Full de pràctiques amb vídeos per a la pantalla i l'EPUB

// ═══ Postext Cookbook · Nº 132 · A lab sheet whose clips play on screen and in the EPUB ════
// https://postext.dev/en/cookbook/pendulum-lab-video-players
// Code: MIT · Text: original (CC BY 4.0) · Clips: rendered in code (CC BY 4.0)
// Fonts: Source Serif 4, Red Hat Display, Red Hat Mono (SIL OFL 1.1) · Needs postext ≥ 1.16.1
import {
  buildDocument, renderPageToCanvas, renderToHtml, applyHtmlViewerOverrides,
  clearMeasurementCache, registerResourceImage, defaultResourceTypes, resourceVideoLink,
} from 'https://esm.sh/postext';
import { renderToPdf, decompressWoff2 } from 'https://esm.sh/postext-pdf';
import { renderToEpub, readEpub } from 'https://esm.sh/postext-epub';

const LANG = 'es'; // @lang: the language of the sample document ('en' | 'es')
const RECIPE = 'pendulum-lab-video-players';

// ─── 1 · Design ─────────────────────────────────────────────────────────────
const palette = { // the clips' own colours: a cream ground, the rust bob, warm black ink
  ink: '#22201b', // text, the play mark, the QR modules, table heads
  rust: '#a8432b', // the accent: the band, labels, list numbers (the bob's red, darker)
  cream: '#f6f1e4', rule: '#cbc2ae', // box fills, a shade deeper than the clips; hairlines
  muted: '#68625a', paper: '#ffffff' }; // muted: running heads, notes, prompts
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
const colorPalette = Object.entries({ ...palette, 'main-color': palette.rust }) // defaults: rust
  .map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } }));
const [TEXT, DISPLAY, MONO] = ['Source Serif 4', 'Red Hat Display', 'Red Hat Mono'];
const [TOP, INNER, OUTER, BAND, LEAD] = [22, 20, 17, 84, 13.2]; // mm, A4; LEAD in pt
const px = (value) => ({ value, unit: 'px' }); // the screen edition's sizes
const at = (to, edge, x, y, size) => ({ anchor: { to, edge }, offset: { x, y }, size });
const label = (size, color = 'rust') => ({ fontFamily: MONO, fontSize: pt(size), fontWeight: 600,
  letterSpacing: pt(size * 0.16), textTransform: 'uppercase', color: col(color) });

// #region answer: two clips of the book's own: a poster and a QR code, or a player
const clip = (id, file, poster, caption, altText) => ({
  id, typeId: 'video', kind: 'video', createdAt: 0, updatedAt: 0, caption: t(caption),
  note: t({ en: '8.00 s, 25 frames per second · Postext Cookbook, CC BY 4.0',
    es: '8,00 s, 25 fotogramas por segundo · Postext Cookbook, CC BY 4.0' }),
  altText: t(altText), placement: { position: 'bottom', span: 'column' },
  video: { source: 'file', fileId: file, format: 'mp4', width: 640, height: 360, duration: 8,
    url: asset(file), // the production address: printed as the QR code, linked from the PDF
    poster: { fileId: poster, format: 'jpeg', width: 640, height: 360 }, // the first frame
  },
});
const videoStyle = {
  playMark: { shape: 'rounded', position: 'top-left', size: mm(7), inset: mm(3),
    background: col('ink'), color: col('paper') },
  qr: { position: 'bottom-right', size: mm(19), inset: mm(2.5), // 111 characters: 45 modules
    color: col('ink'), background: col('paper'), radius: mm(1) },
  // The HTML5 player of a file honours every option. download: false writes
  // controlslist="nodownload": it hides the button, and the file stays at its address.
  player: { download: false, loop: true, muted: true, preload: 'auto',
    pictureInPicture: false, remotePlayback: false },
};
const clips = [
  clip('small', 'pendulum-small.mp4', 'pendulum-small-poster.jpg',
    { en: 'Released from rest at 10°.', es: 'Soltado desde el reposo a 10°.' },
    { en: 'A rust bob on a dark string hangs a few degrees off the vertical, under a short bar.',
      es: 'Una lenteja roja cuelga de un hilo oscuro a pocos grados de la vertical.' }),
  clip('large', 'pendulum-large.mp4', 'pendulum-large-poster.jpg',
    { en: 'Released from rest at 80°.', es: 'Soltado desde el reposo a 80°.' },
    { en: 'The same pendulum pulled out almost level with its pivot, a pale arc below it.',
      es: 'El mismo péndulo, casi a la altura de su eje, sobre un arco pálido.' }),
];
// #endregion

