Poemas compuestos verso a verso

// ═══ Postext Cookbook · Nº 015 · Poems set line by line ═════════════════════════════
// https://postext.dev/en/cookbook/poetry-collection
// Code: MIT · Text: G. M. Hopkins, Poems, 1918 (PD) · Plate and ornament: drawn in code
// Fonts: Sorts Mill Goudy, Italiana, Marcellus SC (SIL OFL 1.1) · Needs postext ≥ 1.4.1
import {
  buildDocument, renderPageToCanvas, clearMeasurementCache, registerResourceImage,
} from 'https://esm.sh/postext';

const LANG = 'en'; // @lang: the language of the sample document ('en' | 'es')
const RECIPE = 'poetry-collection';

// ─── 1 · Design ─────────────────────────────────────────────────────────────
const palette = { // every colour in the config links to one of these
  ink: '#26221f', // the text: a warm near-black
  sage: '#56673f', // the one accent: numerals, the plate's ground, the ornament's leaves
  sepia: '#8c5f3a', // used for the rowan berries only
  muted: '#746a60', // dates, folios, leaders and the colophon
  paper: '#fbf8f2', // the page
};
// The hex travels with the id: designs do not read the palette (gotcha: palette-skips-designs).
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
const colorPalette = [
  ...Object.entries(palette).map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } })),
  // The engine's defaults link to 'main-color': point it at the accent, so nothing prints blue.
  { id: 'main-color', name: 'accent (defaults)', value: { hex: palette.sage, model: 'hex' } },
];
const TRIM_W = 140, TRIM_H = 216; // mm: a poetry trim, tall enough for a sonnet's turnovers
const LEAD = 15; // pt: the body's leading, the grid every line of verse sits on

// #region answer: verse: a paragraph per line, indents kept, turnovers that hang, stanza space
// A poem is one :::paragraphs{style="verse"} container with a paragraph per line, so no line
// runs on into the next. An indented line starts with spaces, two to an em, and a :::space
// line leaves one line of the grid between stanzas (blank lines only separate paragraphs):
//   :::paragraphs{style="verse"}
//   The world is charged with the grandeur of God.
//
//       It will flame out, like shining from shook foil;
//
//   :::space
//
//   And for all this, nature is never spent;
//   :::
const verse = {
  id: 'verse',
  textAlign: 'left', // ragged: a line that turns over is not stretched to the measure
  hangingIndent: em(4), // a turned line hangs past the 1 and 2 em indents
  // Verse is never hyphenated; ragged text is not in 1.4.1 either (gotcha: ragged-no-hyphenation).
  hyphenation: false,
};
// A paragraph loses its leading spaces, and hangingIndent overrides firstLineIndent, so in verse
// each pair of leading spaces becomes an em space behind a word joiner, where the trim stops.
const indentVerse = (md) => md.replace(/:::paragraphs\{style="verse"\}\n[\s\S]*?\n:::\n/g,
  (poem) => poem.replace(/^((?: {2})+)(?=\S)/gm, (s) => `\u2060${'\u2003'.repeat(s.length / 2)}`));
// Hook-up: paragraphStyles: [verse, …] and buildDocument({ markdown: indentVerse(markdown) }).
// #endregion

// #region lines: the lines around a poem: a dedication above it, a place and a date below
const lineStyles = [
  { id: 'dedication', fontSize: pt(9.5), marginBottom: pt(LEAD) }, // under The Windhover
  { id: 'date', fontFamily: 'Marcellus SC', fontSize: pt(8), color: col('muted'),
    textAlign: 'right', marginTop: pt(LEAD) }, // a line of space above, flush right
];
// #endregion

// #region poem-head: every poem opens a page under its numeral and its title
// '{1:I}' numbers the poems I to IV and {number} prints it (gotcha: heading-number-placeholders).
// The head is HEAD_LINES grid lines (minHeight, no bottom margin), so each poem starts on the same
// line; numeral and title fill 4, or 5 if the title wraps (gotcha: overflow-ellipsis-default).
const HEAD_LINES = 6;
const poemHead = { enabled: true, minHeight: pt(LEAD * HEAD_LINES), slot: { elements: [
  { kind: 'text', id: 'numeral', content: '{number}', fontFamily: 'Italiana', fontSize: pt(22),
    color: col('sage'), align: 'left',
    placement: { anchor: { to: 'container', edge: 'top-left' } } },
  { kind: 'text', id: 'title', content: '{titleText}', fontFamily: 'Sorts Mill Goudy',
    italic: true, fontSize: pt(17), color: col('ink'), align: 'left', overflow: 'wrap',
    placement: { anchor: { to: '#numeral', edge: 'below' }, offset: { y: mm(2) },
      size: { width: 'fill' } } },
] } };
// Parity 'any': the next page, recto or verso (restated: gotcha headings-drop-h1-break).
const poems = { level: 1, numberingTemplate: '{1:I}', advancedDesign: poemHead,
  marginBottom: pt(0), breakBefore: { enabled: true, parity: 'any' } };
// #endregion

