En pocas palabras

Dos páginas de un cómic japonés. Las japonesas llevan el texto de arriba abajo en columnas estrechas; las demás ediciones mantienen el orden japonés de las viñetas, empezando arriba a la derecha.

Lo que vas a componer

Las dos primeras páginas de un manga de kendo, 前の晩 (La noche antes), escrito para esta receta y dibujado en blanco y negro: Hana entrena sola la víspera del torneo de la prefectura, Sora le lleva un amuleto del santuario y el entrenador los manda a casa. Primero va el original japonés, rotulado como en una revista semanal: letra antigua (kana de corte Mincho, kanji de corte Gothic), bocadillos altos en vez de anchos y sin punto al final. Enfrente, las mismas dos páginas en la lengua de esta página (en inglés en la página japonesa), empezando también por la viñeta de arriba a la derecha, como se publica el manga con licencia desde principios de los 2000. El formato es B6, 128 × 182 mm, el del tankōbon.

Esta receta responde a

¿Cómo maqueto un manga que se lea de derecha a izquierda?
¿Cómo rotulo japonés en vertical dentro de los bocadillos?

La respuesta corta

script.js · líneas 44–60en el código completo

const comics = (lang) => ({
  // The pages were drawn for right-to-left reading: panel 1 sits top right. The
  // reading direction stays 'auto', which follows the art in a left-to-right
  // language too: the English page keeps the Japanese panel order.
  artDirection: 'rtl',
  mirrorArt: false, // never flop the art: Hana's grip on the sword, the kimono's fold
  gutter: { horizontal: mm(4.5), vertical: mm(2) }, // a tier gap twice the panel gap
  panel: { borderWidth: pt(0.9), borderColor: col('ink'), background: col('paper') },
  lettering: {
    fontFamily: EDITIONS[lang].faces[0], color: col('ink'),
    fontSize: pt(['ja', 'zh'].includes(lang) ? 8.5 : 7.5), // one size per edition
    // 'auto' sets Japanese in columns of 8 characters at most and drops the final 。.
    // Chinese goes in columns too: a book bound on the right never mixes the two.
    writingMode: lang === 'zh' ? 'vertical' : 'auto',
  },
  balloonStyles: balloons(),
});

Ingredientes

Funciones: Sentido de lectura y orden del manga Rotulación de cómic Rotular en otros idiomas Texto vertical Fuentes chinas, japonesas y coreanas Libros encuadernados por la derecha División en viñetas Imagen y recorte de la viñeta Personajes y anclas Páginas de cómic Estilos de bocadillo Onomatopeyas Paleta de color semántica Páginas en un canvas Exportación a PDF
También usa: Corte de líneas en chino Bordes y calles de las viñetas Furigana: lecturas en kana sobre los kanji Color del papel Fuentes incrustadas en el PDF Figuras y tablas como recursos Ruby: lecturas en pinyin y zhuyin Números en pie en texto vertical
Tipografía: Zen Antique, Dela Gothic One, Comic Neue, Bangers, Noto Sans SC, ZCOOL KuaiLe, Playpen Sans Arabic, Lalezar (SIL OFL 1.1)
Recursos: kendo-charm.jpg
El viejo dojo de madera del instituto al anochecer, con las puertas abiertas e iluminadas (Generated With Diffusion Models, original)
Hana, sola en el dojo, alza la espada de bambú sobre la cabeza (Generated With Diffusion Models, original)
Sora se asoma por la puerta corredera con un amuleto (Generated With Diffusion Models, original)
Primer plano del rostro sudoroso de Hana (Generated With Diffusion Models, original)
Sora le tiende el amuleto a Hana (Generated With Diffusion Models, original)
El entrenador Mori en la puerta, a contraluz, de brazos cruzados (Generated With Diffusion Models, original)
Primer plano de la media sonrisa del entrenador Mori (Generated With Diffusion Models, original)
Hana se ata el amuleto a la armadura mientras Sora se rasca la cabeza (Generated With Diffusion Models, original)
Hana y Sora en la azotea del instituto al atardecer, de espaldas (Generated With Diffusion Models, original)
API: buildDocumentclearMeasurementCachedecompressWoff2registerResourceImagerenderPageToCanvasrenderToPdf

Elaboración

#1 · Lee en el sentido en que se dibujó

El código es la respuesta corta de arriba. Un mangaka compone cada página desde arriba a la derecha: la primera viñeta, el primer personaje que habla y el recorrido de la mirada por cada franja empiezan ahí. artDirection: 'rtl' se lo dice al motor, y con el sentido de lectura en 'auto' todas las ediciones siguen al dibujo; una edición árabe se leería de derecha a izquierda de todos modos. El dibujo nunca se refleja. Las editoriales occidentales invertían el manga hasta 2002, más o menos, y los lectores veían a todos los espadachines volverse zurdos y los kimonos cruzarse al revés: dejar las páginas como se dibujaron le cuesta al lector una costumbre, e invertirlas le cuesta el dibujo. Cada :::page lleva su división, 30 / 34 [46 | *] / * [44 | *], y la primera celda de cada franja se coloca a la derecha (sentido de lectura).

#2 · Marca a cada personaje una sola vez, sobre el dibujo

script.js · líneas 235–355en el código completo

const ART = { // fractions of the picture: the same in every language
  dojo: {
    alt: t({ en: 'The old wooden kendo dojo at dusk, its doors open and lit.',
      es: 'El viejo dojo de madera al anochecer, con las puertas abiertas e iluminadas.',
      ca: 'L’antic dojo de fusta al capvespre, amb les portes obertes i il·luminades.',
      pt: 'O velho dojô de madeira ao anoitecer, com as portas abertas e iluminadas.',
      zh: '黄昏时分的老木造剑道场，门敞开着，里面亮着灯。',
      ar: 'قاعة الكندو الخشبية القديمة عند الغسق، أبوابها مفتوحة ومضاءة.',
      ja: '夕暮れの古い木造の剣道場。戸が開いて、中に明かりがともっている。' }),
  safeArea: { x: 0.45, y: 0.32, width: 0.5, height: 0.51 },
  anchors: [{ id: 'dojo', x: 0.66, y: 0.63 }] },
  swing: {
    alt: t({ en: 'Hana, alone in the dojo, swings her bamboo sword overhead.',
      es: 'Hana, sola en el dojo, alza la espada de bambú sobre la cabeza.',
      ca: 'La Hana, sola al dojo, aixeca l’espasa de bambú per sobre del cap.',
      pt: 'Hana, sozinha no dojô, ergue a espada de bambu acima da cabeça.',
      zh: '花独自在道场里，把竹剑高举过头。',
      ar: 'هانا وحدها في القاعة ترفع سيف الخيزران فوق رأسها.',
      ja: 'ひとり道場で、竹刀を頭上に振りかぶる花。' }),
  safeArea: { x: 0.36, y: 0, width: 0.31, height: 0.5 },
  avoid: [{ x: 0.43, y: 0, width: 0.17, height: 0.12 }],
  anchors: [{ id: 'hana', x: 0.535, y: 0.28, head: { x: 0.53, y: 0.22 },
    face: { x: 0.49, y: 0.14, width: 0.11, height: 0.17 } }] },
  doorway: {
    alt: t({ en: 'Sora peeks round the sliding door, holding a shrine charm.',
      es: 'Sora se asoma por la puerta corredera con un amuleto en la mano.',
      ca: 'En Sora treu el cap per la porta corredissa amb un amulet a la mà.',
      pt: 'Sora espia pela porta de correr com um amuleto na mão.',
      zh: '空从拉门后探出头，手里攥着护身符。',
      ar: 'سورا يطلّ من وراء الباب المنزلق وفي يده تميمة.',
      ja: 'お守りを手に、引き戸の陰からのぞく空。' }),
  safeArea: { x: 0.37, y: 0.09, width: 0.34, height: 0.5 },
  avoid: [{ x: 0.49, y: 0.41, width: 0.08, height: 0.1 }],
  anchors: [{ id: 'sora', x: 0.545, y: 0.31, head: { x: 0.55, y: 0.22 },
    face: { x: 0.47, y: 0.16, width: 0.2, height: 0.18 } }] },
  closeup: {
    alt: t({ en: "Close-up of Hana's sweating, startled face.",
      es: 'Primer plano del rostro sudoroso y sobresaltado de Hana.',
      ca: 'Primer pla de la cara suada i sobresaltada de la Hana.',
      pt: 'Primeiro plano do rosto suado e assustado de Hana.',
      zh: '花满脸是汗、吃了一惊的特写。',
      ar: 'لقطة قريبة لوجه هانا المتعرّق المذعور.',
      ja: '汗をかき、はっとした花の顔のアップ。' }),
  safeArea: { x: 0.27, y: 0.28, width: 0.43, height: 0.51 },
  anchors: [{ id: 'hana', x: 0.475, y: 0.665, head: { x: 0.45, y: 0.35 },
    face: { x: 0.3, y: 0.3, width: 0.4, height: 0.45 } }] },
  charm: {
    alt: t({ en: 'Sora holds out the charm; Hana looks at it, sword on her shoulder.',
      es: 'Sora le tiende el amuleto; Hana lo mira con la espada al hombro.',
      ca: 'En Sora li allarga l’amulet; la Hana el mira amb l’espasa a l’espatlla.',
      pt: 'Sora estende o amuleto; Hana olha para ele com a espada no ombro.',
      zh: '空递出护身符，花扛着竹剑看着它。',
      ar: 'سورا يمدّ التميمة، وهانا تنظر إليها والسيف على كتفها.',
      ja: '空がお守りを差し出し、竹刀を肩にかついだ花がそれを見る。' }),
  safeArea: { x: 0.21, y: 0.09, width: 0.56, height: 0.53 },
  avoid: [{ x: 0.43, y: 0.47, width: 0.06, height: 0.09 }],
  anchors: [{ id: 'sora', x: 0.325, y: 0.335, head: { x: 0.29, y: 0.22 },
    face: { x: 0.26, y: 0.17, width: 0.11, height: 0.2 } },
  { id: 'hana', x: 0.675, y: 0.335, head: { x: 0.665, y: 0.22 },
    face: { x: 0.62, y: 0.17, width: 0.11, height: 0.2 } }] },
  coach: {
    alt: t({ en: 'Coach Mori in the doorway, backlit, arms crossed.',
      es: 'El entrenador Mori en la puerta, a contraluz, de brazos cruzados.',
      ca: 'L’entrenador Mori a la porta, a contrallum, de braços plegats.',
      pt: 'O treinador Mori na porta, contra a luz, de braços cruzados.',
      zh: '森老师站在门口，背着光，双臂抱在胸前。',
      ar: 'المدرّب موري عند الباب، والضوء خلفه، عاقدًا ذراعيه.',
      ja: '逆光の戸口で腕を組んで立つ森先生。' }),
  safeArea: { x: 0.33, y: 0.13, width: 0.3, height: 0.32 },
  anchors: [{ id: 'mori', x: 0.425, y: 0.215, head: { x: 0.42, y: 0.17 },
    face: { x: 0.37, y: 0.13, width: 0.1, height: 0.11 } }] },
  smile: {
    alt: t({ en: "Close-up of Mori's stern face breaking into a small smile.",
      es: 'Primer plano del rostro severo de Mori, que esboza una sonrisa.',
      ca: 'Primer pla de la cara severa d’en Mori, que esbossa un somriure.',
      pt: 'Primeiro plano do rosto severo de Mori, que esboça um sorriso.',
      zh: '森老师严肃的脸上露出一丝笑意的特写。',
      ar: 'لقطة قريبة لوجه موري الصارم وقد ارتسمت عليه ابتسامة.',
      ja: '厳しい顔がふっとゆるむ森先生のアップ。' }),
  safeArea: { x: 0.43, y: 0.21, width: 0.51, height: 0.53 },
  anchors: [{ id: 'mori', x: 0.69, y: 0.52, head: { x: 0.6, y: 0.25 },
    face: { x: 0.45, y: 0.28, width: 0.45, height: 0.32 } }] },
  kneel: {
    alt: t({ en: 'Kneeling, Hana ties the charm to her armour; Sora scratches his head.',
      es: 'De rodillas, Hana se ata el amuleto a la armadura; Sora se rasca la cabeza.',
      ca: 'De genolls, la Hana es lliga l’amulet a l’armadura; en Sora es grata el cap.',
      pt: 'De joelhos, Hana amarra o amuleto na armadura; Sora coça a cabeça.',
      zh: '花跪坐着把护身符系在护具上，空挠着头。',
      ar: 'هانا جاثية تربط التميمة بدرعها، وسورا يحكّ رأسه.',
      ja: '正座してお守りを防具に結ぶ花と、頭をかく空。' }),
  safeArea: { x: 0.21, y: 0.08, width: 0.61, height: 0.48 },
  avoid: [{ x: 0.27, y: 0.43, width: 0.06, height: 0.12 }],
  anchors: [{ id: 'hana', x: 0.305, y: 0.245, head: { x: 0.3, y: 0.17 },
    face: { x: 0.25, y: 0.1, width: 0.11, height: 0.17 } },
  { id: 'sora', x: 0.7, y: 0.25, head: { x: 0.71, y: 0.15 },
    face: { x: 0.64, y: 0.1, width: 0.13, height: 0.18 } }] },
  roof: {
    alt: t({ en: 'Seen from behind, Hana and Sora sit on the school roof at sunset.',
      es: 'De espaldas, Hana y Sora sentados en la azotea del instituto al atardecer.',
      ca: 'D’esquena, la Hana i en Sora asseguts al terrat de l’institut a la posta.',
      pt: 'De costas, Hana e Sora sentados no terraço da escola ao pôr do sol.',
      zh: '夕阳下，花和空坐在学校楼顶的背影。',
      ar: 'هانا وسورا جالسان على سطح المدرسة عند الغروب، من الخلف.',
      ja: '夕焼けの屋上に並んで座る花と空の後ろ姿。' }),
  safeArea: { x: 0.24, y: 0.41, width: 0.47, height: 0.31 },
  anchors: [{ id: 'hana', x: 0.36, y: 0.52, head: { x: 0.36, y: 0.48 },
    face: { x: 0.31, y: 0.43, width: 0.11, height: 0.14 } },
  { id: 'sora', x: 0.63, y: 0.52, head: { x: 0.625, y: 0.47 },
    face: { x: 0.58, y: 0.41, width: 0.1, height: 0.15 } }] },
};
const panels = () => Promise.all([
  comicPanel('dojo', asset('kendo-dojo.jpg'), ART.dojo),
  comicPanel('swing', asset('kendo-swing.jpg'), ART.swing),
  comicPanel('doorway', asset('kendo-doorway.jpg'), ART.doorway),
  comicPanel('closeup', asset('kendo-closeup.jpg'), ART.closeup),
  comicPanel('charm', asset('kendo-charm.jpg'), ART.charm),
  comicPanel('coach', asset('kendo-coach.jpg'), ART.coach),
  comicPanel('smile', asset('kendo-smile.jpg'), ART.smile),
  comicPanel('kneel', asset('kendo-kneel.jpg'), ART.kneel),
  comicPanel('roof', asset('kendo-roof.jpg'), ART.roof),
]);