// #region periods: Table 2 is worked out here, not typed: T = T0 / AGM(1, cos ½θ0)
// The arithmetic-geometric mean gives the elliptic integral K of the exact period in a few steps.
const T0 = 2 * Math.PI * Math.sqrt(1 / 9.81); // s: L = 1 m, g = 9.81 m/s²
const agm = (a, b) => (Math.abs(a - b) < 1e-15 ? a : agm((a + b) / 2, Math.sqrt(a * b)));
const period = (degrees) => T0 / agm(1, Math.cos((degrees * Math.PI) / 360));
const num = (x, digits) => x.toFixed(digits).replace('.', t({ en: '.', es: ',' }));
const cell = (content, align = 'right') => ({ content, align, verticalAlign: 'middle' });
const table = (id, caption, head, rows, columnWidths) => ({ id, typeId: 'table', kind: 'table',
  createdAt: 0, updatedAt: 0, caption: t(caption), placement: { position: 'here' },
  table: { model: { headerRowCount: 1, columnWidths, rows: [head.map((h, i) =>
    ({ ...cell(h, i ? 'right' : 'left'), isHeader: true })), ...rows] } } });
const periods = table('periods', { en: 'Exact periods of a pendulum 1.00 m long.',
  es: 'Periodos exactos de un péndulo de 1,00 m.' },
['Amplitude|Amplitud', 'T (s)', 'T/T~0~', 'Longer by|Aumento'].map((h) =>
  t({ en: h.split('|')[0], es: h.split('|').at(-1) })),
[5, 10, 20, 30, 45, 60, 80, 90].map((d) => [cell(`${d}°`, 'left'), cell(num(period(d), 3)),
  cell(num(period(d) / T0, 3)), cell(`${num((period(d) / T0 - 1) * 100, 2)} %`)]),
[1.2, 1, 1, 1.1]);
const blank = cell(' \n '); // two empty lines: room to write
const data = table('data', { en: 'Your measurements.', es: 'Tus medidas.' },
  t({ en: ['Clip', 'Swings in 8 s', 'T (s)'], es: ['Vídeo', 'Oscilaciones en 8 s', 'T (s)'] }),
  [10, 80].map((d, i) => [cell(`${t({ en: 'Video', es: 'Vídeo' })} ${i + 1} · ${d}°`, 'left'),
    blank, blank]), [1.2, 1.5, 0.8]);
// #endregion

// #region opener: a rust band with the sheet's number, its title and the fields to fill in
const words = (id, content, family, size, placement, extra) => ({ kind: 'text', id, content,
  fontFamily: family, fontSize: pt(size), color: col('paper'), align: 'left',
  overflow: 'wrap', placement, ...extra }); // titles wrap (gotcha: overflow-ellipsis-default)
const names = t({ en: ['Name', 'Group', 'Date'], es: ['Nombre', 'Grupo', 'Fecha'] });
const fields = [[0, 86], [90, 30], [124, 49]].flatMap(([x, width], i) => [ // mm, from the margin
  words(`label-${i}`, names[i], MONO, 7, at('page', 'top-left', mm(INNER + x), mm(BAND - 16)),
    label(7, 'paper')),
  { kind: 'box', id: `field-${i}`, style: { backgroundColor: col('paper'), borderRadius: mm(1) },
    placement: at('page', 'top-left', mm(INNER + x), mm(BAND - 12.5),
      { width: mm(width), height: mm(6.5) }) }]);
const opener = { enabled: true, minHeight: mm(BAND - TOP + 6), slot: { elements: [
  { kind: 'box', id: 'band', style: { backgroundColor: col('rust') },
    placement: at('bleed', 'top-left', mm(0), mm(0), { width: 'fill', height: mm(BAND) }) },
  words('kicker', '{attr.kicker}', MONO, 8.5, at('page', 'top-left', mm(INNER), mm(14)),
    label(8.5, 'paper')),
  words('title', '{titleText}', DISPLAY, 46, at('#kicker', 'below', mm(0), mm(2.5),
    { width: mm(150) }), { fontWeight: 800, lineHeight: 0.98 }),
  words('lead', '{attr.lead}', TEXT, 10, at('#title', 'below', mm(0), mm(3.5),
    { width: mm(158) }), { lineHeight: 1.4 }),
  ...fields] } }; // a label over a white field for each, to fill in by hand
// #endregion

const head = (id, content, edge, x, extra) => ({ kind: 'text', id, content, parity: 'even',
  pages: 'body', ...label(7, 'muted'), fontWeight: 500, placement: at('page', edge, mm(x),
    mm(12)), ...extra });
const header = { elements: [
  head('folio', '{pageNumber}', 'top-left', OUTER, { color: col('rust'), fontWeight: 700 }),
  head('title', '{title} · {attr.kicker}', 'top-left', OUTER + 7)] };
const footer = { elements: [head('drop-folio', '{title} · {pageNumber}', 'bottom-right', 0, {
  parity: 'all', pages: 'opener', placement: at('page', 'bottom-right', mm(-OUTER), mm(-11)) })] };
const box = (id, extra) => ({ id, background: col('cream'), borderRadius: mm(1.5),
  padding: { top: mm(3), right: mm(3.5), bottom: mm(3), left: mm(3.5) },
  titleStyle: { ...label(7.5), gap: mm(1.2) }, body: { fontSize: pt(9.2), lineHeight: pt(LEAD),
    textAlign: 'left', firstLineIndent: pt(0) }, ...extra });

