end = y < DECK ? 10 : 10 - (6 * (y - DECK)) / (BED - DECK);
    if (x < end || x > W - end) return false;
    return !arches.some(([a, b]) => { // the opening's half width at y (a parabola)
      const c = (SPRING - y) / (2 * (SPRING - CTRL)); // t(1 − t) at height y
      const half = c <= 0 ? 0.5 : c >= 0.25 ? -1 : Math.sqrt(0.25 - c);
      return Math.abs(x - (a + b) / 2) <= half * (b - a);
    });
  };
  for (let y = TOP + 2.2; y < BED; y += 2.2) { // courses of stone, joints staggered
    for (let x = 4; x < W - 4; x += 0.5) {
      if (solid(x, y) && solid(x + 0.5, y)) {
        out += `<path d="M${f(x)} ${f(y)}h0.5" stroke="${joint}" stroke-width="0.2"/>`;
      }
    }
    for (let x = 4 + rand() * 4; x < W - 6; x += 3 + rand() * 4) {
      if (solid(x, y) && solid(x, y - 2.2)) {
        out += `<path d="M${f(x)} ${f(y - 2.2)}v2.2" stroke="${joint}" stroke-width="0.2"/>`;
      }
    }
  }
  for (const [a, b] of arches) { // the voussoirs: a ring of stones round each opening
    const cx = (a + b) / 2;
    for (let t = 0; t <= 1.0001; t += 1 / 14) {
      const x = a + (b - a) * t;
      const y = SPRING - 2 * t * (1 - t) * (SPRING - CTRL);
      const [dx, dy] = [x - cx, y - (WATER + 2)];
      const k = 3 / Math.hypot(dx, dy);
      out += `<path d="M${f(x)} ${f(y)}l${f(dx * k)} ${f(dy * k)}" stroke="${joint}" `
        + 'stroke-width="0.25"/>';
    }
    out += `<path d="${opening([a, b]).replace(/Z$/, '')}" fill="none" stroke="${palette.ink}" `
      + 'stroke-width="0.35"/>';
  }
  out += `<path d="${outline}" fill="none" stroke="${palette.ink}" stroke-width="0.4"/>`;
  // The ground in section: the banks and the riverbed, hatched below the profile.
  const edge = profile.map(([x, y]) => `${f(x)} ${f(y)}`).join('L');
  out += `<path d="M${edge}L${W} ${H}L0 ${H}Z" fill="${palette.paper}"/>`;
  for (let x0 = -H; x0 < W; x0 += 1.6) { // 45° hatching, cut where it leaves the ground
    let from = null;
    for (let t = 0; t <= H + 0.05; t += 0.1) {
      const [x, y] = [x0 + t, H - t];
      const inside = x >= 0 && x <= W && y > groundAt(x);
      if (inside && !from) from = [x, y];
      if (from && (!inside || t + 0.1 > H + 0.05)) {
        out += `<path d="M${f(from[0])} ${f(from[1])}L${f(x - 0.1)} ${f(y + 0.1)}" `
          + `stroke="${palette.rule}" stroke-width="0.25"/>`;
        from = null;
      }
    }
  }
  out += `<path d="M${edge}" fill="none" stroke="${palette.muted}" stroke-width="0.3"/>`
    + `<rect x="55.5" y="${BED}" width="8" height="15.6" fill="${palette.flag}"/>` // 6 m deep
    + `<path d="M9.4 ${TOP}H${W - 9.4}" stroke="${palette.ink}" stroke-width="1.2"/>`; // coping
  return `<svg xmlns="http://www.w3.org/2000/svg" width="${W * 10}" height="${H * 10}" `
    + `viewBox="0 0 ${W} ${H}">${out}</svg>`;
}
function resultsTable() {
  const row = (name, yes, no, bar, bold = '') => [cell(`${bold}${name}${bold}`),
    cell('', { image: { resourceId: bar } }), cell(`${bold}${num(yes)}${bold}`,
      { align: 'right' }), cell(`${bold}${num(no)}${bold}`, { align: 'right' }),
    cell(`${bold}${share(yes, no)}${bold}`, { align: 'right' })];
  return { headerRowCount: 1, columnWidths: [22, 110, 14, 14, 14], rows: [
    [head('Ward'), head('Share of the vote'), head('Yes', 'right'),
      head('No', 'right'), head('Yes share', 'right')],
    ...bars.map((b) => row(b.ward, b.yes, b.no, b.id, b.id === 'bar-town' ? '**' : ''))] };
}
function forecastTable() {
  const days = [['Thu', 'Bright spells', 16, 8, 'W 18'], ['Fri', 'Showers', 14, 9, 'W 22'],
    ['Sat', 'Heavy rain', 12, 9, 'SW 30'], ['Sun', 'Clearing', 13, 6, 'NW 20'],
    ['Mon', 'Sunny, cold start', 15, 4, 'N 8']];
  return { headerRowCount: 1, columnWidths: [10, 40, 12, 12, 16], rows: [
    [head('Day'), head('Outlook'), head('High', 'right'), head('Low', 'right'),
      head('Wind mph', 'right')],
    ...days.map(([day, sky, hi, lo, wind]) => [cell(`**${day}**`), cell(sky),
      cell(`${hi}°`, { align: 'right' }), cell(`${lo}°`, { align: 'right' }),
      cell(wind, { align: 'right' })])] };
}
// #endregion