Las palabras cambian con el idioma; el dibujo no. Cada imagen lleva una zona segura que todo recorte respeta y, por cada personaje, una boca (adonde apunta el rabillo), una cabeza (para los bocadillos de pensamiento) y una cara que ningún bocadillo puede tapar, todo en fracciones de la imagen. Cada línea del guion nombra a quien habla, sora: …, y el motor coloca el bocadillo junto a ese personaje en cualquier idioma. Si quien habla no sale en la viñeta, como Sora cuando aparece el entrenador en la puerta, el rabillo va hacia el borde: sora{tail=bottom}.

#3 · Deja que cada idioma ponga sus bocadillos

script.js · líneas 64–71en el código completo

const balloons = () => [
  { id: 'speech', fill: col('paper'), stroke: col('ink'), strokeWidth: pt(0.6), roundness: 2 },
  { id: 'whisper', fill: col('paper'), stroke: col('ink'), roundness: 2 },
  { id: 'thought', fill: col('paper'), stroke: col('ink') },
  { id: 'inner', fill: col('tone'), stroke: col('tone'), strokeWidth: pt(0), italic: false },
  { id: 'caption', fill: col('paper'), stroke: col('ink'), strokeWidth: pt(0.5) },
  { id: 'sfx', color: col('ink'), haloColor: col('paper') },
];

Los estilos dicen qué clase de voz lleva cada bocadillo: un óvalo para hablar, un contorno discontinuo para susurrar, una nube para pensar y un recuadro gris para la voz interior de Hana. Cómo se colocan las palabras dentro es cosa de cada edición. En japonés, el motor compone columnas de ocho caracteres como mucho, quita el 。 que cierra un bocadillo y conserva el 、, pone de pie en un solo cuadratín las dos cifras de 第42回 (:tcy[42]) y junta !? en una sola celda. El guion da la lectura de cada nombre la primera vez que aparece, {一ノ瀬|いちのせ}, como hace el manga con el furigana sobre los nombres. En español, los mismos bocadillos se vuelven óvalos con líneas horizontales, y su orden sigue empezando por la derecha.

#4 · Carga las fuentes de cada edición con sus palabras

script.js · líneas 359–371en el código completo

const SFX = /^sfx[^:：\n]*[:：](.*)$/gm; // sound-effect lines: the second face sets them
async function loadEdition(lang) {
  const text = TEXT[lang];
  const [face, sfx] = EDITIONS[lang].faces;
  const faces = { [face]: FONTS[face], [sfx]: FONTS[sfx] };
  if (['ja', 'zh'].includes(lang)) { // CJK: only the files that hold these characters
    const effects = [...text.matchAll(SFX)].map((m) => m[1]).join('');
    await loadCjkFonts({ [face]: FONTS[face] }, text.replace(SFX, ''), { vertical: true });
    await loadCjkFonts({ [sfx]: FONTS[sfx] }, effects, { vertical: true });
  }
  if (lang === 'ar') await loadArabicFonts(faces, text);
  await loadComicFonts(faces, text); // the bold and italic the faces do not ship
}

Zen Antique y Dela Gothic One se publican en un centenar de archivos cada una, uno por bloque de caracteres: cada fuente se carga con las palabras que compone, los bocadillos la primera y las onomatopeyas la segunda, y la página solo descarga los archivos que necesita. loadComicFonts declara la negrita de un grito y la cursiva de una voz interior a partir de los archivos que estas fuentes sí tienen, así que la pantalla y el PDF dibujan las mismas letras.

#5 · Pon el original junto a cada edición

script.js · líneas 376–385en el código completo

const FACING = LANG === 'ja' ? 'en' : LANG; // Japanese readers see the English edition
const TEXT = { ja: original, [FACING]: LANG === 'ja' ? english : markdown };
await loadFonts(FONTS, Object.values(TEXT).join('\n'));
const resources = await panels();
const build = async (lang) => { // the same pictures and page; this language's lettering
  await loadEdition(lang);
  return buildWithFonts(() => buildDocument({ markdown: TEXT[lang], resources,
    continuation: { pageIndexOffset: 1 } }, edition(lang)), TEXT[lang]);
};
const docs = [await build('ja'), await build(FACING)];

Cada idioma de este sitio tiene su propia edición de las dos páginas, escrita en su content.<lang>.md, y cada edición queda frente al original japonés: /* @content@ja */ incluye content.ja.md en todas las ediciones, y la página japonesa empareja el original con la rotulación inglesa. La edición china también va en columnas, porque un libro que se abre por la derecha no mezcla bocadillos verticales y horizontales; la árabe se lee de derecha a izquierda por su propio sentido.

La receta completa

Sandbox

// ═══ Postext Cookbook · Nº 149 · Manga read right to left, lettered vertically ══════
// https://postext.dev/en/cookbook/manga-right-to-left
// Code: MIT · Story: written for the recipe (CC BY 4.0) · Pictures: generated with diffusion models
// Fonts: Zen Antique, Comic Neue and six more (SIL OFL 1.1) · Needs postext ≥ 1.21.0
// Two pages of a kendo manga: the Japanese original, then the same pages lettered again.
import {
  buildDocument, renderPageToCanvas, clearMeasurementCache, registerResourceImage,
  loadVerticalAlternates,
} from 'https://esm.sh/postext';
import { renderToPdf, decompressWoff2 } from 'https://esm.sh/postext-pdf';

const LANG = 'es'; // @lang: this edition's language; the Japanese original faces it
const RECIPE = 'manga-right-to-left';

// ─── 1 · Design ─────────────────────────────────────────────────────────────
// #region palette: black ink on a warm white, one screen-tone grey
const palette = {
  ink: '#151413', // panel borders, balloon outlines, the lettering
  paper: '#fdfcf9', // the page and the balloons
  tone: '#e8e6e1', // the inner-voice box, a light screen tone
  muted: '#6f6b64',
  accent: '#a8322b', // the cover red (the Folio case in recipe.json)
};
const col = (id) => ({ hex: palette[id], model: 'hex', paletteId: id });
const colorPalette = [
  ...Object.entries(palette).map(([id, hex]) => ({ id, name: id, value: { hex, model: 'hex' } })),
  { id: 'main-color', name: 'ink (defaults)', value: { hex: palette.ink, model: 'hex' } },
];
// #endregion

// The engine's lettering and sound-effect faces per language (defaultComicFont and
// defaultComicSfxFont), written out so FONTS and the PDF know them.
const EDITIONS = {
  ja: { locale: 'ja', faces: ['Zen Antique', 'Dela Gothic One'] },
  en: { locale: 'en-us', faces: ['Comic Neue', 'Bangers'] },
  es: { locale: 'es', faces: ['Comic Neue', 'Bangers'] },
  ca: { locale: 'ca', faces: ['Comic Neue', 'Bangers'] },
  pt: { locale: 'pt-BR', faces: ['Comic Neue', 'Bangers'] },
  zh: { locale: 'zh-Hans', faces: ['Noto Sans SC', 'ZCOOL KuaiLe'] },
  ar: { locale: 'ar', faces: ['Playpen Sans Arabic', 'Lalezar'] },
};