// #region front: the half-title, the frontispiece, the title page and the contents
// Headings too, each on a page of its own, with no number, contents entry or folio.
// A style restates the break, or inherits the poems' (gotcha: style-inherits-break).
const leaf = { numbered: false, toc: false, span: 'page', footer: { elements: [] },
  breakBefore: { enabled: true, parity: 'any' } };
const onPage = (y, width) => ({ anchor: { to: 'page', edge: 'top' }, offset: { y: mm(y) },
  ...(width && { size: { width: mm(width) } }) }); // centred, y mm below the trim
const face = (id, content, font, size, y, extra = {}) => ({ kind: 'text', id, content,
  fontFamily: font, fontSize: pt(size), color: col('ink'), align: 'center',
  placement: onPage(y), ...extra });
const image = (id, placement) => ({ kind: 'image', id, resourceId: id, placement });
const design = (...elements) => ({ enabled: true, slot: { elements } });
const front = [
  { id: 'half-title', ...leaf,
    advancedDesign: design(face('title', '{titleText}', 'Italiana', 20, 60)) },
  { id: 'plate', ...leaf, advancedDesign: design( // span 'page': a column clips its design
    image('plate', { anchor: { to: 'bleed', edge: 'top-left' }, size: { width: 'fill' } }),
    face('caption', '{attr.caption}', 'Sorts Mill Goudy', 8.5, 203,
      { italic: true, color: col('muted') })) },
  { id: 'title-page', ...leaf, advancedDesign: design(
    face('author', '{author}', 'Marcellus SC', 10, 46, // {author}, {title}: the frontmatter
      { letterSpacing: pt(2.4), textTransform: 'uppercase' }),
    // A multiple of the size, never pt() (gotcha: design-lineheight-multiple).
    face('title', '{title}', 'Italiana', 54, 56, { lineHeight: 1 }),
    face('subtitle', '{subtitle}', 'Sorts Mill Goudy', 13, 80,
      { italic: true, color: col('sage') }),
    image('sprig', onPage(96, 30)),
    face('press', 'The Herbarium Press', 'Marcellus SC', 8.5, 182,
      { letterSpacing: pt(1.8), color: col('muted') })) },
  { id: 'contents', ...leaf, span: 'column', advancedDesign: { enabled: false },
    fontFamily: 'Italiana', fontSize: pt(24), lineHeight: pt(LEAD * 2), marginBottom: pt(LEAD) },
];
// #endregion

// #region contents: what :::toc prints for each poem: numeral, italic title, leader, page
// The toc centres each numeral on its line, not on the baseline (gotcha: toc-number-baseline);
// left at the titles' size, these Italiana numerals land on it, where 9 pt ones rode high.
const contents = {
  levels: [{ level: 1, italic: true, marginBottom: pt(LEAD), numberFontFamily: 'Italiana',
    numberFontWeight: 400, numberColor: col('sage'), numberWidth: mm(6), numberGap: mm(3) }],
  pageNumber: { fontFamily: 'Marcellus SC', fontSize: pt(9), color: col('muted'), width: mm(6) },
  leader: { char: '. ', gap: mm(2) }, // spaced dots, right-aligned so they line up
};
// #endregion

// #region ornament: a resource type for artwork that prints no caption and no label
// No caption prefix and no caption: the sprig prints bare, where ::resource{id="sprig"} puts
// it (double quotes: gotcha resource-double-quotes), a fifth of the measure wide, centred.
const ornament = { id: 'ornament', name: 'Ornament', shortLabel: '', captionPrefix: '',
  numberingTemplate: '{n}', resetOn: 'never', counterFormat: 'decimal',
  defaultPlacement: { position: 'here', width: 0.2, align: 'center' } };
// #endregion

const proseStyles = [ // the note on the text and the colophon, under the contents
  { id: 'note', fontSize: pt(9.5), lineHeight: pt(13) },
  { id: 'colophon', fontSize: pt(8), lineHeight: pt(11), color: col('muted'), textAlign: 'left',
    firstLineIndent: pt(0), marginTop: pt(LEAD) },
];
const folio = (pages) => ({ kind: 'text', id: `folio-${pages}`, content: '{pageNumber}', pages,
  fontFamily: 'Marcellus SC', fontSize: pt(9), color: col('muted'), align: 'center',
  placement: { anchor: { to: 'container', edge: 'top' }, offset: { y: mm(10) } } });

const config = () => ({ // a factory: the engine caches resolved configs per object
  colorPalette,
  // The list replaces Figure and Table; a book with figures spreads defaultResourceTypes() in.
  resourceTypes: [ornament],
  page: { // mirror: left is the inner margin; 150 dpi is for the screen
    sizePreset: 'custom', width: mm(TRIM_W), height: mm(TRIM_H), dpi: 150,
    backgroundColor: col('paper'),
    margins: { top: mm(22), bottom: mm(24), left: mm(22), right: mm(18), mirror: true },
  },
  layout: { layoutType: 'single' },
  bodyText: { // the note's prose: justified, hyphenated (en-us), spaces 0.8–1.6 of normal
    fontFamily: 'Sorts Mill Goudy', fontSize: pt(11), lineHeight: pt(LEAD), color: col('ink'),
    boldColor: col('ink'), italicColor: col('ink'), firstLineIndent: mm(4),
    indentAfterHeading: false, minWordSpacing: 0.8, maxWordSpacing: 1.6,
  },
  headings: {
    fontFamily: 'Sorts Mill Goudy', fontWeight: 400, color: col('ink'),
    levels: [poems, { level: 2, fontFamily: 'Marcellus SC', fontSize: pt(9), lineHeight: pt(LEAD),
      color: col('sage'), marginTop: pt(0), marginBottom: pt(0) }],
  },
  headingStyles: front,
  toc: contents,
  paragraphStyles: [verse, ...lineStyles, ...proseStyles],
  header: { elements: [] }, // no running heads: each poem starts a page under its own title
  footer: { elements: [folio('opener'), folio('body')] }, // centred; never on a blank page
});