// #region floats: the photo sits in its box, the results float to a foot, the forecast to a head
// A caption label prints only when captionPrefix has text: '' leaves no "Figure 1".
const unnumbered = (id, name, captionStyle) => ({ id, name, shortLabel: name, captionPrefix: '',
  numberingTemplate: '', resetOn: 'never', counterFormat: 'decimal', captionStyle });
const resourceTypes = [unnumbered('picture', 'Picture'), // captions under the picture
  unnumbered('panel', 'Panel', { position: 'above', fontSize: pt(9.5) })]; // tables: titled above
const resource = (id, typeId, kind, body, extra) => ({ id, typeId, kind, [kind]: body,
  createdAt: 0, updatedAt: 0, ...extra });
const resources = [
  // Set inline in the page-span banner box: a 'top' float never lands above the line that
  // cites it (gotcha: top-float-next-page). A :::space gives it air (gotcha: box-embed-no-gap).
  // 2400 px at 150 dpi is 406 mm: the photo shrinks to the box (gotcha: bitmap-print-size).
  resource('ridge', 'picture', 'bitmap', { fileId: 'ridge-2400.jpg', format: 'jpeg', width: 2400,
    height: 800 }, { placement: { position: 'here' },
    altText: 'Wind turbines on a snow-covered ridge under a bright, cloudy sky.',
    caption: '**File picture:** turbines on an upland ridge. Each of the three planned for '
      + 'Harrow Ridge would generate 2.3 megawatts.',
    note: 'Photograph: Jason Blackeye, CC0, via Wikimedia Commons' }),
  // Drawn in code (the art region) and set inline, where ::resource puts it in column 1.
  resource('bridge', 'picture', 'svg', { fileId: 'bridge.svg', width: 1190, height: 460 },
    { placement: { position: 'here' },
      altText: 'Drawing of a two-arch stone bridge between sloping river banks; under its '
        + 'central pier, a red concrete footing.',
      caption: '**The rebuilt pier.** Its new concrete footing (red) goes six metres below the '
        + 'riverbed. Both arches were relaid with their own stones.',
      note: 'Drawing: The Courier' }),
  // A page-span 'bottom' float sits under both columns of the page that cites it. On the last
  // page it follows the balanced columns, so the copy there is fitted to bring it to the foot.
  resource('wards', 'panel', 'table', { styleId: 'results', model: resultsTable() },
    { placement: { position: 'bottom', span: 'page' }, caption: '**How the wards voted**',
      note: 'Red: yes. Grey: no. The black line marks half the vote. '
        + 'Source: Elverdale Town Council.' }),
  // A column 'top' float waits for the head of the next column with room.
  resource('forecast', 'panel', 'table', { styleId: 'forecast', model: forecastTable() },
    { placement: { position: 'top', span: 'column' }, caption: '**The next five days**',
      note: 'Sunrise 6.57, sunset 19.03 on Thursday. Forecast: Wend Valley Weather Station.' }),
];
// #endregion
resources.push(...bars.map((b) => resource(b.id, 'panel', 'svg', // the bars the table cells draw
  { fileId: `${b.id}.svg`, width: 1000, height: 34 },
  { altText: `${b.ward}: ${num(b.yes)} yes, ${num(b.no)} no` })));
const markdown = String.raw`---
Markdown sample · 124 lines · content.en.md
title: "The Elverdale Courier"
author: "The Elverdale Courier"
publishDate: "Thursday 24 September 2026"
---

# The Elverdale Courier {style="front" issue="Vol. 116 · No. 39" area="Elverdale, Harrow and the Upper Wend" outlook="Bright spells, breezy" temps="16° · 8°" since="Est. 1911" day="Every Thursday" price="90p"}

:::callout{type="banner" span="page"}
## Harrow Ridge turbines win the town’s vote {style="lead"}

*Elverdale backs its own wind farm by 62% on a 71% turnout. Now the cooperative must raise £9.8 million*

:::space{lines=0.5}

::resource{id="ridge"}
:::

:::callout{type="briefs" span="page" placement="bottom" title="In brief"}
:::columns{count=4 breaks="2,3,4"}
:chip[TRANSPORT]{style="flag"} **Bus 44 back on Sundays.** The Elverdale to Kirkby bus will run every two hours on Sundays from 4 October, paid for by the county for a year. The first leaves the Market Place at 8.10.