// #region answer: the art reads right to left, so every edition does
const comics = (lang) => ({
  // The pages were drawn for right-to-left reading: panel 1 sits top right. The
  // reading direction stays 'auto', which follows the art in a left-to-right
  // language too: the English page keeps the Japanese panel order.
  artDirection: 'rtl',
  mirrorArt: false, // never flop the art: Hana's grip on the sword, the kimono's fold
  gutter: { horizontal: mm(4.5), vertical: mm(2) }, // a tier gap twice the panel gap
  panel: { borderWidth: pt(0.9), borderColor: col('ink'), background: col('paper') },
  lettering: {
    fontFamily: EDITIONS[lang].faces[0], color: col('ink'),
    fontSize: pt(['ja', 'zh'].includes(lang) ? 8.5 : 7.5), // one size per edition
    // 'auto' sets Japanese in columns of 8 characters at most and drops the final 。.
    // Chinese goes in columns too: a book bound on the right never mixes the two.
    writingMode: lang === 'zh' ? 'vertical' : 'auto',
  },
  balloonStyles: balloons(),
});
// #endregion

// #region balloons: oval speech, a dashed whisper, a grey box for the inner voice
const balloons = () => [
  { id: 'speech', fill: col('paper'), stroke: col('ink'), strokeWidth: pt(0.6), roundness: 2 },
  { id: 'whisper', fill: col('paper'), stroke: col('ink'), roundness: 2 },
  { id: 'thought', fill: col('paper'), stroke: col('ink') },
  { id: 'inner', fill: col('tone'), stroke: col('tone'), strokeWidth: pt(0), italic: false },
  { id: 'caption', fill: col('paper'), stroke: col('ink'), strokeWidth: pt(0.5) },
  { id: 'sfx', color: col('ink'), haloColor: col('paper') },
];
// #endregion

const config = () => ({ // a factory: the engine caches resolved configs per object
  // Each edition's language, written out (gotcha: ja-locale-tag); the original is built
  // with 'ja' in every edition (edition('ja') below).
  locale: t({ ja: 'ja', en: 'en-us', es: 'es', ca: 'ca', zh: 'zh-Hans', ar: 'ar', pt: 'pt-BR' }),
  colorPalette,
  page: {
    sizePreset: 'custom', width: mm(128), height: mm(182), dpi: 150, // B6, a tankōbon
    binding: 'right', backgroundColor: col('paper'), // manga open from the right, in any language
    margins: { top: mm(13), bottom: mm(15), left: mm(11), right: mm(11), mirror: true },
  },
  bodyText: {
    fontFamily: 'Zen Antique', fontSize: pt(9), lineHeight: pt(15), color: col('ink'),
    boldColor: col('ink'), italicColor: col('ink'), referenceColor: col('ink'),
  },
  headings: { fontFamily: 'Zen Antique', color: col('ink'),
    levels: [{ level: 1, breakBefore: { enabled: true, parity: 'any' } }] }, // the H1 break
  header: { elements: [] }, // comic pages are all panels: no running heads, no folios
  footer: { elements: [] },
  comics: comics(LANG),
});
// Another edition changes the language, and with it the faces, the writing mode and the
// house rules of the lettering. Nothing else: not the page, not the panels.
const edition = (lang) => ({ ...config(), locale: EDITIONS[lang].locale, comics: comics(lang) });

// ─── 2 · Content ────────────────────────────────────────────────────────────
const markdown = String.raw`---
Muestra en Markdown · 40 líneas · content.es.md
title: "La noche antes"
author: "Postext Cookbook"
---

:::page{split="30 / 34 [46 | *] / * [44 | *]"}
::panel{art=dojo}
caption: La víspera del 42.º torneo de la prefectura.
dojo: …¡Yaaah!
::panel{art=swing}
sfx: ¡FUUSH!
hana{inner}: ¡Cincuenta más…!
::panel{art=doorway}
sora{whisper}: Hala, Ichinose sigue entrenando…
sora{thought}: Y ahora, ¿cómo entro?
::panel{art=closeup}
hana: …¿¡Quién anda ahí!?
::panel{art=charm}
hana: …¿Aizawa?
sora: ¡P-perdona! Es un amuleto del santuario de mi abuela.
sora: Llévatelo mañana.
:::

:::page{split="38 [44 | *] / 34 / *"}
::panel{art=coach}
sfx: ¡CLAC!
mori: Eh.
mori: El instituto cerró hace una hora.
sora{tail=bottom}: M-Mori-sensei…
::panel{art=smile}
mori: Descansar también es entrenar.
mori: …Mañana espero mucho de ti.
hana{tail=bottom}: ¡Sí, sensei!
::panel{art=kneel}
sora{thought}: No nos ha echado la bronca…
hana: Gracias, Aizawa. Lo llevaré puesto.
::panel{art=roof}
hana: …¿Sabes? Tengo un poco de miedo.
sora: Yo también. Y eso que no compito.
hana: Ja. ¿Y eso qué tiene que ver?
:::
`; // content.<lang>.md: this edition's lettering
const original = String.raw`---
Muestra en Markdown · 40 líneas · content.ja.md
title: "前の晩"
author: "Postext Cookbook"
---

:::page{split="30 / 34 [46 | *] / * [44 | *]"}
::panel{art=dojo}
caption: 第:tcy[42]回県大会の前日。
dojo: ……ヤアッ！
::panel{art=swing}
sfx: ブンッ
hana{inner}: あと:tcy[50]本……！
::panel{art=doorway}
sora{whisper}: うわ、{一ノ瀬|いちのせ}さん、まだやってる……
sora{thought}: 声、かけづらいなあ
::panel{art=closeup}
hana: ……誰!?
::panel{art=charm}
hana: ……{相沢|あいざわ}くん？
sora: ご、ごめん！　これ、うちのばあちゃんの神社のお守り
sora: 明日、持ってって
:::

:::page{split="38 [44 | *] / 34 / *"}
::panel{art=coach}
sfx: ガラッ
mori: こら。
mori: 下校時刻、とっくに過ぎてるぞ。
sora{tail=bottom}: も、森先生……
::panel{art=smile}
mori: 試合の前の晩は、休むのも稽古だ。
mori: ……明日、期待してるぞ。
hana{tail=bottom}: はい！
::panel{art=kneel}
sora{thought}: 怒られなかった……
hana: ありがとう、相沢くん。つけていくね
::panel{art=roof}
hana: ……ほんとはね、ちょっと怖いんだ
sora: 僕も。試合に出ないのに
hana: ふふっ、なにそれ
:::
`; // content.ja.md, the original, in every edition
const english = String.raw`---
Muestra en Markdown · 40 líneas · content.en.md
title: "The Night Before"
author: "Postext Cookbook"
---

:::page{split="30 / 34 [46 | *] / * [44 | *]"}
::panel{art=dojo}
caption: The day before the 42nd Prefectural Tournament.
dojo: …Yaaah!
::panel{art=swing}
sfx: FWOOSH
hana{inner}: Fifty more…!
::panel{art=doorway}
sora{whisper}: Wow, Ichinose's still at it…
sora{thought}: I can't just barge in.
::panel{art=closeup}
hana: …Who's there!?
::panel{art=charm}
hana: …Aizawa?
sora: S-sorry! It's a charm from my grandma's shrine.
sora: Take it tomorrow.
:::

:::page{split="38 [44 | *] / 34 / *"}
::panel{art=coach}
sfx: SLIDE
mori: Hey.
mori: School closed an hour ago.
sora{tail=bottom}: M-Mori-sensei…
::panel{art=smile}
mori: Rest is training too.
mori: …I'm expecting a lot tomorrow.
hana{tail=bottom}: Yes, sensei!
::panel{art=kneel}
sora{thought}: He didn't yell at us…
hana: Thanks, Aizawa. I'll wear it.
::panel{art=roof}
hana: …Honestly? I'm a little scared.
sora: Me too. And I'm not even competing.
hana: Heh. What's that got to do with it?
:::
`; // the Japanese edition faces the original with it
// The same panels and speaker ids in every file; only the words change.

// ─── 3 · Fonts ──────────────────────────────────────────────────────────────
const FONTS = {
  'Zen Antique': ['400'], 'Dela Gothic One': ['400'], 'Comic Neue': ['400', '700', '400i', '700i'],
  Bangers: ['400'], 'Noto Sans SC': ['400', '700'], 'ZCOOL KuaiLe': ['400'],
  'Playpen Sans Arabic': ['400', '700'], Lalezar: ['400'],
};