// ─── 2 · Content ────────────────────────────────────────────────────────────
const markdown = String.raw`---
Muestra en Markdown · 188 líneas · content.en.md
title: "Pied Beauty"
subtitle: "Four poems of the natural world"
author: "Gerard Manley Hopkins"
---

# Pied Beauty {style="half-title"}

# Fern and Rowan {style="plate" caption="Fern and rowan: the ‘flitches of fern’ and the ‘beadbonny ash’ of Inversnaid"}

# Pied Beauty {style="title-page"}

# Contents {style="contents"}

:::toc

:::space{lines=2}

## A note on the text

:::paragraphs{style="note"}
This selection follows the first edition of the poems, edited by Robert Bridges in 1918, nearly thirty years after Hopkins’s death. Its spelling, accents and indents are kept, and lines that rhyme with one another start the same distance in. A line too long for the page is turned over, and the turnover is set deeper than the lines around it, so that it reads as part of the line above. No word is broken unless Hopkins broke it, as he did at the end of the first line of *The Windhover*. Under each poem is the date from Bridges’s notes, with the place when he gives one.
:::

:::paragraphs{style="colophon"}
Set in Sorts Mill Goudy, Italiana and Marcellus SC (SIL Open Font License). Text from Project Gutenberg eBook 22403, accents and indents from Wikisource. Plate and ornament drawn for this edition.
:::

# God’s Grandeur

:::paragraphs{style="verse"}
The world is charged with the grandeur of God.

    It will flame out, like shining from shook foil;

    It gathers to a greatness, like the ooze of oil

Crushed. Why do men then now not reck his rod?

Generations have trod, have trod, have trod;

    And all is seared with trade; bleared, smeared with toil;

    And wears man’s smudge and shares man’s smell: the soil

Is bare now, nor can foot feel, being shod.

:::space

And for all this, nature is never spent;

    There lives the dearest freshness deep down things;

And though the last lights off the black West went

    Oh, morning, at the brown brink eastward, springs—

Because the Holy Ghost over the bent

    World broods with warm breast and with ah! bright wings.
:::

:::paragraphs{style="date"}
23 February 1877
:::

# The Windhover

:::paragraphs{style="dedication"}
*To Christ our Lord*
:::

:::paragraphs{style="verse"}
I caught this morning morning’s minion, king-

    dom of daylight’s dauphin, dapple-dawn-drawn Falcon, in his riding

    Of the rolling level underneath him steady air, and striding

High there, how he rung upon the rein of a wimpling wing

In his ecstacy! then off, off forth on swing,

    As a skate’s heel sweeps smooth on a bow-bend: the hurl and gliding

    Rebuffed the big wind. My heart in hiding

Stirred for a bird,—the achieve of, the mastery of the thing!

:::space

Brute beauty and valour and act, oh, air, pride, plume, here

    Buckle! AND the fire that breaks from thee then, a billion

Times told lovelier, more dangerous, O my chevalier!

:::space

    No wonder of it: shéer plód makes plough down sillion

Shine, and blue-bleak embers, ah my dear,

    Fall, gall themselves, and gash gold-vermillion.
:::

:::paragraphs{style="date"}
St Beuno’s, 30 May 1877
:::

# Pied Beauty

:::paragraphs{style="verse"}
Glory be to God for dappled things—

  For skies of couple-colour as a brinded cow;

    For rose-moles all in stipple upon trout that swim:

Fresh-firecoal chestnut-falls; finches’ wings;

  Landscape plotted and pieced—fold, fallow, and plough;

    And áll trádes, their gear and tackle and trim.

:::space

All things counter, original, spare, strange;

  Whatever is fickle, freckled (who knows how?)

    With swift, slow; sweet, sour; adazzle, dim;

He fathers-forth whose beauty is past change:

                Praise him.
:::

:::paragraphs{style="date"}
St Beuno’s, Tremeirchion, summer 1877
:::

# Inversnaid

:::paragraphs{style="verse"}
This darksome burn, horseback brown,

His rollrock highroad roaring down,

In coop and in comb the fleece of his foam

Flutes and low to the lake falls home.

:::space

A windpuff-bonnet of fáwn-fróth

Turns and twindles over the broth

Of a pool so pitchblack, féll-frówning,

It rounds and rounds Despair to drowning.

:::space

Degged with dew, dappled with dew

Are the groins of the braes that the brook treads through,

Wiry heathpacks, flitches of fern,

And the beadbonny ash that sits over the burn.