:chip[SCHOOLS]{style="flag"} **An orchard for Brook Lane.** Pupils at Brook Lane Primary planted 24 apple and pear trees on Friday, all of them varieties grown in the valley before 1900.

:chip[ARTS]{style="flag"} **Book Weekend full.** Every ticket for the fourteen events of the Book Weekend, 9 to 11 October, has gone. The Saturday talks will be screened free in the Corn Exchange.

:chip[COUNCIL]{style="flag"} **Bin day moves.** Recycling north of the river goes out on Tuesdays instead of Mondays, starting in the week of 5 October. New calendars come with next week’s Courier.
:::
:::

:::paragraphs{style="byline"}
By **Martha Quayle** · Local Democracy Reporter
:::

:::paragraphs{style="flush"}
Elverdale will build a wind farm of its own. In the first town-wide poll since the 1974 vote to save the Corn Exchange, 3,904 residents backed plans for three turbines on Harrow Ridge, and 2,393 voted against.
:::

The count at the Corn Exchange finished shortly before midnight on Tuesday. Turnout was 71%, the highest the town clerk, Anjali Rees, can remember at any election. “People queued in the rain outside St Oswald’s,” she said. “We ran out of pencils at eleven.” The last ballot box, from Harrow, came in at twenty to ten.

The scheme belongs to Wend Valley Energy, a cooperative that residents formed in 2023 so that the wind on the ridge would pay the valley rather than a distant landlord. Its three turbines of 2.3 megawatts each would supply about 6,500 homes in an average year, far more than the 4,700 in the parish.

### Who pays and who gains

The cooperative must now raise £9.8 million. A share offer opens next Thursday, with a minimum stake of £50. It hopes to find £2.4 million in the valley and to borrow the rest from a community energy lender. Members would earn up to 4% a year, and £120,000 a year would go to a town fund, spent by a panel that residents elect.

“Two thousand households putting in £1,200 each would do it,” said Tom Ashby, who chairs the cooperative and farms at Low Harrow. “We had 312 pledges by Wednesday lunchtime.”

### Objectors turn to the planners

The Harrow Ridge Action Group, which campaigned against the scheme, says the turbines, 125 metres to the tip of the blade, will dominate the view from the Wend Way and disturb the curlews that nest on the moor.

“A poll is not a planning permission,” said its secretary, Clare Whitlock. “We will make our case to the district council, and we expect to be heard.”

The planning application is due in the spring, after a year of bird and wind surveys. If it succeeds, work could start in 2028, and the turbines would be turning by the autumn of 2029. The cooperative’s 640 founding members have paid £180,000 for the surveys.

:::paragraphs{style="jump"}
How each ward voted, and what happens next: **page 2**
:::

# Town & Valley

:::callout{type="banner" span="page" title="Transport"}
## Old Mill Bridge reopens after 14 months {style="wide"}

*Cars, buses and the Saturday market cross the Wend again. Lorries must wait for a load test next spring*
:::

:::paragraphs{style="byline"}
By **Owen Pryce**
:::

:::paragraphs{style="flush"}
The Old Mill Bridge reopened to traffic at seven o’clock on Monday morning, fourteen months after the flood of July 2025 scoured out the footing of its central pier and cracked both of its arches.
:::

The repair cost £1.9 million, most of it from the county council’s flood recovery fund. Engineers rebuilt the pier on a new concrete footing sunk six metres into the riverbed, and relaid the arches with 3,100 of their own stones, each one numbered as it came down and set back in the same place.

::resource{id="bridge"}

It reopened five days before the first storm of the autumn. Heavy rain is forecast for Saturday :ref{id="forecast" text="(Weather, right)"}, and the county’s engineers will be on the bridge to watch the river rise.

The first vehicle across was Keith Barlow’s dairy van, which has spent more than a year on the eleven-mile detour through Kirkby. “Forty minutes each way, six days a week,” he said. “I’d rather not add it up.”

The bridge is open to cars, vans and buses, and closed to goods vehicles over 7.5 tonnes. The county says heavy traffic had weakened the old structure long before the flood, and it will not let lorries back until the new pier has passed a load test next spring.