// #region art: nine panels, with each speaker's mouth, head and face marked once
const ART = { // fractions of the picture: the same in every language
  dojo: {
    alt: t({ en: 'The old wooden kendo dojo at dusk, its doors open and lit.',
      es: 'El viejo dojo de madera al anochecer, con las puertas abiertas e iluminadas.',
      ca: 'L’antic dojo de fusta al capvespre, amb les portes obertes i il·luminades.',
      pt: 'O velho dojô de madeira ao anoitecer, com as portas abertas e iluminadas.',
      zh: '黄昏时分的老木造剑道场，门敞开着，里面亮着灯。',
      ar: 'قاعة الكندو الخشبية القديمة عند الغسق، أبوابها مفتوحة ومضاءة.',
      ja: '夕暮れの古い木造の剣道場。戸が開いて、中に明かりがともっている。' }),
  safeArea: { x: 0.45, y: 0.32, width: 0.5, height: 0.51 },
  anchors: [{ id: 'dojo', x: 0.66, y: 0.63 }] },
  swing: {
    alt: t({ en: 'Hana, alone in the dojo, swings her bamboo sword overhead.',
      es: 'Hana, sola en el dojo, alza la espada de bambú sobre la cabeza.',
      ca: 'La Hana, sola al dojo, aixeca l’espasa de bambú per sobre del cap.',
      pt: 'Hana, sozinha no dojô, ergue a espada de bambu acima da cabeça.',
      zh: '花独自在道场里，把竹剑高举过头。',
      ar: 'هانا وحدها في القاعة ترفع سيف الخيزران فوق رأسها.',
      ja: 'ひとり道場で、竹刀を頭上に振りかぶる花。' }),
  safeArea: { x: 0.36, y: 0, width: 0.31, height: 0.5 },
  avoid: [{ x: 0.43, y: 0, width: 0.17, height: 0.12 }],
  anchors: [{ id: 'hana', x: 0.535, y: 0.28, head: { x: 0.53, y: 0.22 },
    face: { x: 0.49, y: 0.14, width: 0.11, height: 0.17 } }] },
  doorway: {
    alt: t({ en: 'Sora peeks round the sliding door, holding a shrine charm.',
      es: 'Sora se asoma por la puerta corredera con un amuleto en la mano.',
      ca: 'En Sora treu el cap per la porta corredissa amb un amulet a la mà.',
      pt: 'Sora espia pela porta de correr com um amuleto na mão.',
      zh: '空从拉门后探出头，手里攥着护身符。',
      ar: 'سورا يطلّ من وراء الباب المنزلق وفي يده تميمة.',
      ja: 'お守りを手に、引き戸の陰からのぞく空。' }),
  safeArea: { x: 0.37, y: 0.09, width: 0.34, height: 0.5 },
  avoid: [{ x: 0.49, y: 0.41, width: 0.08, height: 0.1 }],
  anchors: [{ id: 'sora', x: 0.545, y: 0.31, head: { x: 0.55, y: 0.22 },
    face: { x: 0.47, y: 0.16, width: 0.2, height: 0.18 } }] },
  closeup: {
    alt: t({ en: "Close-up of Hana's sweating, startled face.",
      es: 'Primer plano del rostro sudoroso y sobresaltado de Hana.',
      ca: 'Primer pla de la cara suada i sobresaltada de la Hana.',
      pt: 'Primeiro plano do rosto suado e assustado de Hana.',
      zh: '花满脸是汗、吃了一惊的特写。',
      ar: 'لقطة قريبة لوجه هانا المتعرّق المذعور.',
      ja: '汗をかき、はっとした花の顔のアップ。' }),
  safeArea: { x: 0.27, y: 0.28, width: 0.43, height: 0.51 },
  anchors: [{ id: 'hana', x: 0.475, y: 0.665, head: { x: 0.45, y: 0.35 },
    face: { x: 0.3, y: 0.3, width: 0.4, height: 0.45 } }] },
  charm: {
    alt: t({ en: 'Sora holds out the charm; Hana looks at it, sword on her shoulder.',
      es: 'Sora le tiende el amuleto; Hana lo mira con la espada al hombro.',
      ca: 'En Sora li allarga l’amulet; la Hana el mira amb l’espasa a l’espatlla.',
      pt: 'Sora estende o amuleto; Hana olha para ele com a espada no ombro.',
      zh: '空递出护身符，花扛着竹剑看着它。',
      ar: 'سورا يمدّ التميمة، وهانا تنظر إليها والسيف على كتفها.',
      ja: '空がお守りを差し出し、竹刀を肩にかついだ花がそれを見る。' }),
  safeArea: { x: 0.21, y: 0.09, width: 0.56, height: 0.53 },
  avoid: [{ x: 0.43, y: 0.47, width: 0.06, height: 0.09 }],
  anchors: [{ id: 'sora', x: 0.325, y: 0.335, head: { x: 0.29, y: 0.22 },
    face: { x: 0.26, y: 0.17, width: 0.11, height: 0.2 } },
  { id: 'hana', x: 0.675, y: 0.335, head: { x: 0.665, y: 0.22 },
    face: { x: 0.62, y: 0.17, width: 0.11, height: 0.2 } }] },
  coach: {
    alt: t({ en: 'Coach Mori in the doorway, backlit, arms crossed.',
      es: 'El entrenador Mori en la puerta, a contraluz, de brazos cruzados.',
      ca: 'L’entrenador Mori a la porta, a contrallum, de braços plegats.',
      pt: 'O treinador Mori na porta, contra a luz, de braços cruzados.',
      zh: '森老师站在门口，背着光，双臂抱在胸前。',
      ar: 'المدرّب موري عند الباب، والضوء خلفه، عاقدًا ذراعيه.',
      ja: '逆光の戸口で腕を組んで立つ森先生。' }),
  safeArea: { x: 0.33, y: 0.13, width: 0.3, height: 0.32 },
  anchors: [{ id: 'mori', x: 0.425, y: 0.215, head: { x: 0.42, y: 0.17 },
    face: { x: 0.37, y: 0.13, width: 0.1, height: 0.11 } }] },
  smile: {
    alt: t({ en: "Close-up of Mori's stern face breaking into a small smile.",
      es: 'Primer plano del rostro severo de Mori, que esboza una sonrisa.',
      ca: 'Primer pla de la cara severa d’en Mori, que esbossa un somriure.',
      pt: 'Primeiro plano do rosto severo de Mori, que esboça um sorriso.',
      zh: '森老师严肃的脸上露出一丝笑意的特写。',
      ar: 'لقطة قريبة لوجه موري الصارم وقد ارتسمت عليه ابتسامة.',
      ja: '厳しい顔がふっとゆるむ森先生のアップ。' }),
  safeArea: { x: 0.43, y: 0.21, width: 0.51, height: 0.53 },
  anchors: [{ id: 'mori', x: 0.69, y: 0.52, head: { x: 0.6, y: 0.25 },
    face: { x: 0.45, y: 0.28, width: 0.45, height: 0.32 } }] },
  kneel: {
    alt: t({ en: 'Kneeling, Hana ties the charm to her armour; Sora scratches his head.',
      es: 'De rodillas, Hana se ata el amuleto a la armadura; Sora se rasca la cabeza.',
      ca: 'De genolls, la Hana es lliga l’amulet a l’armadura; en Sora es grata el cap.',
      pt: 'De joelhos, Hana amarra o amuleto na armadura; Sora coça a cabeça.',
      zh: '花跪坐着把护身符系在护具上，空挠着头。',
      ar: 'هانا جاثية تربط التميمة بدرعها، وسورا يحكّ رأسه.',
      ja: '正座してお守りを防具に結ぶ花と、頭をかく空。' }),
  safeArea: { x: 0.21, y: 0.08, width: 0.61, height: 0.48 },
  avoid: [{ x: 0.27, y: 0.43, width: 0.06, height: 0.12 }],
  anchors: [{ id: 'hana', x: 0.305, y: 0.245, head: { x: 0.3, y: 0.17 },
    face: { x: 0.25, y: 0.1, width: 0.11, height: 0.17 } },
  { id: 'sora', x: 0.7, y: 0.25, head: { x: 0.71, y: 0.15 },
    face: { x: 0.64, y: 0.1, width: 0.13, height: 0.18 } }] },
  roof: {
    alt: t({ en: 'Seen from behind, Hana and Sora sit on the school roof at sunset.',
      es: 'De espaldas, Hana y Sora sentados en la azotea del instituto al atardecer.',
      ca: 'D’esquena, la Hana i en Sora asseguts al terrat de l’institut a la posta.',
      pt: 'De costas, Hana e Sora sentados no terraço da escola ao pôr do sol.',
      zh: '夕阳下，花和空坐在学校楼顶的背影。',
      ar: 'هانا وسورا جالسان على سطح المدرسة عند الغروب، من الخلف.',
      ja: '夕焼けの屋上に並んで座る花と空の後ろ姿。' }),
  safeArea: { x: 0.24, y: 0.41, width: 0.47, height: 0.31 },
  anchors: [{ id: 'hana', x: 0.36, y: 0.52, head: { x: 0.36, y: 0.48 },
    face: { x: 0.31, y: 0.43, width: 0.11, height: 0.14 } },
  { id: 'sora', x: 0.63, y: 0.52, head: { x: 0.625, y: 0.47 },
    face: { x: 0.58, y: 0.41, width: 0.1, height: 0.15 } }] },
};
const panels = () => Promise.all([
  comicPanel('dojo', asset('kendo-dojo.jpg'), ART.dojo),
  comicPanel('swing', asset('kendo-swing.jpg'), ART.swing),
  comicPanel('doorway', asset('kendo-doorway.jpg'), ART.doorway),
  comicPanel('closeup', asset('kendo-closeup.jpg'), ART.closeup),
  comicPanel('charm', asset('kendo-charm.jpg'), ART.charm),
  comicPanel('coach', asset('kendo-coach.jpg'), ART.coach),
  comicPanel('smile', asset('kendo-smile.jpg'), ART.smile),
  comicPanel('kneel', asset('kendo-kneel.jpg'), ART.kneel),
  comicPanel('roof', asset('kendo-roof.jpg'), ART.roof),
]);
// #endregion

// #region fonts: each edition loads its two faces with the words they set
const SFX = /^sfx[^:：\n]*[:：](.*)$/gm; // sound-effect lines: the second face sets them
async function loadEdition(lang) {
  const text = TEXT[lang];
  const [face, sfx] = EDITIONS[lang].faces;
  const faces = { [face]: FONTS[face], [sfx]: FONTS[sfx] };
  if (['ja', 'zh'].includes(lang)) { // CJK: only the files that hold these characters
    const effects = [...text.matchAll(SFX)].map((m) => m[1]).join('');
    await loadCjkFonts({ [face]: FONTS[face] }, text.replace(SFX, ''), { vertical: true });
    await loadCjkFonts({ [sfx]: FONTS[sfx] }, effects, { vertical: true });
  }
  if (lang === 'ar') await loadArabicFonts(faces, text);
  await loadComicFonts(faces, text); // the bold and italic the faces do not ship
}
// #endregion

// ─── 4 · Build & show ───────────────────────────────────────────────────────
// #region editions: the original on the right-hand page, this edition's lettering facing it
const FACING = LANG === 'ja' ? 'en' : LANG; // Japanese readers see the English edition
const TEXT = { ja: original, [FACING]: LANG === 'ja' ? english : markdown };
await loadFonts(FONTS, Object.values(TEXT).join('\n'));
const resources = await panels();
const build = async (lang) => { // the same pictures and page; this language's lettering
  await loadEdition(lang);
  return buildWithFonts(() => buildDocument({ markdown: TEXT[lang], resources,
    continuation: { pageIndexOffset: 1 } }, edition(lang)), TEXT[lang]);
};
const docs = [await build('ja'), await build(FACING)];
// #endregion
const TITLE = t({
  en: 'A manga read right to left', es: 'Un manga que se lee de derecha a izquierda',
  ca: 'Un manga que es llegeix de dreta a esquerra', zh: '从右往左读的漫画',
  pt: 'Um mangá lido da direita para a esquerda',
  ar: 'مانغا تُقرأ من اليمين إلى اليسار', ja: '右から左へ読む漫画' });
showBook(docs, { title: TITLE });
offerPdf(() => renderToPdf(docs, { fontProvider: comicPdfProvider, resourceBytes: imageBytes }),
  `${RECIPE}.pdf`);

Kit · core, fonts, viewer, pdf, images, cjk, arabic, comics: igual en todas las recetas · 722 líneas
// ─── Kit ── helpers shared by every Cookbook recipe · postext.dev/cookbook ─────

// ─── Kit · core v1 ── the same in every recipe · postext.dev/cookbook
function mm(value) { return { value, unit: 'mm' }; }
function pt(value) { return { value, unit: 'pt' }; }
function em(value) { return { value, unit: 'em' }; }
/** The sample language's string: t({ en: 'Figure', es: 'Figura' }). */
function t(strings) { return strings[LANG] ?? Object.values(strings)[0]; }
/** A file in this recipe's assets folder, served from the Postext repo by jsDelivr. */
function asset(file) { return `https://cdn.jsdelivr.net/gh/drnachio/postext@main/cookbook/${RECIPE}/assets/${file}`; }

// ─── Kit · fonts v2 ── the same in every recipe · postext.dev/cookbook
// Postext measures with the loaded faces and caches the widths: load every face
// before the first build, from Fontsource, the files the PDF embeds too.