:::space

What would the world be, once bereft

Of wet and of wildness? Let them be left,

O let them be left, wildness and wet;

Long live the weeds and the wilderness yet.
:::

:::paragraphs{style="date"}
28 September 1881
:::

::resource{id="sprig"}
`; // content.<lang>.md, inlined by the Cookbook

// #region art: a photogram of fern and rowan, and a rowan sprig for the ornament
let seed = 1877; // Mulberry32, a tiny seeded PRNG: never Math.random() in a recipe
const rand = () => {
  let r = Math.imul((seed = (seed + 0x6d2b79f5) | 0) ^ (seed >>> 15), 1 | seed);
  r = (r + Math.imul(r ^ (r >>> 7), 61 | r)) ^ r;
  return ((r ^ (r >>> 14)) >>> 0) / 4294967296;
};
const mix = (a, b, k) => `#${[1, 3, 5].map((i) => Math.round(parseInt(palette[a].slice(i, i + 2),
  16) * (1 - k) + parseInt(palette[b].slice(i, i + 2), 16) * k).toString(16).padStart(2, '0'))
  .join('')}`;
const f = (n) => n.toFixed(1);
const path = (d, fill, a = 1) => `<path d="${d}" fill="${fill}" fill-opacity="${a}"/>`;
const ring = (pts) => `M${pts.map(([x, y]) => `${f(x)} ${f(y)}`).join('L')}Z`;
const disk = (x, y, r, fill, a = 1) => `<circle cx="${f(x)}" cy="${f(y)}" r="${f(r)}" `
  + `fill="${fill}" fill-opacity="${a}"/>`;
const PX = 10; // a drawing w × h mm has a viewBox in tenths of a millimetre, w·PX × h·PX
const svgOf = (w, h, body) => `<svg xmlns="http://www.w3.org/2000/svg" width="${w * PX}" `
  + `height="${h * PX}" viewBox="0 0 ${w * PX} ${h * PX}">${body}</svg>`;
// A cubic Bézier and its unit normal at t.
const bez = ([p0, p1, p2, p3], t) => {
  const u = 1 - t;
  const coord = (i) => u * u * u * p0[i] + 3 * u * u * t * p1[i] + 3 * u * t * t * p2[i]
    + t * t * t * p3[i];
  const dt = (i) => 3 * u * u * (p1[i] - p0[i]) + 6 * u * t * (p2[i] - p1[i])
    + 3 * t * t * (p3[i] - p2[i]);
  const [dx, dy] = [dt(0), dt(1)];
  const len = Math.hypot(dx, dy) || 1;
  return { x: coord(0), y: coord(1), a: Math.atan2(dy, dx), nx: -dy / len, ny: dx / len };
};
// A stalk: the curve drawn as a filled band tapering from w0 to w1.
const stalk = (curve, w0, w1) => {
  const left = [];
  const right = [];
  for (let i = 0; i <= 40; i++) {
    const p = bez(curve, i / 40);
    const w = (w0 + (w1 - w0) * (i / 40)) / 2;
    left.push([p.x + p.nx * w, p.y + p.ny * w]);
    right.unshift([p.x - p.nx * w, p.y - p.ny * w]);
  }
  return ring([...left, ...right]);
};
// A leaf blade from its base (x, y) along angle a: length l, half-width w, `teeth` serrations.
const blade = (x, y, a, l, w, teeth = 0) => {
  const [c, s] = [Math.cos(a), Math.sin(a)];
  const at = (u, v) => [x + u * c - v * s, y + u * s + v * c];
  const side = (sign) => Array.from({ length: 25 }, (_, i) => {
    const t = i / 24;
    let h = w * Math.sin(Math.PI * t ** 0.85) ** 0.9;
    if (teeth && t > 0.25) h *= 1 - 0.18 * ((t * teeth) % 1);
    return at(l * t, sign * h);
  });
  return ring([...side(1), ...side(-1).reverse()]);
};
// A fern frond: a curving rachis, alternate pinnae longest near the base, each a comb of lobes.
function fern(curve, reach, lobe) {
  const d = [stalk(curve, 20, 3)];
  const n = 30;
  for (let i = 3; i < n; i++) {
    const t = i / n;
    const p = bez(curve, t);
    const side = i % 2 ? 1 : -1;
    const len = reach * Math.sin(Math.PI * Math.min(1, (1 - t) * 1.25) / 2) ** 1.2;
    const pa = p.a + side * (1.05 - 0.35 * t); // pinnae lean towards the tip
    const [cx, cy] = [Math.cos(pa), Math.sin(pa)];
    const sweep = side * 0.18; // each pinna arches a little towards the tip
    const axis = [[p.x, p.y], [p.x + cx * len / 3, p.y + cy * len / 3],
      [p.x + Math.cos(pa - sweep) * len * 0.68, p.y + Math.sin(pa - sweep) * len * 0.68],
      [p.x + Math.cos(pa - sweep * 2) * len, p.y + Math.sin(pa - sweep * 2) * len]];
    d.push(stalk(axis, 5, 1.2));
    const k = Math.max(2, Math.round(len / (lobe * 0.82)));
    for (let j = 0; j < k; j++) {
      const s = (j + 0.5) / (k + 0.3);
      const q = bez(axis, s);
      const size = lobe * (1.05 - s * 0.6) * (0.92 + rand() * 0.16);
      for (const sgn of [1, -1]) d.push(blade(q.x, q.y, q.a + sgn * 0.95, size * 1.6, size * 0.5));
    }
    const tip = bez(axis, 1);
    d.push(blade(tip.x, tip.y, tip.a, lobe * 1.2, lobe * 0.35));
  }
  return d.join('');
}
// Rowan: a woody stem, pinnate leaves of serrated leaflets and a dome of berries.
function rowan(curve, leaves, cluster, scale = 1) {
  const d = [stalk(curve, 22 * scale, 8 * scale)];
  const dots = [];
  for (const [t, side, len] of leaves) {
    const p = bez(curve, t);
    const a = p.a + side * 0.9;
    const l = len * scale;
    const rachis = [[p.x, p.y], [p.x + Math.cos(a) * l / 3, p.y + Math.sin(a) * l / 3],
      [p.x + Math.cos(a + side * 0.12) * l * 2 / 3, p.y + Math.sin(a + side * 0.12) * l * 2 / 3],
      [p.x + Math.cos(a + side * 0.25) * l, p.y + Math.sin(a + side * 0.25) * l]];
    d.push(stalk(rachis, 5 * scale, 2 * scale));
    for (let j = 0; j < 6; j++) {
      const q = bez(rachis, 0.18 + j * 0.15);
      const size = (130 - j * 6) * scale;
      for (const sgn of [1, -1]) d.push(blade(q.x, q.y, q.a + sgn * 1.25, size, size * 0.22, 7));
    }
    const tip = bez(rachis, 1);
    d.push(blade(tip.x, tip.y, tip.a, 125 * scale, 27 * scale, 7));
  }
  const [cx, cy, r] = cluster; // berries on short stalks, heaped into a dome
  for (let i = 0; i < 34; i++) {
    const a = -Math.PI * (0.08 + rand() * 0.84);
    const dist = r * Math.sqrt(rand());
    const [bx, by] = [cx + Math.cos(a) * dist * 1.25, cy + Math.sin(a) * dist * 0.8];
    d.push(stalk([[cx, cy + r * 0.5], [cx, cy], [bx, by + 20 * scale], [bx, by]], 3 * scale,
      2 * scale));
    dots.push([bx, by, (17 + rand() * 5) * scale]);
  }
  return { d: d.join(''), dots };
}