That has disappointed some traders. “It’s half a bridge for us,” said Priya Chandra, who runs the builders’ merchant on Mill Lane. “Our timber still comes round by Kirkby, eleven miles each way.”

For the market, it came just in time. Stallholders from the south bank have carried their stock over the footbridge for a year, and Saturday’s market will be the first in more than a year with every pitch taken.

:::callout{type="story" span="page" title="The wind farm vote"}
## Harrow was the one ward to say no {style="second"}
:::

:::paragraphs{style="flush"}
Every ward but one voted for the wind farm in Tuesday’s poll. Market gave it the biggest majority, with 69% voting yes, and Brook Lane the smallest, 736 votes to 591 :ref{id="wards" text="(Results, below)"}.
:::

Harrow, the ward beneath the ridge, voted against by 511 votes to 469, on a turnout of 76%, the highest of the five wards. “Most of the people who voted no can see the ridge from their front doors,” said its councillor, Ruth Okafor, who has asked the cooperative to meet Harrow residents before the application goes in. The first meeting is on 8 October.

Tom Ashby, the cooperative’s chair, said it had expected Harrow to be the hardest ward to win. He has offered to move the nearest turbine 200 metres further from the village, which would cost about 4% of its output, and will put both sites to Harrow residents at the October meeting.

The poll does not bind the district council, which expects to decide the planning application in the summer of 2027. Anyone may comment on it for 21 days after it is published.

:::columnbreak

## Letters

**Tea at the count.** I was one of 22 volunteers who sorted 6,297 ballots in the Corn Exchange on Tuesday night. When the urn ran dry at ten, the cricket club lent us theirs, and we finished at a quarter to twelve. Thank you to the Rotary Club for the sandwiches, and to whoever left a tin of flapjacks on the returning officer’s table.

:::paragraphs{style="sign"}
*Margaret Oyelaran, Brook Lane*
:::

:::paragraphs{style="flush"}
**The view belongs to all of us.** Those of us who walk the Wend Way every week were outvoted by people who have never climbed the ridge. I counted eleven pairs of curlews up there in May. I hope the district council will remember that the moor is not the town’s to sell, whatever the count says.
:::

:::paragraphs{style="sign"}
*David Hurst, Low Harrow*
:::

:::paragraphs{style="imprint"}
An imaginary weekly. Text CC BY 4.0. Set in Grenze Gotisch, PT Serif and Libre Franklin (SIL OFL).
:::
`; // content.en.md, inlined by the Cookbook

// ─── 3 · Fonts ──────────────────────────────────────────────────────────────
const FONTS = { // text, display and label faces, loaded before the build (gotcha: fonts-first)
  'PT Serif': ['400', '400i', '700'], 'Grenze Gotisch': ['700'],
  'Libre Franklin': ['400', '600', '700', '800', '900'] };

// ─── 4 · Build & show ───────────────────────────────────────────────────────
await loadFonts(FONTS, markdown);
await Promise.all([loadImage('ridge-2400.jpg', asset('ridge-2400.jpg')),
  loadSvg('bridge.svg', bridgeSvg()), ...bars.map((b) => loadSvg(`${b.id}.svg`, b.svg))]);
const doc = await buildWithFonts(() => buildDocument({ markdown, resources }, config()), markdown);
showPages(doc, { title: 'Newspaper front page' });

Kit · core, fonts, viewer, images: the same in every recipe · 270 lines
// ─── Kit ── helpers shared by every Cookbook recipe · postext.dev/cookbook ─────

// ─── Kit · core v1 ── the same in every recipe · postext.dev/cookbook ─────────
function mm(value) { return { value, unit: 'mm' }; }
function pt(value) { return { value, unit: 'pt' }; }
function em(value) { return { value, unit: 'em' }; }
/** The sample language's string: t({ en: 'Figure', es: 'Figura' }). */
function t(strings) { return strings[LANG] ?? Object.values(strings)[0]; }
/** A file in this recipe's assets folder, served from the Postext repo by jsDelivr. */
function asset(file) { return `https://cdn.jsdelivr.net/gh/drnachio/postext@main/cookbook/${RECIPE}/assets/${file}`; }

// ─── Kit · fonts v1 ── the same in every recipe · postext.dev/cookbook ────────
// Postext measures text with the faces the browser has loaded, and caches the
// widths, so every face must be ready before the first build. Faces come from
// Fontsource: the same static files the PDF embeds, so screen and PDF agree.