/** faces = { 'Family Name': ['400', '400i', '700'] }. `text` is the sample:
 *  č ł † α χ also load latin-ext and greek files (kitSubsetsFor). With
 *  `optional`, a face Fontsource does not ship is skipped instead of failing.
 *  Resolves to the number of faces added. */
async function loadFonts(faces, text = '', { optional = false } = {}) {
  kitStatus('Loading fonts…');
  const ranges = {
    latin: 'U+0000-00FF,U+0131,U+0152-0153,U+02BB-02BC,U+02C6,U+02DA,U+02DC,U+0304,U+0308,U+0329,'
      + 'U+2000-206F,U+20AC,U+2122,U+2191,U+2193,U+2212,U+2215,U+FEFF,U+FFFD',
    'latin-ext': 'U+0100-02BA,U+02BD-02C5,U+02C7-02CC,U+02CE-02D7,U+02DD-02FF,U+0304,U+0308,U+0329,'
      + 'U+1D00-1DBF,U+1E00-1E9F,U+1EF2-1EFF,U+2020,U+20A0-20AB,U+20AD-20C0,U+2113,U+2C60-2C7F,U+A720-A7FF',
    greek: 'U+0370-03FF',
  };
  const jobs = [];
  let added = 0;
  for (const [family, specs] of Object.entries(faces)) {
    const id = fontsourceId(family);
    const todo = [...new Set(specs)].map((spec) => [parseInt(spec, 10), spec.endsWith('i') ? 'italic' : 'normal'])
      .filter(([weight, style]) => !hasFace(family, weight, style)); // before any await
    const meta = optional || /[^\0-ÿ]/u.test(text) ? await fontsourceMeta(family) : null;
    const subsets = ['latin', ...kitSubsetsFor(text, meta)];
    for (const [weight, style] of todo) {
      if (optional && !(meta?.weights.includes(weight) && meta.styles.includes(style))) continue;
      for (const subset of subsets) {
        const url = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-${subset}-${weight}-${style}.woff2`;
        const face = new FontFace(family, `url(${url}) format('woff2')`,
          { weight: String(weight), style, unicodeRange: ranges[subset] });
        jobs.push(face.load().then((ready) => { document.fonts.add(ready); added++; }, () => {
          if (subset === 'latin' && !optional) throw new Error(`Fontsource has no ${family} ${weight} ${style}`);
        }));
      }
    }
  }
  await Promise.all(jobs).catch((error) => { kitFail(error); throw error; });
  return added;
}

/** Runs `build` and loads any face the pages use that FONTS missed (a regular
 *  one with a warning), then clears the measurement cache and builds again. */
async function buildWithFonts(build, text = '') {
  const tried = new Set();
  for (let round = 0; round < 3; round++) {
    kitStatus('Laying out…');
    await new Promise(requestAnimationFrame);          // let the status paint first
    const result = await Promise.resolve().then(build).catch((error) => { kitFail(error); throw error; });
    const wanted = { base: {}, variants: {} };
    for (const { font, base } of [result].flat().flatMap(fontStringsOf)) {
      const { family, weight, style } = parseFont(font);
      const key = `${family}|${weight}|${style}`;
      if (tried.has(key) || hasFace(family, weight, style)) continue;
      tried.add(key);
      (wanted[base ? 'base' : 'variants'][family] ??= []).push(`${weight}${style === 'italic' ? 'i' : ''}`);
    }
    if (Object.keys(wanted.base).length) {
      console.warn(`[cookbook] FONTS does not list ${JSON.stringify(wanted.base)}: loading them.`);
    }
    const added = await loadFonts(wanted.base, text) + await loadFonts(wanted.variants, text, { optional: true });
    if (added === 0) return result;
    clearMeasurementCache();
  }
  throw new Error('The fonts did not settle after three builds.');
}

/** Every font string of the layout; `base` marks a block's own face. */
function fontStringsOf(doc) {
  const found = new Map();
  const walk = (node) => {
    if (!node || typeof node !== 'object') return;
    if (Array.isArray(node)) { node.forEach(walk); return; }
    for (const [key, value] of Object.entries(node)) {
      if (typeof value === 'string' && /fontString$/i.test(key)) {
        found.set(value, found.get(value) || key === 'fontString');
      } else if (value && typeof value === 'object') walk(value);
    }
  };
  walk(doc.pages);
  walk(doc.blocks);
  return [...found].map(([font, base]) => ({ font, base }));
}

/** '700 37.5px Open Sans' / 'italic 400 13px "Source Serif 4"' → { family, weight, style }.
 *  A string with no weight ('95.8px Young Serif', from a design text) is 400. */
function parseFont(font) {
  const m = /^(?:(italic|oblique)\s+)?(?:small-caps\s+)?(?:(\d+|bold|normal)\s+)?[\d.]+px\s+(.+)$/.exec(font.trim());
  if (!m) throw new Error(`Unexpected font string: ${font}`);
  const weight = m[2] === 'bold' ? 700 : !m[2] || m[2] === 'normal' ? 400 : Number(m[2]);
  return { family: m[3].replace(/^["']|["']$/g, ''), weight, style: m[1] ? 'italic' : 'normal' };
}

/** A loaded FontFace covers this family, weight and style (fonts.check() would
 *  also say yes for families nobody declared). */
function hasFace(family, weight, style) {
  for (const face of document.fonts) {
    if (face.status !== 'loaded' || face.style !== style) continue;
    if (face.family.replace(/^["']|["']$/g, '') !== family) continue;
    const [low, high = low] = face.weight.split(' ').map(Number);
    if (weight >= low && weight <= high) return true;
  }
  return false;
}

/** The files beyond latin `text` needs that `meta`'s family ships. */
function kitSubsetsFor(text, meta) {
  return [[/[Ā-˿ᴀ-ᶿḀ-ỿ†ℓⱠ-Ɀ꜠-ꟿ]/u, 'latin-ext'], [/[Ͱ-Ͽ]/u, 'greek']]
    .filter(([re, x]) => re.test(text) && meta?.subsets?.includes(x)).map(([, x]) => x);
}

/** Fontsource's id for a family: 'Source Serif 4' → 'source-serif-4'. */
function fontsourceId(family) { return family.toLowerCase().replace(/\s+/g, '-'); }

/** The family's Fontsource metadata (weights, styles, subsets), or null. */
function fontsourceMeta(family) {
  fontsourceMeta.cache ??= new Map();
  const id = fontsourceId(family);
  if (!fontsourceMeta.cache.has(id)) {
    fontsourceMeta.cache.set(id, fetch(`https://api.fontsource.org/v1/fonts/${id}`)
      .then((res) => (res.ok ? res.json() : null), () => null));
  }
  return fontsourceMeta.cache.get(id);
}

// ─── Kit · viewer v1 ── the same in every recipe · postext.dev/cookbook
/** The pages as spreads on a dark desk, page 1 alone, then verso | recto,
 *  each painted when it scrolls near. */
function showPages(docs, { title, width = 460 } = {}) {
  const root = viewer(title);
  const pages = [docs].flat().flatMap((doc) =>
    doc.pages.map((page) => ({ doc, page, n: (doc.pageIndexOffset ?? 0) + page.index })));
  const spreads = [];
  let verso = null;
  for (const p of pages) {
    if (p.n % 2 === 1) { if (verso) spreads.push([verso, null]); verso = p; }
    else { spreads.push([verso, p]); verso = null; }
  }
  if (verso) spreads.push([verso, null]);
  const density = Math.min(window.devicePixelRatio || 1, 2);
  showPages.painter?.disconnect();
  const painter = new IntersectionObserver((entries) => {
    for (const { isIntersecting, target } of entries) {
      if (!isIntersecting) continue;
      painter.unobserve(target);
      const { doc, page } = target.postext;
      renderPageToCanvas(page, doc, target, { scale: (width * density) / page.width });
    }
  }, { rootMargin: '800px' });
  showPages.painter = painter;
  root.replaceChildren(...spreads.map((pair) => {
    const spread = document.createElement('div');
    spread.className = 'pt-spread';
    for (const p of pair) {
      const figure = document.createElement('figure');
      if (p) {
        const label = p.page.pageLabel || String(p.n + 1);
        const canvas = document.createElement('canvas');
        canvas.postext = p;
        canvas.style.aspectRatio = `${p.page.width} / ${p.page.height}`;
        canvas.setAttribute('role', 'img');
        canvas.setAttribute('aria-label', `Page ${label}`);
        const folio = document.createElement('figcaption');
        folio.textContent = label;
        figure.append(canvas, folio);
        painter.observe(canvas);
      } else figure.className = 'pt-blank';
      spread.append(figure);
    }
    return spread;
  }));
  kitStatus(`${pages.length} ${pages.length === 1 ? 'page' : 'pages'}`);
  document.documentElement.dataset.postext = 'ready';
  return pages.length;
}

/** The desk, the bar and the error reporting, created once. */
function viewer(title) {
  if (!document.getElementById('pt-kit')) {
    document.head.insertAdjacentHTML('beforeend', `<style id="pt-kit">
      :root { color-scheme: dark; }
      body { margin: 0; background: #0e1014; color: #b9bcc4; font: 13px/1.45 system-ui, sans-serif; }
      #pt-bar { position: sticky; top: 0; z-index: 1; display: flex; flex-wrap: wrap; align-items: center;
        gap: 6px 16px; padding: 10px 16px; background: rgb(14 16 20 / .92); backdrop-filter: blur(6px);
        border-bottom: 1px solid #23262d; }
      #pt-bar strong { color: #f4f1ea; font-weight: 600; }
      #pt-actions { display: flex; gap: 12px; margin-left: auto; }
      #pt-actions a, #pt-actions button { color: #d8a21a; font: inherit; background: none; border: 0; padding: 0; cursor: pointer; }
      #pages { display: grid; justify-items: center; gap: 48px; padding: 32px 16px 72px; }
      .pt-spread { display: flex; }
      .pt-spread figure { margin: 0; width: min(460px, 44vw); }
      .pt-spread canvas { display: block; width: 100%; background: #fff;
        box-shadow: 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figure:first-child canvas { box-shadow: inset -14px 0 14px -14px rgb(0 0 0 / .18), 0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
      .pt-spread figcaption { margin-top: 10px; text-align: center; font: 600 10px/1 system-ui, sans-serif;
        letter-spacing: .18em; text-transform: uppercase; color: #6c7079; }
      .pt-blank { visibility: hidden; }
      @media (max-width: 760px) {
        .pt-spread { flex-direction: column; gap: 32px; }
        .pt-spread figure { width: min(460px, 92vw); }
        .pt-blank { display: none; }
      }
    </style>`);
    document.body.insertAdjacentHTML('afterbegin',
      '<header id="pt-bar"><strong id="pt-title"></strong><span id="pt-status" role="status"></span><span id="pt-actions"></span></header>');
    document.getElementById('pt-title').textContent = document.title || 'Postext';
    addEventListener('error', (event) => kitFail(event.error ?? event.message));
    addEventListener('unhandledrejection', (event) => kitFail(event.reason));
  }
  if (title) document.getElementById('pt-title').textContent = title;
  return document.getElementById('pages')
    ?? document.body.appendChild(Object.assign(document.createElement('main'), { id: 'pages' }));
}

function kitStatus(text) {
  viewer();
  document.getElementById('pt-status').textContent = text;
}

function kitFail(error) {
  document.documentElement.dataset.postext = 'error';
  kitStatus(`Error: ${error?.message ?? error}`);
}