const config = () => ({ // a factory: the engine caches configs by identity
  locale: t({ en: 'en-us', es: 'es' }), // exact codes (gotcha: hyphenation-locales)
  // Figure, Table, Video in the sheet's language, counted 1, 2… (gotcha: resource-types-locale)
  resourceTypes: defaultResourceTypes(LANG).map((type) => ({ ...type, numberingTemplate: '{n}',
    resetOn: 'never', shortLabel: t({ en: type.name, es: type.name.toLowerCase() }) })),
  colorPalette, videoStyle,
  page: { sizePreset: 'custom', width: mm(210), height: mm(297), dpi: 150, margins: {
    top: mm(TOP), bottom: mm(22), left: mm(INNER), right: mm(OUTER), mirror: true } },
  layout: { layoutType: 'double', gutterWidth: mm(7) }, // columns of 83 mm
  bodyText: { fontFamily: TEXT, fontSize: pt(9.4), lineHeight: pt(LEAD), color: col('ink'),
    boldColor: col('ink'), italicColor: col('ink'), referenceColor: col('rust'),
    textAlign: 'justify', firstLineIndent: mm(4), indentAfterHeading: false,
    hyphenation: { enabled: true }, optimalLineBreaking: true,
    avoidWidows: true, avoidOrphans: true, avoidRunts: true },
  headings: { fontFamily: DISPLAY, color: col('ink'), fontWeight: 700, levels: [
    // Restated: any headings object drops the H1 break (gotcha: headings-drop-h1-break).
    { level: 1, span: 'page', breakBefore: { enabled: true, parity: 'odd' },
      marginTop: pt(0), marginBottom: pt(0), advancedDesign: opener },
    { level: 2, fontSize: pt(12.5), lineHeight: pt(LEAD), marginTop: pt(LEAD),
      marginBottom: pt(LEAD / 2) },
  ] },
  orderedLists: { numberFormat: 'arabic', fontFamily: MONO, fontWeight: 700,
    color: col('rust'), marginTop: pt(0), marginBottom: pt(0) },
  calloutStyles: [
    box('aim', { stripe: { enabled: true, side: 'top', width: pt(2.5), color: col('rust') } }),
    box('method'), box('sheet'),
    { id: 'answer', background: col('paper'), borderRadius: mm(1), marginTop: mm(1.2),
      marginBottom: mm(2.5), border: { enabled: true, color: col('rule'), width: pt(0.6) },
      padding: { top: mm(1), right: mm(2.5), bottom: mm(1), left: mm(2.5) },
      body: { ...label(6.5, 'muted'), fontWeight: 500, lineHeight: pt(LEAD) } },
  ],
  tableStyle: { rules: 'horizontal', borderColor: col('rule'), borderWidth: pt(0.5),
    headerBackground: col('ink'), headerColor: col('paper'), headerFontFamily: MONO,
    headerFontSize: pt(7.5), bodyFontFamily: MONO, bodyFontSize: pt(8.5),
    bodyColor: col('ink'), cellPadding: mm(1.4) },
  captionStyle: { fontFamily: TEXT, fontSize: pt(8), color: col('ink'), labelBold: true,
    labelColor: col('rust'), gap: mm(2), note: { fontSize: pt(7), color: col('muted') } },
  paragraphStyles: [
    { id: 'formula', fontSize: pt(11), textAlign: 'center', firstLineIndent: pt(0),
      marginTop: pt(LEAD / 2), marginBottom: pt(LEAD / 2) },
    { id: 'colophon', fontFamily: MONO, fontSize: pt(6.5), lineHeight: pt(9.5),
      color: col('muted'), textAlign: 'left', firstLineIndent: pt(0), marginTop: pt(LEAD) },
  ],
  header, footer, htmlViewer: { overrides: screen }, // canvas and PDF ignore the overrides
});

// #region screen: the screen edition: one column at the pane's width, the clips as players
const [PANE_W, PANE_H] = [400, 640]; // px
const screen = {
  page: { width: px(PANE_W), height: px(PANE_H), dpi: 122, // so the 9.4 pt text is 16 px
    margins: { top: px(28), bottom: px(28), left: px(22), right: px(22), mirror: false } },
  layout: { layoutType: 'single' }, bodyText: { textAlign: 'left' }, // ragged in a narrow pane
  headings: { levels: [{ level: 1, span: 'column', breakBefore: { enabled: false },
    fontSize: px(28), lineHeight: px(32), fontWeight: 800, marginBottom: px(16),
    advancedDesign: { enabled: false } }] }, // the title alone: the band and fields are print's
  header: { elements: [] }, footer: { elements: [] } };
// #endregion

// ─── 2 · Content ────────────────────────────────────────────────────────────
const markdown = String.raw`---
Mostra en Markdown · 86 línies · content.es.md
title: "Física en el laboratorio"
subtitle: "Cuaderno de prácticas, de 16 a 18 años"
---

# El periodo de un péndulo {kicker="Unidad 4 · Oscilaciones · Práctica 4.2" lead="Dos péndulos de la misma longitud, soltados desde 10° y desde 80°. Cronometra los dos en vídeo y averigua si el periodo depende de la amplitud de la oscilación."}

:::callout{type="aim" title="Objetivo"}
Medir en vídeo el periodo de un péndulo de 1,00 m y ver hasta dónde vale la fórmula de las oscilaciones pequeñas.

**Necesitas** los vídeos, un móvil o una pantalla y una calculadora.
:::

## Los dos vídeos

El :ref{id="small"} y el :ref{id="large"} se generaron a partir de una solución numérica de la ecuación del movimiento del péndulo, θ″ = −(*g*/*L*) sen θ, calculada en pasos de un milisegundo para un péndulo de 1,00 m. Cada uno dura 8,00 s a 25 fotogramas por segundo, así que un fotograma son 0,04 s. El modelo no tiene rozamiento, así que las oscilaciones no se apagan.