/** faces = { 'Family Name': ['400', '400i', '700'] }. `text` is the sample:
 *  letters beyond Latin-1 (č, ł, ő…) also load the latin-ext files. With
 *  `optional`, a face Fontsource does not ship is skipped instead of failing.
 *  Resolves to the number of faces added. */
async function loadFonts(faces, text = '', { optional = false } = {}) {
  kitStatus('Loading fonts…');
  const ranges = {
    latin: 'U+0000-00FF,U+0131,U+0152-0153,U+02BB-02BC,U+02C6,U+02DA,U+02DC,U+0304,U+0308,U+0329,'
      + 'U+2000-206F,U+20AC,U+2122,U+2191,U+2193,U+2212,U+2215,U+FEFF,U+FFFD',
    'latin-ext': 'U+0100-02BA,U+02BD-02C5,U+02C7-02CC,U+02CE-02D7,U+02DD-02FF,U+0304,U+0308,U+0329,'
      + 'U+1D00-1DBF,U+1E00-1E9F,U+1EF2-1EFF,U+2020,U+20A0-20AB,U+20AD-20C0,U+2113,U+2C60-2C7F,U+A720-A7FF',
  };
  const subsets = /[Ā-˿Ḁ-ỿ]/.test(text) ? ['latin', 'latin-ext'] : ['latin'];
  const jobs = [];
  let added = 0;
  for (const [family, specs] of Object.entries(faces)) {
    const id = fontsourceId(family);
    const meta = optional ? await fontsourceMeta(family) : null;
    for (const spec of new Set(specs)) {
      const weight = parseInt(spec, 10);
      const style = spec.endsWith('i') ? 'italic' : 'normal';
      if (hasFace(family, weight, style)) continue;
      if (optional && !(meta?.weights.includes(weight) && meta.styles.includes(style))) continue;
      for (const subset of subsets) {
        const url = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-${subset}-${weight}-${style}.woff2`;
        const face = new FontFace(family, `url(${url}) format('woff2')`,
          { weight: String(weight), style, unicodeRange: ranges[subset] });
        jobs.push(face.load().then((ready) => { document.fonts.add(ready); added++; }, () => {
          if (subset === 'latin' && !optional) throw new Error(`Fontsource has no ${family} ${weight} ${style}`);
        }));
      }
    }
  }
  await Promise.all(jobs).catch((error) => { kitFail(error); throw error; });
  return added;
}

/** Runs `build` (a buildDocument or buildBundle call) and checks the faces
 *  the pages use. A regular face missing from FONTS is loaded with a warning;
 *  bold and italic variants are loaded when the family ships them. Then the
 *  measurement caches are cleared and the build runs again. */
async function buildWithFonts(build, text = '') {
  const tried = new Set();
  for (let round = 0; round < 3; round++) {
    kitStatus('Laying out…');
    await new Promise(requestAnimationFrame);          // let the status paint first
    const result = await Promise.resolve().then(build).catch((error) => { kitFail(error); throw error; });
    const wanted = { base: {}, variants: {} };
    for (const { font, base } of [result].flat().flatMap(fontStringsOf)) {
      const { family, weight, style } = parseFont(font);
      const key = `${family}|${weight}|${style}`;
      if (tried.has(key) || hasFace(family, weight, style)) continue;
      tried.add(key);
      (wanted[base ? 'base' : 'variants'][family] ??= []).push(`${weight}${style === 'italic' ? 'i' : ''}`);
    }
    if (Object.keys(wanted.base).length) {
      console.warn(`[cookbook] FONTS does not list ${JSON.stringify(wanted.base)}: loading them.`);
    }
    const added = await loadFonts(wanted.base, text) + await loadFonts(wanted.variants, text, { optional: true });
    if (added === 0) return result;
    clearMeasurementCache();
  }
  throw new Error('The fonts did not settle after three builds.');
}

/** Every font string of the layout. `base` marks a block's own face; its
 *  bold, italic and bold-italic variants are listed whether or not used. */
function fontStringsOf(doc) {
  const found = new Map();
  const walk = (node) => {
    if (!node || typeof node !== 'object') return;
    if (Array.isArray(node)) { node.forEach(walk); return; }
    for (const [key, value] of Object.entries(node)) {
      if (typeof value === 'string' && /fontString$/i.test(key)) {
        found.set(value, found.get(value) || key === 'fontString');
      } else if (value && typeof value === 'object') walk(value);
    }
  };
  walk(doc.pages);
  walk(doc.blocks);
  return [...found].map(([font, base]) => ({ font, base }));
}