// The frontispiece: a photogram, the specimens left in paper white on a brushed field of
// sage, the way Anna Atkins printed her ferns in cyanotype.
function photogram(w, h) {
  const [W, H] = [w * PX, h * PX];
  const [x0, y0, x1, y1] = [70, 70, W - 70, H - 170]; // the brushed-on coating
  const phase = [rand(), rand(), rand()].map((r) => r * 6.3);
  const wob = (v, amp) => amp * (Math.sin(v / 37 + phase[0]) * 0.5 + Math.sin(v / 13 + phase[1])
    * 0.3 + Math.sin(v / 5.3 + phase[2]) * 0.2) + (rand() - 0.5) * amp * 0.4;
  const edge = [];
  for (let x = x0; x <= x1; x += 10) edge.push([x, y0 + wob(x, 7)]);
  for (let y = y0; y <= y1; y += 10) edge.push([x1 + wob(y, 16), y]);
  for (let x = x1; x >= x0; x -= 10) edge.push([x, y1 + wob(x + 99, 7)]);
  for (let y = y1; y >= y0; y -= 10) edge.push([x0 + wob(y + 55, 16), y]);
  const out = [`<defs><radialGradient id="g" cx="0.42" cy="0.38" r="0.85">`
    + `<stop offset="0" stop-color="${mix('sage', 'paper', 0.06)}"/>`
    + `<stop offset="1" stop-color="${mix('sage', 'ink', 0.4)}"/></radialGradient></defs>`,
  path(ring(edge), 'url(#g)')]; // a single path with a gradient fill; only its outline is ragged
  const frond = fern([[520, 1960], [380, 1350], [640, 700], [930, 190]], 400, 26);
  const tree = rowan([[1090, 1960], [1160, 1450], [960, 1060], [1000, 640]],
    [[0.2, -1, 300], [0.4, 1, 280], [0.58, -1, 290], [0.76, 1, 250]], [1000, 600, 150], 0.85);
  // Opaque, as a photogram is: where the two specimens overlap they print one white.
  out.push(path(frond, palette.paper), path(tree.d, palette.paper));
  for (const [x, y, r] of tree.dots) out.push(disk(x, y, r, palette.paper), disk(x, y - r * 0.2,
    r * 0.22, mix('sage', 'paper', 0.5)));
  return svgOf(w, h, out.join(''));
}

// The ornament: a rowan leaf laid flat, with a bunch of berries at its tip.
function sprig() {
  const [w, h] = [36, 12];
  const rib = [[16, 66], [90, 56], [170, 56], [236, 60]];
  const d = [stalk(rib, 6, 3)];
  for (let j = 0; j < 5; j++) {
    const q = bez(rib, 0.12 + j * 0.19);
    const size = 50 - j * 3;
    for (const sgn of [1, -1]) d.push(blade(q.x, q.y, q.a + sgn * 1.1, size, size * 0.22, 8));
  }
  const tip = bez(rib, 1);
  d.push(blade(tip.x, tip.y, tip.a, 44, 10.5, 8));
  const out = [path(d.join(''), palette.sage)];
  for (const [dx, dy, r] of [[34, -16, 9], [44, 2, 10], [30, 14, 9], [52, -12, 8.5],
    [58, 10, 8], [22, -2, 8]]) {
    const [bx, by] = [262 + dx, 60 + dy];
    out.push(path(stalk([[240, 64], [252, 66], [bx - 10, by + 2], [bx, by]], 2.6, 1.8),
      palette.sage), disk(bx, by, r, palette.sepia));
  }
  return svgOf(w, h, out.join(''));
}

const art = { plate: photogram(TRIM_W, TRIM_H), sprig: sprig() };
for (const [id, svg] of Object.entries(art)) await loadSvg(`${id}.svg`, svg);
// #endregion