La imagen impresa de cada vídeo es su primer fotograma, y el código de la esquina lo abre. Escanéalo con el móvil o mira los vídeos en la edición de pantalla. Los dos se repiten en bucle, empiezan sin sonido y tienen un menú de velocidad: bájala a la mitad para contar.

## Fundamento

Un péndulo simple es una lenteja pequeña y pesada colgada de un hilo ligero que no se estira. Si se aparta y se suelta, oscila a uno y otro lado de su punto más bajo. El **periodo**, *T*, es el tiempo que tarda en ir y volver al punto de partida.

Galileo observó que un péndulo conserva el periodo mientras sus oscilaciones se apagan, y los relojeros se apoyaron en ello durante tres siglos. En oscilaciones pequeñas, el periodo solo depende de la longitud *L* y de la intensidad del campo gravitatorio *g*:

:::paragraphs{style="formula"}
*T*~0~ = 2π (*L*/*g*)^1/2^
:::

Con *L* = 1,00 m y *g* = 9,81 m s^−2^, *T*~0~ vale 2,006 s. Para deducirla se sustituye sen θ por θ en radianes, lo que solo vale con un error menor del 1 % hasta unos 14°. Más allá, la fuerza que devuelve la lenteja al centro crece más despacio que el ángulo, la lenteja se entretiene cerca de los extremos y cada oscilación tarda algo más. Con la amplitud θ~0~, el ángulo desde el que se suelta la lenteja, y *K*, la integral elíptica completa de primera especie, el periodo exacto es

:::paragraphs{style="formula"}
*T* = 4 (*L*/*g*)^1/2^ *K*(sen ½θ~0~)
:::

## Procedimiento

:::callout{type="method"}
1. Reproduce el primer vídeo desde el principio. La lenteja se suelta desde el reposo en el primer fotograma.
2. Cuenta las oscilaciones completas, de ida y vuelta al punto de partida, hasta que el vídeo acaba a los 8,00 s. Estima la última con una precisión de un cuarto de oscilación.
3. Divide 8,00 s entre el número de oscilaciones para obtener el periodo.
4. Repite con el segundo vídeo y completa la tabla.
:::

## Resultados

::resource{id="data"}

Los valores de la :ref{id="periods"} salen de la fórmula exacta, con tres decimales. Compara tus periodos con las filas de 10° y de 80°.

::resource{id="periods"}

## Cuestiones

:::callout{type="sheet"}
1. ¿Qué vídeo tiene el periodo más largo, y en qué porcentaje?

:::callout{type="answer"}
Respuesta
:::space{lines=3}
:::

2. La lenteja del segundo vídeo recorre un arco mucho más largo. ¿Por qué su periodo no crece en la misma proporción?

:::callout{type="answer"}
Respuesta
:::space{lines=4}
:::

3. La primera corrección a la fórmula de las oscilaciones pequeñas da *T* = *T*~0~ (1 + θ~0~^2^/16), con θ~0~ en radianes. Calcúlala para 80° y compárala con la tabla. ¿Basta con un término?

:::callout{type="answer"}
Respuesta
:::space{lines=4}
:::

4. Un reloj de pie oscila 4° a cada lado de la vertical. ¿Necesitaría su relojero la fórmula exacta?

:::callout{type="answer"}
Respuesta
:::space{lines=3}
:::
:::

:::paragraphs{style="colophon"}
Física en el laboratorio, práctica 4.2 · Compuesto en Source Serif 4, Red Hat Display y Red Hat Mono (SIL Open Font License) · Texto y vídeos: Postext Cookbook, CC BY 4.0.
:::
`; // content.<lang>.md, inlined by the Cookbook
const resources = [...clips, data, periods];

// ─── 3 · Fonts ──────────────────────────────────────────────────────────────
const FONTS = { // every face the pages use, loaded before the build (gotcha: fonts-first)
  'Source Serif 4': ['400', '400i', '700', '700i'], 'Red Hat Display': ['700', '800'],
  'Red Hat Mono': ['400', '500', '600', '700'] };

// #region greek: θ and π come from the text face's greek file, which the kit does not load
// Fontsource cuts each face by script, and the PDF keeps its latin file (gotcha: latin-subset).
const GREEK = 'U+0370-03FF'; // Greek and Coptic
const file = (family, subset, [weight, style]) => 'https://cdn.jsdelivr.net/npm/@fontsource/'
  + `${fontsourceId(family)}@5/files/${fontsourceId(family)}-${subset}-${weight}-${style}.woff2`;
const faceOf = (spec) => [parseInt(spec, 10), spec.endsWith('i') ? 'italic' : 'normal'];
const bytesOf = async (url) => new Uint8Array(await (await fetch(url)).arrayBuffer());
const greek = FONTS[TEXT].map(faceOf).map(([weight, style]) => ({ family: TEXT, weight, style,
  url: file(TEXT, 'greek', [weight, style]) }));
const loadGreek = () => Promise.all(greek.map(async ({ weight, style, url }) => document.fonts.add(
  await new FontFace(TEXT, `url(${url})`, { weight: `${weight}`, style, unicodeRange: GREEK })
    .load())));
// The PDF takes both files of a text face; it asks for every weight, and Source Serif 4 ships
// 200 to 900 (gotcha: pdf-provider-all-styles). A character comes from the first file with it.
const pdfFont = async (family, weight, style) => {
  const latin = await fontsourceProvider(family, weight, style);
  return family !== TEXT ? latin : [latin, await decompressWoff2(await bytesOf(file(TEXT,
    'greek', [Math.max(weight, 200), style])))];
};
// #endregion