/** '700 37.5px Open Sans' / 'italic 400 13px "Source Serif 4"' → { family, weight, style }.
 *  A string with no weight ('95.8px Young Serif', from a design text) is 400. */
function parseFont(font) {
  const m = /^(?:(italic|oblique)\s+)?(?:small-caps\s+)?(?:(\d+|bold|normal)\s+)?[\d.]+px\s+(.+)$/.exec(font.trim());
  if (!m) throw new Error(`Unexpected font string: ${font}`);
  const weight = m[2] === 'bold' ? 700 : !m[2] || m[2] === 'normal' ? 400 : Number(m[2]);
  return { family: m[3].replace(/^["']|["']$/g, ''), weight, style: m[1] ? 'italic' : 'normal' };
}

/** True when a loaded FontFace covers exactly this family, weight and style
 *  (document.fonts.check() is also true for families nobody declared). */
function hasFace(family, weight, style) {
  for (const face of document.fonts) {
    if (face.status !== 'loaded' || face.style !== style) continue;
    if (face.family.replace(/^["']|["']$/g, '') !== family) continue;
    const [low, high = low] = face.weight.split(' ').map(Number);
    if (weight >= low && weight <= high) return true;
  }
  return false;
}

/** Fontsource's id for a family: 'Source Serif 4' → 'source-serif-4'. */
function fontsourceId(family) { return family.toLowerCase().replace(/\s+/g, '-'); }

/** The weights and styles a family ships ({ weights: [400, 700], styles: ['normal', 'italic'] }), or null. */
function fontsourceMeta(family) {
  fontsourceMeta.cache ??= new Map();
  const id = fontsourceId(family);
  if (!fontsourceMeta.cache.has(id)) {
    fontsourceMeta.cache.set(id, fetch(`https://api.fontsource.org/v1/fonts/${id}`)
      .then((res) => (res.ok ? res.json() : null), () => null));
  }
  return fontsourceMeta.cache.get(id);
}

// ─── Kit · viewer v1 ── the same in every recipe · postext.dev/cookbook ───────
/** Shows the pages as facing spreads on a dark desk: the first page is a
 *  recto on its own, then verso | recto pairs, as in a bound book. Pages
 *  are painted when they scroll near the screen. */
function showPages(docs, { title, width = 460 } = {}) {
  const root = viewer(title);
  const pages = [docs].flat().flatMap((doc) =>
    doc.pages.map((page) => ({ doc, page, n: (doc.pageIndexOffset ?? 0) + page.index })));
  const spreads = [];
  let verso = null;
  for (const p of pages) {
    if (p.n % 2 === 1) { if (verso) spreads.push([verso, null]); verso = p; }
    else { spreads.push([verso, p]); verso = null; }
  }
  if (verso) spreads.push([verso, null]);
  const density = Math.min(window.devicePixelRatio || 1, 2);
  showPages.painter?.disconnect();
  const painter = new IntersectionObserver((entries) => {
    for (const { isIntersecting, target } of entries) {
      if (!isIntersecting) continue;
      painter.unobserve(target);
      const { doc, page } = target.postext;
      renderPageToCanvas(page, doc, target, { scale: (width * density) / page.width });
    }
  }, { rootMargin: '800px' });
  showPages.painter = painter;
  root.replaceChildren(...spreads.map((pair) => {
    const spread = document.createElement('div');
    spread.className = 'pt-spread';
    for (const p of pair) {
      const figure = document.createElement('figure');
      if (p) {
        const label = p.page.pageLabel || String(p.n + 1);
        const canvas = document.createElement('canvas');
        canvas.postext = p;
        canvas.style.aspectRatio = `${p.page.width} / ${p.page.height}`;
        canvas.setAttribute('role', 'img');
        canvas.setAttribute('aria-label', `Page ${label}`);
        const folio = document.createElement('figcaption');
        folio.textContent = label;
        figure.append(canvas, folio);
        painter.observe(canvas);
      } else figure.className = 'pt-blank';
      spread.append(figure);
    }
    return spread;
  }));
  kitStatus(`${pages.length} ${pages.length === 1 ? 'page' : 'pages'}`);
  document.documentElement.dataset.postext = 'ready';
  return pages.length;
}