// Nothing cites them: designs show the plate and the sprig, ::resource sets the tailpiece.
const svgResource = (id, w, h, altText) => ({ id, typeId: 'ornament', kind: 'svg', altText,
  createdAt: 0, updatedAt: 0, svg: { fileId: `${id}.svg`, width: w * PX, height: h * PX } });
const resources = [
  svgResource('plate', TRIM_W, TRIM_H, 'A photogram of a fern frond and a sprig of rowan in '
    + 'berry, left white on a brushed sage ground.'),
  svgResource('sprig', 36, 12, 'Ornament: a rowan leaf with a bunch of berries.'),
];

// ─── 3 · Fonts ──────────────────────────────────────────────────────────────
// Loaded before the first build (gotcha: fonts-first). None of the three ships a bold.
const FONTS = { 'Sorts Mill Goudy': ['400', '400i'], Italiana: ['400'], 'Marcellus SC': ['400'] };

// ─── 4 · Build & show ───────────────────────────────────────────────────────
await loadFonts(FONTS, markdown);
// :::toc lists the page each poem lands on: the build lays out again until those settle.
const verses = indentVerse(markdown); // the leading spaces of verse, as em spaces
const doc = await buildWithFonts(() => buildDocument({ markdown: verses, resources }, config()),
  markdown);
showPages(doc, { title: 'Pied Beauty · four poems by Gerard Manley Hopkins' });

Kit · core, fonts, viewer, images: igual en todas las recetas · 270 líneas
// ─── Kit ── helpers shared by every Cookbook recipe · postext.dev/cookbook ─────

// ─── Kit · core v1 ── the same in every recipe · postext.dev/cookbook ─────────
function mm(value) { return { value, unit: 'mm' }; }
function pt(value) { return { value, unit: 'pt' }; }
function em(value) { return { value, unit: 'em' }; }
/** The sample language's string: t({ en: 'Figure', es: 'Figura' }). */
function t(strings) { return strings[LANG] ?? Object.values(strings)[0]; }
/** A file in this recipe's assets folder, served from the Postext repo by jsDelivr. */
function asset(file) { return `https://cdn.jsdelivr.net/gh/drnachio/postext@main/cookbook/${RECIPE}/assets/${file}`; }

// ─── Kit · fonts v1 ── the same in every recipe · postext.dev/cookbook ────────
// Postext measures text with the faces the browser has loaded, and caches the
// widths, so every face must be ready before the first build. Faces come from
// Fontsource: the same static files the PDF embeds, so screen and PDF agree.

/** faces = { 'Family Name': ['400', '400i', '700'] }. `text` is the sample:
 *  letters beyond Latin-1 (č, ł, ő…) also load the latin-ext files. With
 *  `optional`, a face Fontsource does not ship is skipped instead of failing.
 *  Resolves to the number of faces added. */
async function loadFonts(faces, text = '', { optional = false } = {}) {
  kitStatus('Loading fonts…');
  const ranges = {
    latin: 'U+0000-00FF,U+0131,U+0152-0153,U+02BB-02BC,U+02C6,U+02DA,U+02DC,U+0304,U+0308,U+0329,'
      + 'U+2000-206F,U+20AC,U+2122,U+2191,U+2193,U+2212,U+2215,U+FEFF,U+FFFD',
    'latin-ext': 'U+0100-02BA,U+02BD-02C5,U+02C7-02CC,U+02CE-02D7,U+02DD-02FF,U+0304,U+0308,U+0329,'
      + 'U+1D00-1DBF,U+1E00-1E9F,U+1EF2-1EFF,U+2020,U+20A0-20AB,U+20AD-20C0,U+2113,U+2C60-2C7F,U+A720-A7FF',
  };
  const subsets = /[Ā-˿Ḁ-ỿ]/.test(text) ? ['latin', 'latin-ext'] : ['latin'];
  const jobs = [];
  let added = 0;
  for (const [family, specs] of Object.entries(faces)) {
    const id = fontsourceId(family);
    const meta = optional ? await fontsourceMeta(family) : null;
    for (const spec of new Set(specs)) {
      const weight = parseInt(spec, 10);
      const style = spec.endsWith('i') ? 'italic' : 'normal';
      if (hasFace(family, weight, style)) continue;
      if (optional && !(meta?.weights.includes(weight) && meta.styles.includes(style))) continue;
      for (const subset of subsets) {
        const url = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-${subset}-${weight}-${style}.woff2`;
        const face = new FontFace(family, `url(${url}) format('woff2')`,
          { weight: String(weight), style, unicodeRange: ranges[subset] });
        jobs.push(face.load().then((ready) => { document.fonts.add(ready); added++; }, () => {
          if (subset === 'latin' && !optional) throw new Error(`Fontsource has no ${family} ${weight} ${style}`);
        }));
      }
    }
  }
  await Promise.all(jobs).catch((error) => { kitFail(error); throw error; });
  return added;
}