// ─── 4 · Build & show ───────────────────────────────────────────────────────
await Promise.all([loadFonts(FONTS, markdown), loadGreek(),
  ...clips.map(({ video }) => loadImage(video.poster.fileId, asset(video.poster.fileId)))]);
const doc = await buildWithFonts(() => buildDocument({ markdown, resources }, config()), markdown);
showPages(doc, { title: t({ en: 'The period of a pendulum', es: 'El periodo de un péndulo' }) });
offerPdf(() => renderToPdf(doc, { fontProvider: pdfFont, resourceBytes: imageBytes }),
  `${RECIPE}.pdf`);

// #region epub: a fixed-layout EPUB that carries both MP4 files and plays them on the page
const media = new Map(await Promise.all(clips.map(async ({ video }) =>
  [video.fileId, { bytes: await bytesOf(asset(video.fileId)), mediaType: 'video/mp4' }])));
const fonts = await Promise.all([ // every face as bytes (gotcha: epub-embeds-given-fonts)
  ...Object.entries(FONTS).flatMap(([family, specs]) => specs.map(faceOf).map(([w, s]) =>
    ({ family, weight: w, style: s, url: file(family, 'latin', [w, s]) }))),
  ...greek.map((face) => ({ ...face, unicodeRange: GREEK })), // after latin: tried first
].map(async ({ url, ...face }) => ({ ...face, format: 'woff2', bytes: await bytesOf(url) })));
const epub = await renderToEpub([doc], { layout: 'fixed', fonts,
  metadata: { title: doc.metadata.title, creators: ['Postext Cookbook'], language: LANG,
    rights: 'CC BY 4.0', modified: new Date('2026-10-05T00:00:00Z') }, // the same bytes each run
  // The clips as video/mp4 and the posters as pictures; the book packs both under media/.
  resourceBytes: (fileId) => media.get(fileId)
    ?? { bytes: imageBytes(fileId), mediaType: 'image/jpeg' },
});
// #endregion

const [read, kb] = [readEpub(epub), (bytes) => `${Math.round(bytes.length / 1024)} KB`];
const list = (lines) => `<ul>${lines.map((line) => `<li>${line}</li>`).join('')}</ul>`;
const desk = Object.assign(document.createElement('section'), { id: 'editions', innerHTML: `
<style>#editions{display:flex;flex-wrap:wrap;gap:28px;justify-content:center;align-items:start;
padding:28px 16px 0;color:#d9d5cc}#editions figure{margin:0}#editions figcaption{margin-top:16px;
color:#8b8f97}#screen{width:${PANE_W}px;height:${PANE_H}px;overflow:auto;border-radius:12px;
box-shadow:0 0 0 8px #1d1f24}#editions article{width:min(380px,92vw);padding:4px 18px;
border-radius:8px;background:#15181d;overflow-wrap:anywhere}#editions a{color:#d8a21a}</style>
<figure><div id="screen" role="region" tabindex="0"></div><figcaption>${t({ en: 'Screen'
  + ' edition', es: 'Edición de pantalla' })} · HTML · ${PANE_W} × ${PANE_H} px</figcaption>
</figure><article><h3>EPUB 3 · ${read.layout}</h3>
<p>${read.spine.length} pages · ${kb(epub)}. The book carries:</p>${list([...read.manifest
  .values()].filter((item) => item.mediaType === 'video/mp4').map(({ path }) =>
  `${path.slice(read.root.length)} · ${kb(read.files.get(path))}`))}
<p>The QR codes and the PDF links open:</p>${list(clips.map(resourceVideoLink))}
<a download="${RECIPE}.epub" href="${URL.createObjectURL(new Blob([epub],
  { type: 'application/epub+zip' }))}">Download ${RECIPE}.epub</a></article>` });
document.getElementById('pages').before(desk);

// #region pane: the screen edition as HTML, each clip in the browser's own player
// A shadow root keeps the page's styles out, so the pane shows the lines as they were measured.
const pane = desk.querySelector('#screen').attachShadow({ mode: 'open' });
pane.innerHTML = renderToHtml(buildDocument({ markdown, resources },
  applyHtmlViewerOverrides(config())), { mode: 'single', padding: 0, background: '#ffffff',
  resourceImageUrl: imageUrl, // the posters, until a clip plays
  resourceVideoUrl: (fileId) => asset(fileId) }); // the file each <video> plays: the asset here
const top = (el) => el.getBoundingClientRect().top; // open the pane on the first player
pane.host.scrollTop = top(pane.querySelector('video')) - top(pane.host) - 48;
// #endregion

Kit · core, fonts, viewer, pdf, images: igual a totes les receptes · 310 línies
// ─── Kit ── helpers shared by every Cookbook recipe · postext.dev/cookbook ─────

// ─── Kit · core v1 ── the same in every recipe · postext.dev/cookbook ─────────
function mm(value) { return { value, unit: 'mm' }; }
function pt(value) { return { value, unit: 'pt' }; }
function em(value) { return { value, unit: 'em' }; }
/** The sample language's string: t({ en: 'Figure', es: 'Figura' }). */
function t(strings) { return strings[LANG] ?? Object.values(strings)[0]; }
/** A file in this recipe's assets folder, served from the Postext repo by jsDelivr. */
function asset(file) { return `https://cdn.jsdelivr.net/gh/drnachio/postext@main/cookbook/${RECIPE}/assets/${file}`; }

// ─── Kit · fonts v1 ── the same in every recipe · postext.dev/cookbook ────────
// Postext measures text with the faces the browser has loaded, and caches the
// widths, so every face must be ready before the first build. Faces come from
// Fontsource: the same static files the PDF embeds, so screen and PDF agree.