/** The desk, the bar and the error reporting, created once. */
function viewer(title) {
  if (!document.getElementById('pt-kit')) {
    document.head.insertAdjacentHTML('beforeend', `<style id="pt-kit">
      :root { color-scheme: dark; }
      body { margin: 0; background: #0e1014; color: #b9bcc4; font: 13px/1.45 system-ui, sans-serif; }
      #pt-bar { position: sticky; top: 0; z-index: 1; display: flex; flex-wrap: wrap; align-items: center;
        gap: 6px 16px; padding: 10px 16px; background: rgb(14 16 20 / .92); backdrop-filter: blur(6px);
        border-bottom: 1px solid #23262d; }
      #pt-bar strong { color: #f4f1ea; font-weight: 600; }
      #pt-actions { display: flex; gap: 12px; margin-left: auto; }
      #pt-actions a, #pt-actions button { color: #d8a21a; font: inherit; background: none; border: 0; padding: 0; cursor: pointer; }
      #pages { display: grid; justify-items: center; gap: 48px; padding: 32px 16px 72px; }
      .pt-spread { display: flex; }
      .pt-spread figure { margin: 0; width: min(460px, 44vw); }
      .pt-spread canvas { display: block; width: 100%; background: #fff;
        box-shadow: 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figure:first-child canvas { box-shadow: inset -14px 0 14px -14px rgb(0 0 0 / .18), 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figcaption { margin-top: 10px; text-align: center; font: 600 10px/1 system-ui, sans-serif;
        letter-spacing: .18em; text-transform: uppercase; color: #6c7079; }
      .pt-blank { visibility: hidden; }
      @media (max-width: 760px) {
        .pt-spread { flex-direction: column; gap: 32px; }
        .pt-spread figure { width: min(460px, 92vw); }
        .pt-blank { display: none; }
      }
    </style>`);
    document.body.insertAdjacentHTML('afterbegin',
      '<header id="pt-bar"><strong id="pt-title"></strong><span id="pt-status" role="status"></span><span id="pt-actions"></span></header>');
    document.getElementById('pt-title').textContent = document.title || 'Postext';
    addEventListener('error', (event) => kitFail(event.error ?? event.message));
    addEventListener('unhandledrejection', (event) => kitFail(event.reason));
  }
  if (title) document.getElementById('pt-title').textContent = title;
  return document.getElementById('pages')
    ?? document.body.appendChild(Object.assign(document.createElement('main'), { id: 'pages' }));
}

function kitStatus(text) {
  viewer();
  document.getElementById('pt-status').textContent = text;
}

function kitFail(error) {
  document.documentElement.dataset.postext = 'error';
  kitStatus(`Error: ${error?.message ?? error}`);
}

// ─── Kit · images v1 ── recipes with pictures · postext.dev/cookbook ──────────
/** Registers a photo or PNG for the canvas and keeps its bytes for the PDF.
 *  fetch → ImageBitmap never taints the canvas (a plain cross-origin <img> would). */
async function loadImage(fileId, url) {
  const res = await fetch(url);
  if (!res.ok) throw new Error(`Image not found (${res.status}): ${url}`);
  const bytes = new Uint8Array(await res.arrayBuffer());
  registerResourceImage(fileId, await createImageBitmap(new Blob([bytes])));
  (loadImage.bytes ??= new Map()).set(fileId, bytes);
}

/** Registers SVG markup (drawn in code, or fetched) as a vector image. */
async function loadSvg(fileId, svg) {
  const img = new Image();
  await img.decode();
  registerResourceImage(fileId, img);
  (loadImage.bytes ??= new Map()).set(fileId, new TextEncoder().encode(svg));
}

/** renderToPdf({ resourceBytes: imageBytes }) */
function imageBytes(fileId) { return loadImage.bytes?.get(fileId); }

/** renderToHtml({ resourceImageUrl: imageUrl }) */
function imageUrl(fileId) {
  const bytes = imageBytes(fileId);
  if (!bytes) return undefined;
  imageUrl.urls ??= new Map();
  if (!imageUrl.urls.has(fileId)) {
    const type = /\.svg$/i.test(fileId) ? 'image/svg+xml' : /\.png$/i.test(fileId) ? 'image/png' : 'image/jpeg';
    imageUrl.urls.set(fileId, URL.createObjectURL(new Blob([bytes], { type })));
  }
  return imageUrl.urls.get(fileId);
}

// ─── /Kit ───────────────────────────────────────────────────────────────────────

The composed script.js runs as it is: paste it into any page’s module script, or open the recipe on CodePen. Recipe folder on GitHub ↗

Variations

#Keep the briefs under the photograph

Without placement="bottom" in content.en.md, the strip stays where its fence is, right under the photograph, and the lead story runs below it to the foot of the page.