/** Runs `build` (a buildDocument or buildBundle call) and checks the faces
 *  the pages use. A regular face missing from FONTS is loaded with a warning;
 *  bold and italic variants are loaded when the family ships them. Then the
 *  measurement caches are cleared and the build runs again. */
async function buildWithFonts(build, text = '') {
  const tried = new Set();
  for (let round = 0; round < 3; round++) {
    kitStatus('Laying out…');
    await new Promise(requestAnimationFrame);          // let the status paint first
    const result = await Promise.resolve().then(build).catch((error) => { kitFail(error); throw error; });
    const wanted = { base: {}, variants: {} };
    for (const { font, base } of [result].flat().flatMap(fontStringsOf)) {
      const { family, weight, style } = parseFont(font);
      const key = `${family}|${weight}|${style}`;
      if (tried.has(key) || hasFace(family, weight, style)) continue;
      tried.add(key);
      (wanted[base ? 'base' : 'variants'][family] ??= []).push(`${weight}${style === 'italic' ? 'i' : ''}`);
    }
    if (Object.keys(wanted.base).length) {
      console.warn(`[cookbook] FONTS does not list ${JSON.stringify(wanted.base)}: loading them.`);
    }
    const added = await loadFonts(wanted.base, text) + await loadFonts(wanted.variants, text, { optional: true });
    if (added === 0) return result;
    clearMeasurementCache();
  }
  throw new Error('The fonts did not settle after three builds.');
}

/** Every font string of the layout. `base` marks a block's own face; its
 *  bold, italic and bold-italic variants are listed whether or not used. */
function fontStringsOf(doc) {
  const found = new Map();
  const walk = (node) => {
    if (!node || typeof node !== 'object') return;
    if (Array.isArray(node)) { node.forEach(walk); return; }
    for (const [key, value] of Object.entries(node)) {
      if (typeof value === 'string' && /fontString$/i.test(key)) {
        found.set(value, found.get(value) || key === 'fontString');
      } else if (value && typeof value === 'object') walk(value);
    }
  };
  walk(doc.pages);
  walk(doc.blocks);
  return [...found].map(([font, base]) => ({ font, base }));
}

/** '700 37.5px Open Sans' / 'italic 400 13px "Source Serif 4"' → { family, weight, style }.
 *  A string with no weight ('95.8px Young Serif', from a design text) is 400. */
function parseFont(font) {
  const m = /^(?:(italic|oblique)\s+)?(?:small-caps\s+)?(?:(\d+|bold|normal)\s+)?[\d.]+px\s+(.+)$/.exec(font.trim());
  if (!m) throw new Error(`Unexpected font string: ${font}`);
  const weight = m[2] === 'bold' ? 700 : !m[2] || m[2] === 'normal' ? 400 : Number(m[2]);
  return { family: m[3].replace(/^["']|["']$/g, ''), weight, style: m[1] ? 'italic' : 'normal' };
}

/** True when a loaded FontFace covers exactly this family, weight and style
 *  (document.fonts.check() is also true for families nobody declared). */
function hasFace(family, weight, style) {
  for (const face of document.fonts) {
    if (face.status !== 'loaded' || face.style !== style) continue;
    if (face.family.replace(/^["']|["']$/g, '') !== family) continue;
    const [low, high = low] = face.weight.split(' ').map(Number);
    if (weight >= low && weight <= high) return true;
  }
  return false;
}

/** Fontsource's id for a family: 'Source Serif 4' → 'source-serif-4'. */
function fontsourceId(family) { return family.toLowerCase().replace(/\s+/g, '-'); }

/** The weights and styles a family ships ({ weights: [400, 700], styles: ['normal', 'italic'] }), or null. */
function fontsourceMeta(family) {
  fontsourceMeta.cache ??= new Map();
  const id = fontsourceId(family);
  if (!fontsourceMeta.cache.has(id)) {
    fontsourceMeta.cache.set(id, fetch(`https://api.fontsource.org/v1/fonts/${id}`)
      .then((res) => (res.ok ? res.json() : null), () => null));
  }
  return fontsourceMeta.cache.get(id);
}

// ─── Kit · viewer v1 ── the same in every recipe · postext.dev/cookbook ───────
/** Shows the pages as facing spreads on a dark desk: the first page is a
 *  recto on its own, then verso | recto pairs, as in a bound book. Pages
 *  are painted when they scroll near the screen. */
function showPages(docs, { title, width = 460 } = {}) {
  const root = viewer(title);
  const pages = [docs].flat().flatMap((doc) =>
    doc.pages.map((page) => ({ doc, page, n: (doc.pageIndexOffset ?? 0) + page.index })));
  const spreads = [];
  let verso = null;
  for (const p of pages) {
    if (p.n % 2 === 1) { if (verso) spreads.push([verso, null]); verso = p; }
    else { spreads.push([verso, p]); verso = null; }
  }
  if (verso) spreads.push([verso, null]);
  const density = Math.min(window.devicePixelRatio || 1, 2);
  showPages.painter?.disconnect();
  const painter = new IntersectionObserver((entries) => {
    for (const { isIntersecting, target } of entries) {
      if (!isIntersecting) continue;
      painter.unobserve(target);
      const { doc, page } = target.postext;
      renderPageToCanvas(page, doc, target, { scale: (width * density) / page.width });
    }
  }, { rootMargin: '800px' });
  showPages.painter = painter;
  root.replaceChildren(...spreads.map((pair) => {
    const spread = document.createElement('div');
    spread.className = 'pt-spread';
    for (const p of pair) {
      const figure = document.createElement('figure');
      if (p) {
        const label = p.page.pageLabel || String(p.n + 1);
        const canvas = document.createElement('canvas');
        canvas.postext = p;
        canvas.style.aspectRatio = `${p.page.width} / ${p.page.height}`;
        canvas.setAttribute('role', 'img');
        canvas.setAttribute('aria-label', `Page ${label}`);
        const folio = document.createElement('figcaption');
        folio.textContent = label;
        figure.append(canvas, folio);
        painter.observe(canvas);
      } else figure.className = 'pt-blank';
      spread.append(figure);
    }
    return spread;
  }));
  kitStatus(`${pages.length} ${pages.length === 1 ? 'page' : 'pages'}`);
  document.documentElement.dataset.postext = 'ready';
  return pages.length;
}