/** faces = { 'Family Name': ['400', '400i', '700'] }. `text` is the sample:
 *  letters beyond Latin-1 (č, ł, ő…) also load the latin-ext files. With
 *  `optional`, a face Fontsource does not ship is skipped instead of failing.
 *  Resolves to the number of faces added. */
async function loadFonts(faces, text = '', { optional = false } = {}) {
  kitStatus('Loading fonts…');
  const ranges = {
    latin: 'U+0000-00FF,U+0131,U+0152-0153,U+02BB-02BC,U+02C6,U+02DA,U+02DC,U+0304,U+0308,U+0329,'
      + 'U+2000-206F,U+20AC,U+2122,U+2191,U+2193,U+2212,U+2215,U+FEFF,U+FFFD',
    'latin-ext': 'U+0100-02BA,U+02BD-02C5,U+02C7-02CC,U+02CE-02D7,U+02DD-02FF,U+0304,U+0308,U+0329,'
      + 'U+1D00-1DBF,U+1E00-1E9F,U+1EF2-1EFF,U+2020,U+20A0-20AB,U+20AD-20C0,U+2113,U+2C60-2C7F,U+A720-A7FF',
  };
  const subsets = /[Ā-˿Ḁ-ỿ]/.test(text) ? ['latin', 'latin-ext'] : ['latin'];
  const jobs = [];
  let added = 0;
  for (const [family, specs] of Object.entries(faces)) {
    const id = fontsourceId(family);
    const meta = optional ? await fontsourceMeta(family) : null;
    for (const spec of new Set(specs)) {
      const weight = parseInt(spec, 10);
      const style = spec.endsWith('i') ? 'italic' : 'normal';
      if (hasFace(family, weight, style)) continue;
      if (optional && !(meta?.weights.includes(weight) && meta.styles.includes(style))) continue;
      for (const subset of subsets) {
        const url = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-${subset}-${weight}-${style}.woff2`;
        const face = new FontFace(family, `url(${url}) format('woff2')`,
          { weight: String(weight), style, unicodeRange: ranges[subset] });
        jobs.push(face.load().then((ready) => { document.fonts.add(ready); added++; }, () => {
          if (subset === 'latin' && !optional) throw new Error(`Fontsource has no ${family} ${weight} ${style}`);
        }));
      }
    }
  }
  await Promise.all(jobs).catch((error) => { kitFail(error); throw error; });
  return added;
}

/** Runs `build` (a buildDocument or buildBundle call) and checks the faces
 *  the pages use. A regular face missing from FONTS is loaded with a warning;
 *  bold and italic variants are loaded when the family ships them. Then the
 *  measurement caches are cleared and the build runs again. */
async function buildWithFonts(build, text = '') {
  const tried = new Set();
  for (let round = 0; round < 3; round++) {
    kitStatus('Laying out…');
    await new Promise(requestAnimationFrame);          // let the status paint first
    const result = await Promise.resolve().then(build).catch((error) => { kitFail(error); throw error; });
    const wanted = { base: {}, variants: {} };
    for (const { font, base } of [result].flat().flatMap(fontStringsOf)) {
      const { family, weight, style } = parseFont(font);
      const key = `${family}|${weight}|${style}`;
      if (tried.has(key) || hasFace(family, weight, style)) continue;
      tried.add(key);
      (wanted[base ? 'base' : 'variants'][family] ??= []).push(`${weight}${style === 'italic' ? 'i' : ''}`);
    }
    if (Object.keys(wanted.base).length) {
      console.warn(`[cookbook] FONTS does not list ${JSON.stringify(wanted.base)}: loading them.`);
    }
    const added = await loadFonts(wanted.base, text) + await loadFonts(wanted.variants, text, { optional: true });
    if (added === 0) return result;
    clearMeasurementCache();
  }
  throw new Error('The fonts did not settle after three builds.');
}

/** Every font string of the layout. `base` marks a block's own face; its
 *  bold, italic and bold-italic variants are listed whether or not used. */
function fontStringsOf(doc) {
  const found = new Map();
  const walk = (node) => {
    if (!node || typeof node !== 'object') return;
    if (Array.isArray(node)) { node.forEach(walk); return; }
    for (const [key, value] of Object.entries(node)) {
      if (typeof value === 'string' && /fontString$/i.test(key)) {
        found.set(value, found.get(value) || key === 'fontString');
      } else if (value && typeof value === 'object') walk(value);
    }
  };
  walk(doc.pages);
  walk(doc.blocks);
  return [...found].map(([font, base]) => ({ font, base }));
}