-:::callout{type="briefs" span="page" placement="bottom" title="In brief"}
+:::callout{type="briefs" span="page" title="In brief"}

Pitfalls

Pitfall

:::columns works only inside a box and never splits

:::columns is ignored outside a callout, and a box that splits never cuts inside a columns group. A breaks attribute counts child blocks, with a nested box as one. Columns inside a box →

Pitfall

The column rule can run down through a page-span opener

In postext 1.4.1 the column rule of a band starts at the top of its highest column. A page-span heading stays in the first column, so when its opener does not end exactly on a grid line, the sliver of second column left beside it makes the rule start at the top of the text block and cross the opener. Make the opener a whole number of grid lines deep, with an empty box of that height or a minHeight when the design is shorter: it then ends on a grid line and leaves no sliver. Column rule →

Pitfall

A table or figure inside a box gets no space around it

In postext 1.4.1 a table or figure that ::resource sets at position 'here' inside a :::callout gets none of the space it keeps in the running text: it touches the paragraph above it and the one below. Put a :::space before the ::resource line, and another after it when text follows; a fraction of a line, such as lines=0.33, gives a small gap. Figures exactly here →

Pitfall

A 'top' float never lands on its citing page

A float never goes above its own reference, so a page-wide 'top' float cited on page N opens page N+1. Cite it earlier, or use position 'auto' or 'bottom', which can take the foot of the citing page. Figure placement →

Pitfall

Bitmaps are laid out in px at the document dpi: declare print size

A bitmap resource is sized from the width and height it declares, in pixels at the document's dpi, not from the file. Declare the print-size pixels (about 300 dpi at the printed width) so the figure lands at the right size and stays sharp. Figures and tables as resources →

Pitfall

Any headings object switches off the H1 page break

By default an H1 breaks to a recto (always-odd), but passing any headings object resets that default, so chapters run on and span: 'page' does nothing. Restate headings.levels[0].breakBefore: { enabled: true, parity } in every config. Chapters that open on a recto →

Pitfall

A swapped palette misses design elements and the reference colour

postext 1.4.1 reads colorPalette into the text styles (body, headings, lists, captions, tables, boxes) but not into the elements of headers, footers, openers and part pages, nor into bodyText.referenceColor: they keep the hex written beside their paletteId. When you swap the palette, for a dark screen edition or a retint, rewrite every linked colour from colorPalette before the build. Semantic colour palette →

Pitfall

A design text's lineHeight is a multiple, never a dimension

In a design slot, a text element's lineHeight multiplies its font size (lineHeight: 1.05). In postext 1.4.1 a dimension such as pt(15) is not rejected: the opener's height measures as NaN, the room it reserves, minHeight included, is dropped without a warning and the text runs under the title. Text, rules and boxes in page designs →

Pitfall

Design text overflow defaults to 'ellipsis-end'

A design text element that does not fit its width ends in an ellipsis by default. Set overflow: 'wrap' for titles that should break onto more lines. Text, rules and boxes in page designs →

Pitfall

A runt fix can tighten tracking that is never painted

In postext 1.4.1, when a paragraph ends on a runt, the layout sets it one line shorter: first with tighter word spacing, then with up to maxRuntTracking thousandths of an em of negative tracking. The canvas and PDF renderers paint tracking only above zero, so a tracked paragraph prints untracked: its justified lines lose the difference from their word spaces and look crushed, and its last line can run past the measure and be clipped at the column edge. Set bodyText.maxRuntTracking: 0, which keeps the word-spacing fix, and reword any runt that comes back. Widows, orphans and runts →

Pitfall

Load every face before layout

Layout measures text with the faces the browser has loaded and caches the widths, so a face that arrives after the first build leaves wrong line breaks and a PDF that no longer matches the screen. Load every weight and style first, and call clearMeasurementCache() before rebuilding when one arrives late. Fonts before layout →

Give the photograph placement: { position: 'top', span: 'page' } and it moves off page 1 to stand alone on page 2. The story on page 1 then ends 92 mm above the briefs strip, and the section moves to page 3.

Credits

Recipe: Ignacio Ferro
Text: Original prose, CC BY 4.0
Images: Wind turbines on a snowy ridge (the front-page photograph, cropped to a band) · Jason Blackeye · CC0 1.0
The bridge drawing and the bars in the ward table, drawn in code in the page's palette · Ignacio Ferro · CC BY 4.0
Fonts: Grenze Gotisch (SIL OFL 1.1) · PT Serif (SIL OFL 1.1) · Libre Franklin (SIL OFL 1.1)
Code: MIT, like Postext

Edit this write-up ↗Recipe folder on GitHub ↗

#What you'll build

#The short answer

#Ingredients

#Method

#1 · Newsprint, ink and one red

#2 · The nameplate is the front page's H1

#3 · A headline across both columns is a box

#4 · More than two columns live inside a box

#5 · Pictures inline, tables as floats

#6 · An inside page opens on a section flag

#The whole recipe

#Variations

#Keep the briefs under the photograph

#Pitfalls

#Credits

More from the Cookbook

Boxes that split, float and pin

Magazine cover and sectioned contents

Research poster on one big page

What you'll build

The short answer

Ingredients

Method

The whole recipe

Variations

Pitfalls

Credits