/** The desk, the bar and the error reporting, created once. */
function viewer(title) {
  if (!document.getElementById('pt-kit')) {
    document.head.insertAdjacentHTML('beforeend', `<style id="pt-kit">
      :root { color-scheme: dark; }
      body { margin: 0; background: #0e1014; color: #b9bcc4; font: 13px/1.45 system-ui, sans-serif; }
      #pt-bar { position: sticky; top: 0; z-index: 1; display: flex; flex-wrap: wrap; align-items: center;
        gap: 6px 16px; padding: 10px 16px; background: rgb(14 16 20 / .92); backdrop-filter: blur(6px);
        border-bottom: 1px solid #23262d; }
      #pt-bar strong { color: #f4f1ea; font-weight: 600; }
      #pt-actions { display: flex; gap: 12px; margin-left: auto; }
      #pt-actions a, #pt-actions button { color: #d8a21a; font: inherit; background: none; border: 0; padding: 0; cursor: pointer; }
      #pages { display: grid; justify-items: center; gap: 48px; padding: 32px 16px 72px; }
      .pt-spread { display: flex; }
      .pt-spread figure { margin: 0; width: min(460px, 44vw); }
      .pt-spread canvas { display: block; width: 100%; background: #fff;
        box-shadow: 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figure:first-child canvas { box-shadow: inset -14px 0 14px -14px rgb(0 0 0 / .18), 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figcaption { margin-top: 10px; text-align: center; font: 600 10px/1 system-ui, sans-serif;
        letter-spacing: .18em; text-transform: uppercase; color: #6c7079; }
      .pt-blank { visibility: hidden; }
      @media (max-width: 760px) {
        .pt-spread { flex-direction: column; gap: 32px; }
        .pt-spread figure { width: min(460px, 92vw); }
        .pt-blank { display: none; }
      }
    </style>`);
    document.body.insertAdjacentHTML('afterbegin',
      '<header id="pt-bar"><strong id="pt-title"></strong><span id="pt-status" role="status"></span><span id="pt-actions"></span></header>');
    document.getElementById('pt-title').textContent = document.title || 'Postext';
    addEventListener('error', (event) => kitFail(event.error ?? event.message));
    addEventListener('unhandledrejection', (event) => kitFail(event.reason));
  }
  if (title) document.getElementById('pt-title').textContent = title;
  return document.getElementById('pages')
    ?? document.body.appendChild(Object.assign(document.createElement('main'), { id: 'pages' }));
}

function kitStatus(text) {
  viewer();
  document.getElementById('pt-status').textContent = text;
}

function kitFail(error) {
  document.documentElement.dataset.postext = 'error';
  kitStatus(`Error: ${error?.message ?? error}`);
}

// ─── Kit · images v1 ── recipes with pictures · postext.dev/cookbook ──────────
/** Registers a photo or PNG for the canvas and keeps its bytes for the PDF.
 *  fetch → ImageBitmap never taints the canvas (a plain cross-origin <img> would). */
async function loadImage(fileId, url) {
  const res = await fetch(url);
  if (!res.ok) throw new Error(`Image not found (${res.status}): ${url}`);
  const bytes = new Uint8Array(await res.arrayBuffer());
  registerResourceImage(fileId, await createImageBitmap(new Blob([bytes])));
  (loadImage.bytes ??= new Map()).set(fileId, bytes);
}

/** Registers SVG markup (drawn in code, or fetched) as a vector image. */
async function loadSvg(fileId, svg) {
  const img = new Image();
  await img.decode();
  registerResourceImage(fileId, img);
  (loadImage.bytes ??= new Map()).set(fileId, new TextEncoder().encode(svg));
}

/** renderToPdf({ resourceBytes: imageBytes }) */
function imageBytes(fileId) { return loadImage.bytes?.get(fileId); }

/** renderToHtml({ resourceImageUrl: imageUrl }) */
function imageUrl(fileId) {
  const bytes = imageBytes(fileId);
  if (!bytes) return undefined;
  imageUrl.urls ??= new Map();
  if (!imageUrl.urls.has(fileId)) {
    const type = /\.svg$/i.test(fileId) ? 'image/svg+xml' : /\.png$/i.test(fileId) ? 'image/png' : 'image/jpeg';
    imageUrl.urls.set(fileId, URL.createObjectURL(new Blob([bytes], { type })));
  }
  return imageUrl.urls.get(fileId);
}

// ─── /Kit ───────────────────────────────────────────────────────────────────────