/** '700 37.5px Open Sans' / 'italic 400 13px "Source Serif 4"' → { family, weight, style }.
 *  A string with no weight ('95.8px Young Serif', from a design text) is 400. */
function parseFont(font) {
  const m = /^(?:(italic|oblique)\s+)?(?:small-caps\s+)?(?:(\d+|bold|normal)\s+)?[\d.]+px\s+(.+)$/.exec(font.trim());
  if (!m) throw new Error(`Unexpected font string: ${font}`);
  const weight = m[2] === 'bold' ? 700 : !m[2] || m[2] === 'normal' ? 400 : Number(m[2]);
  return { family: m[3].replace(/^["']|["']$/g, ''), weight, style: m[1] ? 'italic' : 'normal' };
}

/** True when a loaded FontFace covers exactly this family, weight and style
 *  (document.fonts.check() is also true for families nobody declared). */
function hasFace(family, weight, style) {
  for (const face of document.fonts) {
    if (face.status !== 'loaded' || face.style !== style) continue;
    if (face.family.replace(/^["']|["']$/g, '') !== family) continue;
    const [low, high = low] = face.weight.split(' ').map(Number);
    if (weight >= low && weight <= high) return true;
  }
  return false;
}

/** Fontsource's id for a family: 'Source Serif 4' → 'source-serif-4'. */
function fontsourceId(family) { return family.toLowerCase().replace(/\s+/g, '-'); }

/** The weights and styles a family ships ({ weights: [400, 700], styles: ['normal', 'italic'] }), or null. */
function fontsourceMeta(family) {
  fontsourceMeta.cache ??= new Map();
  const id = fontsourceId(family);
  if (!fontsourceMeta.cache.has(id)) {
    fontsourceMeta.cache.set(id, fetch(`https://api.fontsource.org/v1/fonts/${id}`)
      .then((res) => (res.ok ? res.json() : null), () => null));
  }
  return fontsourceMeta.cache.get(id);
}

// ─── Kit · viewer v1 ── the same in every recipe · postext.dev/cookbook ───────
/** Shows the pages as facing spreads on a dark desk: the first page is a
 *  recto on its own, then verso | recto pairs, as in a bound book. Pages
 *  are painted when they scroll near the screen. */
function showPages(docs, { title, width = 460 } = {}) {
  const root = viewer(title);
  const pages = [docs].flat().flatMap((doc) =>
    doc.pages.map((page) => ({ doc, page, n: (doc.pageIndexOffset ?? 0) + page.index })));
  const spreads = [];
  let verso = null;
  for (const p of pages) {
    if (p.n % 2 === 1) { if (verso) spreads.push([verso, null]); verso = p; }
    else { spreads.push([verso, p]); verso = null; }
  }
  if (verso) spreads.push([verso, null]);
  const density = Math.min(window.devicePixelRatio || 1, 2);
  showPages.painter?.disconnect();
  const painter = new IntersectionObserver((entries) => {
    for (const { isIntersecting, target } of entries) {
      if (!isIntersecting) continue;
      painter.unobserve(target);
      const { doc, page } = target.postext;
      renderPageToCanvas(page, doc, target, { scale: (width * density) / page.width });
    }
  }, { rootMargin: '800px' });
  showPages.painter = painter;
  root.replaceChildren(...spreads.map((pair) => {
    const spread = document.createElement('div');
    spread.className = 'pt-spread';
    for (const p of pair) {
      const figure = document.createElement('figure');
      if (p) {
        const label = p.page.pageLabel || String(p.n + 1);
        const canvas = document.createElement('canvas');
        canvas.postext = p;
        canvas.style.aspectRatio = `${p.page.width} / ${p.page.height}`;
        canvas.setAttribute('role', 'img');
        canvas.setAttribute('aria-label', `Page ${label}`);
        const folio = document.createElement('figcaption');
        folio.textContent = label;
        figure.append(canvas, folio);
        painter.observe(canvas);
      } else figure.className = 'pt-blank';
      spread.append(figure);
    }
    return spread;
  }));
  kitStatus(`${pages.length} ${pages.length === 1 ? 'page' : 'pages'}`);
  document.documentElement.dataset.postext = 'ready';
  return pages.length;
}

/** The desk, the bar and the error reporting, created once. */
function viewer(title) {
  if (!document.getElementById('pt-kit')) {
    document.head.insertAdjacentHTML('beforeend', `<style id="pt-kit">
      :root { color-scheme: dark; }
      body { margin: 0; background: #0e1014; color: #b9bcc4; font: 13px/1.45 system-ui, sans-serif; }
      #pt-bar { position: sticky; top: 0; z-index: 1; display: flex; flex-wrap: wrap; align-items: center;
        gap: 6px 16px; padding: 10px 16px; background: rgb(14 16 20 / .92); backdrop-filter: blur(6px);
        border-bottom: 1px solid #23262d; }
      #pt-bar strong { color: #f4f1ea; font-weight: 600; }
      #pt-actions { display: flex; gap: 12px; margin-left: auto; }
      #pt-actions a, #pt-actions button { color: #d8a21a; font: inherit; background: none; border: 0; padding: 0; cursor: pointer; }
      #pages { display: grid; justify-items: center; gap: 48px; padding: 32px 16px 72px; }
      .pt-spread { display: flex; }
      .pt-spread figure { margin: 0; width: min(460px, 44vw); }
      .pt-spread canvas { display: block; width: 100%; background: #fff;
        box-shadow: 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figure:first-child canvas { box-shadow: inset -14px 0 14px -14px rgb(0 0 0 / .18), 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figcaption { margin-top: 10px; text-align: center; font: 600 10px/1 system-ui, sans-serif;
        letter-spacing: .18em; text-transform: uppercase; color: #6c7079; }
      .pt-blank { visibility: hidden; }
      @media (max-width: 760px) {
        .pt-spread { flex-direction: column; gap: 32px; }
        .pt-spread figure { width: min(460px, 92vw); }
        .pt-blank { display: none; }
      }
    </style>`);
    document.body.insertAdjacentHTML('afterbegin',
      '<header id="pt-bar"><strong id="pt-title"></strong><span id="pt-status" role="status"></span><span id="pt-actions"></span></header>');
    document.getElementById('pt-title').textContent = document.title || 'Postext';
    addEventListener('error', (event) => kitFail(event.error ?? event.message));
    addEventListener('unhandledrejection', (event) => kitFail(event.reason));
  }
  if (title) document.getElementById('pt-title').textContent = title;
  return document.getElementById('pages')
    ?? document.body.appendChild(Object.assign(document.createElement('main'), { id: 'pages' }));
}