// ─── Kit · pdf v2 ── the same in every recipe that exports a PDF
/** The Fontsource files the screen used, as TrueType: the nearest weight the
 *  family ships, upright if it has no italic; latin, then what the face's
 *  letters need (kitSubsetsFor). */
async function fontsourceProvider(family, weight, style, request) {
  const id = fontsourceId(family);
  const meta = await fontsourceMeta(family);
  const weights = meta?.weights?.length ? meta.weights : [400, 700];
  const w = weights.reduce((a, b) => (Math.abs(b - weight) < Math.abs(a - weight) ? b : a));
  const s = style === 'italic' && meta && !meta.styles.includes('italic') ? 'normal' : style;
  const text = String.fromCodePoint(...(request?.codePoints ?? []));
  const more = kitSubsetsFor(text, meta);
  const files = await Promise.all(['latin', ...more].map(async (subset) => {
    const res = await fetch(`https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-${subset}-${w}-${s}.woff2`);
    if (!res.ok) throw new Error(`Fontsource has no ${family} ${w} ${s} ${subset}`);
    return decompressWoff2(new Uint8Array(await res.arrayBuffer()));
  }));
  return files.length === 1 ? files[0] : files;
}

/** A "Build the PDF" button; then "Open the PDF" (a new tab: CodePen's frame
 *  shows no PDFs) and a download link. */
function offerPdf(makePdf, filename) {
  viewer();
  const button = Object.assign(document.createElement('button'), { type: 'button', textContent: 'Build the PDF' });
  button.dataset.postextPdf = filename;
  button.addEventListener('click', async () => {
    button.disabled = true;
    button.textContent = 'Building the PDF…';
    try {
      const bytes = await makePdf();
      const url = URL.createObjectURL(new Blob([bytes], { type: 'application/pdf' }));
      const size = `${Math.max(1, Math.round(bytes.length / 1024))} KB`;
      button.replaceWith(
        Object.assign(document.createElement('a'), { href: url, target: '_blank', rel: 'noopener', textContent: 'Open the PDF ↗' }),
        Object.assign(document.createElement('a'), { href: url, download: filename, textContent: `Download ${filename} · ${size}` }));
    } catch (error) {
      button.disabled = false;
      button.textContent = 'Build the PDF';
      kitFail(error);
    }
  });
  document.getElementById('pt-actions').append(button);
}

// ─── Kit · images v1 ── recipes with pictures · postext.dev/cookbook
/** Registers a photo or PNG for the canvas and keeps its bytes for the PDF.
 *  fetch → ImageBitmap never taints the canvas (a plain cross-origin <img> would). */
async function loadImage(fileId, url) {
  const res = await fetch(url);
  if (!res.ok) throw new Error(`Image not found (${res.status}): ${url}`);
  const bytes = new Uint8Array(await res.arrayBuffer());
  registerResourceImage(fileId, await createImageBitmap(new Blob([bytes])));
  (loadImage.bytes ??= new Map()).set(fileId, bytes);
}

/** Registers SVG markup (drawn in code, or fetched) as a vector image. */
async function loadSvg(fileId, svg) {
  const img = new Image();
  await img.decode();
  registerResourceImage(fileId, img);
  (loadImage.bytes ??= new Map()).set(fileId, new TextEncoder().encode(svg));
}

/** renderToPdf({ resourceBytes: imageBytes }) */
function imageBytes(fileId) { return loadImage.bytes?.get(fileId); }

/** renderToHtml({ resourceImageUrl: imageUrl }) */
function imageUrl(fileId) {
  const bytes = imageBytes(fileId);
  if (!bytes) return undefined;
  imageUrl.urls ??= new Map();
  if (!imageUrl.urls.has(fileId)) {
    const type = /\.svg$/i.test(fileId) ? 'image/svg+xml' : /\.png$/i.test(fileId) ? 'image/png' : 'image/jpeg';
    imageUrl.urls.set(fileId, URL.createObjectURL(new Blob([bytes], { type })));
  }
  return imageUrl.urls.get(fileId);
}

// ─── Kit · cjk v1 ── Chinese, Japanese and Korean books · postext.dev/cookbook
// Fontsource ships a CJK family as about a hundred files per weight, each
// declared in its stylesheet with the unicode-range it covers. The screen
// loads the files the sample touches; the PDF gets the same files for the
// characters its pages set in each face, and embeds each as a subset.
// A book bound on the right (vertical text) is shown with its spreads
// mirrored: page 1 alone on the left of the spine, then [3 | 2].

/** The files of a Fontsource face, read from its stylesheet: { url, range,
 *  ranges }, the last declared first (the order the browser tries them in). */
function cjkSlices(family, weight, style) {
  cjkSlices.cache ??= new Map();
  const id = fontsourceId(family);
  const css = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/${weight}${style === 'italic' ? '-italic' : ''}.css`;
  if (!cjkSlices.cache.has(css)) {
    cjkSlices.cache.set(css, fetch(css)
      .then((res) => {
        if (!res.ok) throw new Error(`Fontsource has no ${family} ${weight} ${style} (${res.status})`);
        return res.text();
      })
      .then((text) => [...text.matchAll(/@font-face\s*{([^}]*)}/g)].map(([, rule]) => {
        const range = /unicode-range:\s*([^;]+);/.exec(rule)?.[1].trim() ?? 'U+0-10FFFF';
        const ranges = range.split(',').map((part) => {
          const [lo, hi = lo] = part.trim().slice(2).split('-');
          return [parseInt(lo, 16), parseInt(hi, 16)];
        });
        return { url: new URL(/url\(([^)]+?\.woff2)\)/.exec(rule)[1], css).href, range, ranges };
      }).reverse()));
  }
  return cjkSlices.cache.get(css);
}

/** The file of `slices` that holds code point `cp`, if any. */
function cjkSliceFor(slices, cp) {
  return slices.find((slice) => slice.ranges.some(([lo, hi]) => cp >= lo && cp <= hi));
}

/** Whether Fontsource serves `family` as a Chinese, Japanese or Korean
 *  family (its subsets name the script). Fails when the API does not
 *  answer: a CJK face taken for a Latin one would paint in a system face. */
async function isCjkFamily(family) {
  const meta = await fontsourceMeta(family);
  if (!meta) throw new Error(`api.fontsource.org did not describe ${family}: reload to try again`);
  return !!meta.subsets?.some((subset) => /^(chinese|japanese|korean)/.test(subset));
}

/** faces = { 'Noto Serif TC': ['400', '700'] }, as for loadFonts: the
 *  whole FONTS object may be passed, its other families are left to
 *  loadFonts. Adds one FontFace per file of each CJK face with its
 *  unicodeRange, then loads the files `text` touches. `text` is what the
 *  faces set: the sample for the text face; a book in several voices calls
 *  it once per voice (loadCjkFonts({ 'LXGW WenKai TC': ['400'] }, quotes)),
 *  so the heading and quotation faces fetch and check only their own
 *  characters. Fails when a character of `text` is in no file of a face.
 *  List every weight the pages use: a weight left to buildWithFonts gets
 *  the latin file only. With { vertical: true } it also loads each
 *  family's vertical forms (brackets, quotes, pause marks) for the canvas,
 *  which needs loadVerticalAlternates imported from postext. Resolves to
 *  the number of files loaded. */
async function loadCjkFonts(faces, text, { vertical = false } = {}) {
  kitStatus('Loading fonts…');
  let loaded = 0;
  try {
    if (vertical && typeof loadVerticalAlternates !== 'function') {
      throw new Error('loadCjkFonts(…, { vertical: true }) needs loadVerticalAlternates imported from postext');
    }
    for (const [family, specs] of Object.entries(faces)) {
      if (!(await isCjkFamily(family))) continue;
      const twin = [];
      for (const spec of new Set(specs)) {
        const weight = parseInt(spec, 10);
        const style = spec.endsWith('i') ? 'italic' : 'normal';
        const slices = await cjkSlices(family, weight, style);
        const missing = [...new Set(text)].filter((ch) => /\S/.test(ch) && !cjkSliceFor(slices, ch.codePointAt(0)));
        if (missing.length) {
          throw new Error(`${family} ${spec} has no file for ${missing.slice(0, 12).join(' ')}: `
            + `give each face the text it sets (loadCjkFonts({ '${family}': ['${spec}'] }, text))`);
        }
        for (const slice of slices) {
          document.fonts.add(new FontFace(family, `url(${slice.url}) format('woff2')`,
            { weight: String(weight), style, unicodeRange: slice.range }));
          twin.push({ source: slice.url, weight: String(weight), style, unicodeRange: slice.range });
        }
        const font = `${style === 'italic' ? 'italic ' : ''}${weight} 16px "${family}"`;
        loaded += (await document.fonts.load(font, text)).length;
        if (!document.fonts.check(font, text)) throw new Error(`${family} ${spec} did not load for the sample`);
      }
      // The same files under a twin name with the `vert` feature on: the
      // canvas paints the punctuation of vertical lines with it.
      if (vertical && twin.length) await loadVerticalAlternates(family, twin);
    }
  } catch (error) {
    kitFail(error);
    throw error;
  }
  return loaded;
}

/** The PDF font provider for recipes with CJK faces: a family whose
 *  Fontsource subsets are Chinese, Japanese or Korean gets the files that
 *  hold the characters its pages set (`request.codePoints`); any other
 *  family gets the latin file fontsourceProvider fetches (the "pdf" block)
 *  and, when the face sets letters only latin-ext has, that file too. */
async function cjkPdfProvider(family, weight, style, request) {
  if (!(await isCjkFamily(family))) return cjkLatinPdfFiles(family, weight, style, request);
  const meta = await fontsourceMeta(family);
  const weights = meta.weights?.length ? meta.weights : [400, 700];
  const w = weights.reduce((a, b) => (Math.abs(b - weight) < Math.abs(a - weight) ? b : a));
  const s = style === 'italic' && !meta.styles.includes('italic') ? 'normal' : style;
  const slices = await cjkSlices(family, w, s);
  const picked = new Set();
  for (const cp of request?.codePoints ?? []) {
    const slice = cjkSliceFor(slices, cp);
    if (slice) picked.add(slice);
  }
  if (!picked.size) picked.add(slices[0]);
  return Promise.all(slices.filter((slice) => picked.has(slice)).map(async (slice) => {
    const res = await fetch(slice.url);
    if (!res.ok) throw new Error(`Fontsource file ${slice.url} (${res.status})`);
    return decompressWoff2(new Uint8Array(await res.arrayBuffer()));
  }));
}

/** A Latin family set next to the CJK faces: its latin file, then its
 *  latin-ext file when the face sets letters only latin-ext has (ō ū in
 *  Hepburn rōmaji, ǎ in pinyin), the file loadFonts adds on screen for
 *  them. Latin comes first: postext-pdf draws a character from the first
 *  file that has it, as the browser takes a character both files hold from
 *  latin. A face Fontsource ships without latin-ext, or whose file does
 *  not come, gets latin alone, and the PDF names the letters it lacks. */
async function cjkLatinPdfFiles(family, weight, style, request) {
  const meta = await fontsourceMeta(family);
  const beyond = [...(request?.codePoints ?? [])].some(cjkLatinExtOnly);
  if (!beyond || !meta?.subsets?.includes('latin-ext')) return fontsourceProvider(family, weight, style);
  const weights = meta.weights?.length ? meta.weights : [400, 700];
  const w = weights.reduce((a, b) => (Math.abs(b - weight) < Math.abs(a - weight) ? b : a));
  const s = style === 'italic' && !meta.styles.includes('italic') ? 'normal' : style;
  const id = fontsourceId(family);
  const url = `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-latin-ext-${w}-${s}.woff2`;
  const [latin, ext] = await Promise.all([fontsourceProvider(family, weight, style), fetch(url)
    .then(async (res) => (res.ok ? decompressWoff2(new Uint8Array(await res.arrayBuffer())) : null), () => null)]);
  return ext ? [latin, ext] : latin;
}

/** Whether code point `cp` is in Fontsource's latin-ext file and not in
 *  its latin file: Latin Extended-A and -B, IPA, the spacing modifiers and
 *  Latin Extended Additional (loadFonts's test for latin-ext), less the
 *  few latin holds too (ı Œ œ ʻ ʼ ˆ ˚ ˜). */
function cjkLatinExtOnly(cp) {
  if (!((cp >= 0x100 && cp <= 0x2ff) || (cp >= 0x1e00 && cp <= 0x1eff))) return false;
  return ![0x131, 0x152, 0x153, 0x2bb, 0x2bc, 0x2c6, 0x2da, 0x2dc].includes(cp);
}

/** showPages for a book bound on either edge. A right-bound book (the
 *  document says so: doc.binding is 'right' for page.binding 'right' and
 *  for vertical text) lies on the desk as it opens: page 1 alone on the
 *  left of the spine, then [3 | 2], the spine shade on each page's inner
 *  edge. `binding` ('left' | 'right') overrides the document's. */
function showBook(docs, { binding, ...options } = {}) {
  const count = showPages(docs, options);
  const right = (binding ?? [docs].flat()[0]?.binding) === 'right';
  if (!document.getElementById('pt-kit-cjk')) {
    // The pages keep direction ltr: a canvas draws text in the direction its
    // element inherits, and under rtl each run would end where the engine
    // starts it, its brackets mirrored.
    document.head.insertAdjacentHTML('beforeend', `<style id="pt-kit-cjk">
      .pt-spread[dir="rtl"] canvas { direction: ltr; }
      .pt-spread[dir="rtl"] figure:first-child canvas { box-shadow: inset 14px 0 14px -14px rgb(0 0 0 / .18),
        0 1px 2px rgb(0 0 0 / .5), 0 22px 44px -16px rgb(0 0 0 / .8); }
    </style>`);
  }
  // Each pair stays [verso, recto] in the page; right to left, the verso
  // sits on the right. Phones stack the pages in reading order either way.
  for (const spread of document.querySelectorAll('#pages > .pt-spread')) spread.dir = right ? 'rtl' : 'ltr';
  document.getElementById('pages').dataset.binding = right ? 'right' : 'left';
  return count;
}

// ─── Kit · arabic v1 ── Arabic-script faces · postext.dev/cookbook
// Fontsource ships an Arabic family as one file per subset and weight: the
// `arabic` file holds the letters, the harakat, the Arabic-Indic digits, the
// Arabic punctuation and the presentation forms; `latin` and `latin-ext`
// hold the rest. loadFonts loads the latin files; this block adds the arabic
// file of every Arabic family, for the canvas and for the PDF, which shapes
// the letters with HarfBuzz from the same bytes.

/** The code points of Fontsource's `arabic` subset, as its stylesheets
 *  declare them (the same unicode-range the browser picks the file by). A
 *  function, not a const: the kit is inlined after the recipe's top-level
 *  awaits, and a const read before its line throws, where a function
 *  declaration is hoisted. */
function arabicRange() {
  return 'U+0600-06FF,U+0750-077F,U+0870-088E,U+0890-0891,U+0897-08E1,U+08E3-08FF,'
    + 'U+200C-200E,U+2010-2011,U+204F,U+2E41,U+FB50-FDFF,U+FE70-FE74,U+FE76-FEFC,U+102E0-102FB,'
    + 'U+10E60-10E7E,U+10EC2-10EC4,U+10EFC-10EFF,U+1EE00-1EEFF';
}

/** Whether code point `cp` is in the arabic file. */
function inArabicRange(cp) {
  inArabicRange.ranges ??= arabicRange().split(',').map((part) => {
    const [lo, hi = lo] = part.slice(2).split('-');
    return [parseInt(lo, 16), parseInt(hi, 16)];
  });
  return inArabicRange.ranges.some(([lo, hi]) => cp >= lo && cp <= hi);
}

/** Whether Fontsource serves `family` with an `arabic` subset. Fails when
 *  the API does not answer: an Arabic face taken for a Latin one would set
 *  its letters in a system face. */
async function isArabicFamily(family) {
  const meta = await fontsourceMeta(family);
  if (!meta) throw new Error(`api.fontsource.org did not describe ${family}: reload to try again`);
  return !!meta.subsets?.includes('arabic');
}

/** The arabic file of a face. */
function arabicFileUrl(family, weight, style) {
  const id = fontsourceId(family);
  return `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-arabic-${weight}-${style}.woff2`;
}

/** faces = { Amiri: ['400', '700'] }, as for loadFonts, after it: the whole
 *  FONTS object may be passed, its families without an arabic subset are
 *  left alone. Adds the arabic file of every listed weight of each Arabic
 *  family (the latin files come from loadFonts) and loads it. `text` is
 *  the sample: fails when it holds an Arabic-script character the arabic
 *  file does not cover. List every weight the pages set in Arabic: a weight
 *  left to buildWithFonts gets the latin file only, and its Arabic letters
 *  fall back to a system face. Resolves to the number of files loaded. */
async function loadArabicFonts(faces, text = '') {
  kitStatus('Loading fonts…');
  let loaded = 0;
  try {
    const outside = [...new Set(text)].filter((ch) => /\p{Script=Arabic}/u.test(ch) && !inArabicRange(ch.codePointAt(0)));
    if (outside.length) throw new Error(`Fontsource's arabic files have no ${outside.slice(0, 12).join(' ')}`);
    for (const [family, specs] of Object.entries(faces)) {
      if (!(await isArabicFamily(family))) continue;
      for (const spec of new Set(specs)) {
        const weight = parseInt(spec, 10);
        const style = spec.endsWith('i') ? 'italic' : 'normal';
        const face = new FontFace(family, `url(${arabicFileUrl(family, weight, style)}) format('woff2')`,
          { weight: String(weight), style, unicodeRange: arabicRange() });
        document.fonts.add(await face.load().catch(() => {
          throw new Error(`Fontsource has no arabic file for ${family} ${weight} ${style}`);
        }));
        loaded++;
      }
    }
  } catch (error) {
    kitFail(error);
    throw error;
  }
  return loaded;
}

/** The PDF font provider for recipes with Arabic faces: a family with an
 *  arabic subset gets its arabic file when its pages set Arabic letters
 *  (`request.codePoints`), then its latin file, and its latin-ext file for
 *  the letters beyond latin (transliteration: ā ḥ ʿ). The arabic file comes
 *  first: it also holds the space and the brackets, so a line of Arabic is
 *  shaped as one run and not cut at every space. Any other family goes to
 *  fontsourceProvider (the "pdf" block). */
async function arabicPdfProvider(family, weight, style, request) {
  if (!(await isArabicFamily(family))) return fontsourceProvider(family, weight, style, request);
  const meta = await fontsourceMeta(family);
  const weights = meta.weights?.length ? meta.weights : [400, 700];
  const w = weights.reduce((a, b) => (Math.abs(b - weight) < Math.abs(a - weight) ? b : a));
  const s = style === 'italic' && !meta.styles.includes('italic') ? 'normal' : style;
  const wanted = [...(request?.codePoints ?? [])];
  const id = fontsourceId(family);
  const urls = [];
  if (!wanted.length || wanted.some(inArabicRange)) urls.push(arabicFileUrl(family, w, s));
  urls.push(`https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-latin-${w}-${s}.woff2`);
  if (meta.subsets.includes('latin-ext') && wanted.some((cp) => /[Ā-˿Ḁ-ỿ]/u.test(String.fromCodePoint(cp)))) {
    urls.push(`https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-latin-ext-${w}-${s}.woff2`);
  }
  return Promise.all(urls.map(async (url) => {
    const res = await fetch(url);
    if (!res.ok) throw new Error(`Fontsource file ${url} (${res.status})`);
    return decompressWoff2(new Uint8Array(await res.arrayBuffer()));
  }));
}

// ─── Kit · comics v1 ── comic pages · postext.dev/cookbook
// The engine letters a comic in a face per language (defaultComicFont:
// Comic Neue, Zen Antique for Japanese, Noto Sans SC, LXGW WenKai TC,
// Playpen Sans Arabic; defaultComicSfxFont: Bangers, Dela Gothic One,
// ZCOOL KuaiLe, Lalezar) and asks for the bold of a shout or a sound effect
// and the italic of an inner voice. Most of these faces ship one weight and
// no italic: this block declares the file Fontsource does ship for those
// variants, so the canvas measures and paints the letters the PDF embeds
// (the providers snap to the shipped file) and not a bold or a slant the
// browser makes up. It also turns the art manifest into panel resources.