function kitStatus(text) {
  viewer();
  document.getElementById('pt-status').textContent = text;
}

function kitFail(error) {
  document.documentElement.dataset.postext = 'error';
  kitStatus(`Error: ${error?.message ?? error}`);
}

// ─── Kit · pdf v1 ── the same in every recipe that exports a PDF ──────────────
/** postext-pdf embeds TrueType bytes. Fetch the Fontsource file the screen
 *  used, snapping to a weight the family ships and falling back to upright
 *  when it has no italic: the PDF asks for every face a block could use. */
async function fontsourceProvider(family, weight, style) {
  const id = fontsourceId(family);
  const meta = await fontsourceMeta(family);
  const weights = meta?.weights?.length ? meta.weights : [400, 700];
  const w = weights.reduce((a, b) => (Math.abs(b - weight) < Math.abs(a - weight) ? b : a));
  const s = style === 'italic' && meta && !meta.styles.includes('italic') ? 'normal' : style;
  const res = await fetch(`https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-latin-${w}-${s}.woff2`);
  if (!res.ok) throw new Error(`Fontsource has no ${family} ${w} ${s} (${res.status})`);
  return decompressWoff2(new Uint8Array(await res.arrayBuffer()));
}

/** A "Build the PDF" button in the bar. Once built: "Open the PDF" (a new
 *  tab, since CodePen's preview frame cannot show PDFs) and a download link. */
function offerPdf(makePdf, filename) {
  viewer();
  const button = Object.assign(document.createElement('button'), { type: 'button', textContent: 'Build the PDF' });
  button.dataset.postextPdf = filename;
  button.addEventListener('click', async () => {
    button.disabled = true;
    button.textContent = 'Building the PDF…';
    try {
      const bytes = await makePdf();
      const url = URL.createObjectURL(new Blob([bytes], { type: 'application/pdf' }));
      const size = `${Math.max(1, Math.round(bytes.length / 1024))} KB`;
      button.replaceWith(
        Object.assign(document.createElement('a'), { href: url, target: '_blank', rel: 'noopener', textContent: 'Open the PDF ↗' }),
        Object.assign(document.createElement('a'), { href: url, download: filename, textContent: `Download ${filename} · ${size}` }));
    } catch (error) {
      button.disabled = false;
      button.textContent = 'Build the PDF';
      kitFail(error);
    }
  });
  document.getElementById('pt-actions').append(button);
}

// ─── Kit · images v1 ── recipes with pictures · postext.dev/cookbook ──────────
/** Registers a photo or PNG for the canvas and keeps its bytes for the PDF.
 *  fetch → ImageBitmap never taints the canvas (a plain cross-origin <img> would). */
async function loadImage(fileId, url) {
  const res = await fetch(url);
  if (!res.ok) throw new Error(`Image not found (${res.status}): ${url}`);
  const bytes = new Uint8Array(await res.arrayBuffer());
  registerResourceImage(fileId, await createImageBitmap(new Blob([bytes])));
  (loadImage.bytes ??= new Map()).set(fileId, bytes);
}

/** Registers SVG markup (drawn in code, or fetched) as a vector image. */
async function loadSvg(fileId, svg) {
  const img = new Image();
  await img.decode();
  registerResourceImage(fileId, img);
  (loadImage.bytes ??= new Map()).set(fileId, new TextEncoder().encode(svg));
}

/** renderToPdf({ resourceBytes: imageBytes }) */
function imageBytes(fileId) { return loadImage.bytes?.get(fileId); }

/** renderToHtml({ resourceImageUrl: imageUrl }) */
function imageUrl(fileId) {
  const bytes = imageBytes(fileId);
  if (!bytes) return undefined;
  imageUrl.urls ??= new Map();
  if (!imageUrl.urls.has(fileId)) {
    const type = /\.svg$/i.test(fileId) ? 'image/svg+xml' : /\.png$/i.test(fileId) ? 'image/png' : 'image/jpeg';
    imageUrl.urls.set(fileId, URL.createObjectURL(new Blob([bytes], { type })));
  }
  return imageUrl.urls.get(fileId);
}

// ─── /Kit ───────────────────────────────────────────────────────────────────────