/** faces = { 'Comic Neue': ['400', '700'], Bangers: ['400'] }, as for
 *  loadFonts, after it (and after loadCjkFonts or loadArabicFonts for the
 *  faces of those scripts); the whole FONTS object may be passed. List in
 *  FONTS only what Fontsource ships (Bangers: ['400']): loadFonts fails on
 *  the rest. For each family, the regular, bold, italic and bold italic it
 *  lacks are declared with its nearest file (the regular for the bold, the
 *  upright for the italic) and loaded for `text`. A CJK face needs the cjk
 *  block; an Arabic face setting Arabic, the arabic block. Resolves to the
 *  number of variants added. */
async function loadComicFonts(faces, text = '') {
  kitStatus('Loading fonts…');
  let added = 0;
  try {
    for (const family of Object.keys(faces)) {
      const meta = await fontsourceMeta(family);
      if (!meta) throw new Error(`api.fontsource.org did not describe ${family}: reload to try again`);
      const weights = meta.weights?.length ? meta.weights : [400, 700];
      const styles = meta.styles?.length ? meta.styles : ['normal'];
      for (const [weight, style] of [[400, 'normal'], [700, 'normal'], [400, 'italic'], [700, 'italic']]) {
        if ((weights.includes(weight) && styles.includes(style)) || hasFace(family, weight, style)) continue;
        const w = weights.reduce((a, b) => (Math.abs(b - weight) < Math.abs(a - weight) ? b : a));
        const s = style === 'italic' && styles.includes('italic') ? 'italic' : 'normal';
        for (const { url, range } of await comicFaceFiles(family, w, s, meta, text)) {
          document.fonts.add(new FontFace(family, `url(${url}) format('woff2')`,
            { weight: String(weight), style, unicodeRange: range }));
        }
        await document.fonts.load(`${style === 'italic' ? 'italic ' : ''}${weight} 16px "${family}"`, text || 'A');
        added++;
      }
    }
  } catch (error) {
    kitFail(error);
    throw error;
  }
  return added;
}

/** The files of a shipped face ({ url, range }): a CJK face's slices (the
 *  cjk block reads them from its stylesheet), else latin, the latin-ext
 *  and greek files `text` needs, and the arabic file when `text` holds
 *  Arabic. */
async function comicFaceFiles(family, weight, style, meta, text) {
  if (meta.subsets?.some((subset) => /^(chinese|japanese|korean)/.test(subset))) {
    if (typeof cjkSlices !== 'function') throw new Error(`${family} is a CJK face: list the cjk kit block`);
    return (await cjkSlices(family, weight, style)).map(({ url, range }) => ({ url, range }));
  }
  const id = fontsourceId(family);
  const file = (subset) => `https://cdn.jsdelivr.net/npm/@fontsource/${id}@5/files/${id}-${subset}-${weight}-${style}.woff2`;
  const files = ['latin', ...kitSubsetsFor(text, meta)].map((subset) => ({ url: file(subset), range: comicRange(subset) }));
  if (meta.subsets?.includes('arabic') && /\p{Script=Arabic}/u.test(text)) {
    if (typeof arabicRange !== 'function') throw new Error(`${family} sets Arabic: list the arabic kit block`);
    files.unshift({ url: file('arabic'), range: arabicRange() });
  }
  return files;
}

/** The unicode-range loadFonts gives a Fontsource file. A function, not a
 *  const: the kit is inlined after the recipe's top-level awaits. */
function comicRange(subset) {
  return {
    latin: 'U+0000-00FF,U+0131,U+0152-0153,U+02BB-02BC,U+02C6,U+02DA,U+02DC,U+0304,U+0308,U+0329,'
      + 'U+2000-206F,U+20AC,U+2122,U+2191,U+2193,U+2212,U+2215,U+FEFF,U+FFFD',
    'latin-ext': 'U+0100-02BA,U+02BD-02C5,U+02C7-02CC,U+02CE-02D7,U+02DD-02FF,U+0304,U+0308,U+0329,'
      + 'U+1D00-1DBF,U+1E00-1E9F,U+1EF2-1EFF,U+2020,U+20A0-20AB,U+20AD-20C0,U+2113,U+2C60-2C7F,U+A720-A7FF',
    greek: 'U+0370-03FF',
  }[subset];
}

/** The PDF font provider of a comic in any script: a CJK face goes to
 *  cjkPdfProvider, an Arabic face to arabicPdfProvider, any other to
 *  fontsourceProvider (the "pdf" block). Each embeds the shipped weight
 *  and style nearest to the one asked for, the file loadComicFonts
 *  declared for the canvas. */
async function comicPdfProvider(family, weight, style, request) {
  const subsets = (await fontsourceMeta(family))?.subsets ?? [];
  if (subsets.some((subset) => /^(chinese|japanese|korean)/.test(subset))) {
    if (typeof cjkPdfProvider !== 'function') throw new Error(`${family} is a CJK face: list the cjk kit block`);
    return cjkPdfProvider(family, weight, style, request);
  }
  if (subsets.includes('arabic') && typeof arabicPdfProvider === 'function') {
    return arabicPdfProvider(family, weight, style, request);
  }
  return fontsourceProvider(family, weight, style, request);
}

/** A panel picture as a resource for art= (and pop=): loads `url`
 *  (write asset('lh-arrive.jpg') in the call, so the lint checks the file)
 *  and declares it with `meta`, its entry in the art manifest:
 *  { width, height, alt, safeArea, anchors, avoid }. The safe area is what
 *  every crop keeps, the anchors the speakers' mouths, heads and faces,
 *  the avoid zones what no balloon covers; all in fractions of the picture,
 *  the same in every language. Without width and height, the picture's own
 *  size. Needs the images block. Resolves to the resource. */
async function comicPanel(id, url, meta = {}) {
  const fileId = decodeURIComponent(url.split('/').pop());
  await loadImage(fileId, url);
  let { width, height } = meta;
  if (!width || !height) {
    const bitmap = await createImageBitmap(new Blob([imageBytes(fileId)]));
    ({ width, height } = bitmap);
    bitmap.close();
  }
  return {
    id, typeId: meta.typeId ?? 'figure', kind: 'bitmap', createdAt: 0, updatedAt: 0,
    bitmap: { fileId, format: /\.png$/i.test(fileId) ? 'png' : 'jpeg', width, height },
    ...(meta.alt && { altText: meta.alt }),
    ...(meta.safeArea && { safeArea: meta.safeArea }),
    ...(meta.anchors?.length && { anchors: meta.anchors }),
    ...(meta.avoid?.length && { avoid: meta.avoid }),
  };
}

// ─── /Kit ───────────────────────────────────────────────────────────────────────

El script.js compuesto funciona tal cual: pégalo como script de módulo en cualquier página o abre la receta en CodePen. Carpeta de la receta en GitHub ↗ (se abre en una nueva pestaña)

Errores frecuentes

Error frecuente

Etiqueta un texto japonés 'ja', nunca zh-Hans ni LANG

Las ediciones de una receta son en y es, pero una muestra japonesa es japonesa en las dos: `locale: LANG` la etiquetaría como inglés o español, y una etiqueta china la compondría con las reglas chinas (puntuación Kaiming, kana pequeño libre de empezar línea, 图 en lugar de 図, formas chinas de los caracteres en el PDF). Escribe 'ja': elige la región de Japón (corte y puntuación de la JLReq, puntos de sésamo, reparto de los furigana, etiquetas 図 y 表) y desactiva la separación silábica. El lint falla un texto con kana bajo una etiqueta zh o ko. Corte de líneas japonés (kinsoku) →

Error frecuente

Las fuentes chinas se cargan por fragmentos, con el bloque cjk

Fontsource sirve una familia china, japonesa o coreana en un centenar de archivos por peso, cada uno con un intervalo de caracteres. loadFonts solo descarga el archivo latin, así que en pantalla los caracteres chinos salen de una fuente del sistema y se miden mal, y fontsourceProvider entrega al PDF ese archivo latin, que los imprime como cajas vacías. Añade el bloque cjk del kit, llama a loadCjkFonts(FONTS, markdown) después de loadFonts (una vez por voz, con el texto que compone, si el libro usa varias fuentes chinas) y pasa a renderToPdf fontProvider: cjkPdfProvider: ambos toman los archivos que contienen los caracteres del texto. Fuentes chinas, japonesas y coreanas →

Error frecuente

Una configuración se cachea por identidad: crea un objeto nuevo

El motor guarda en caché las configuraciones resueltas según la identidad del objeto, así que modificar el mismo objeto y volver a componer reutiliza el resultado anterior. Crea un objeto nuevo en cada composición: por eso la configuración de una receta es una función, config(). Páginas en un canvas →

Error frecuente

Carga todas las fuentes antes de componer

La composición mide el texto con las fuentes que el navegador ha cargado y guarda los anchos, así que una fuente que llega después de la primera composición deja cortes de línea erróneos y un PDF que ya no coincide con la pantalla. Carga antes todos los pesos y estilos, y llama a clearMeasurementCache() antes de recomponer si alguna llega tarde. Fuentes antes de componer →

Pon a la derecha al primer personaje que habla en cada viñeta. Los bocadillos siguen el orden de lectura, así que en la viñeta en la que Sora entrega el amuleto el guion le da la primera frase a Hana, que está a la derecha. Si hablara antes Sora, sus bocadillos se quedarían en su lado de la viñeta, pero las columnas japonesas no dejan sitio debajo para la respuesta de Hana: quedaría a su lado, a la derecha, y se leería primero.
Un bocadillo que no cabe en su viñeta puede salirse del borde, y el motor lo avisa (comicBalloonOverflow). Antes de recortar el diálogo, dale más sitio a esa viñeta en la división.

Créditos

Receta: Ignacio Ferro
Texto: 前の晩 (La noche antes), un manga de kendo de dos páginas escrito para esta receta, con sus rotulaciones en inglés, español, catalán, chino y árabe · Postext Cookbook · CC BY 4.0
Imágenes: El viejo dojo de madera del instituto al anochecer, con las puertas abiertas e iluminadas · Generated With Diffusion Models · original
Hana, sola en el dojo, alza la espada de bambú sobre la cabeza · Generated With Diffusion Models · original
Sora se asoma por la puerta corredera con un amuleto · Generated With Diffusion Models · original
Primer plano del rostro sudoroso de Hana · Generated With Diffusion Models · original
Sora le tiende el amuleto a Hana · Generated With Diffusion Models · original
El entrenador Mori en la puerta, a contraluz, de brazos cruzados · Generated With Diffusion Models · original
Primer plano de la media sonrisa del entrenador Mori · Generated With Diffusion Models · original
Hana se ata el amuleto a la armadura mientras Sora se rasca la cabeza · Generated With Diffusion Models · original
Hana y Sora en la azotea del instituto al atardecer, de espaldas · Generated With Diffusion Models · original
Fuentes: Zen Antique (SIL OFL 1.1) · Dela Gothic One (SIL OFL 1.1) · Comic Neue (SIL OFL 1.1) · Bangers (SIL OFL 1.1) · Noto Sans SC (SIL OFL 1.1) · ZCOOL KuaiLe (SIL OFL 1.1) · Playpen Sans Arabic (SIL OFL 1.1) · Lalezar (SIL OFL 1.1)
Código: MIT, como Postext

Editar este texto ↗ (se abre en una nueva pestaña)Carpeta de la receta en GitHub ↗ (se abre en una nueva pestaña)

En pocas palabras

#Lo que vas a componer

#La respuesta corta

#Ingredientes

#Elaboración

#1 · Lee en el sentido en que se dibujó

#2 · Marca a cada personaje una sola vez, sobre el dibujo

#3 · Deja que cada idioma ponga sus bocadillos

#4 · Carga las fuentes de cada edición con sus palabras

#5 · Pon el original junto a cada edición

#La receta completa

#Errores frecuentes

#Créditos

Más del Recetario

Dos tiras yonkoma en una página

Una novela china vertical, encuadernada por la derecha

Una página rotulada en seis idiomas

Lo que vas a componer

La respuesta corta

Ingredientes

Elaboración

La receta completa

Errores frecuentes

Créditos
